Fig. 15: View Of Rear Oil Seal
Courtesy of GENERAL MOTORS CORP.
1. Remove the rear propeller shaft. Refer to One-Piece Propeller Shaft Replacement or
Two-Piece Propeller Shaft Replacement .
2. Remove the rear oil seal using J 6125-1B (1) and J 23129 (2).
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
Installation Procedure
Fig. 16: Installing The New Rear Oil Seal
Courtesy of GENERAL MOTORS CORP.
1. Using J 36503 install the NEW rear oil seal.
2. Install the rear propeller shaft. Refer to One-Piece Propeller Shaft Replacement or Two-
Piece Propeller Shaft Replacement .
3. Check to transmission fluid level. Add if necessary.
4. Lower the vehicle.
BACKUP LAMP SWITCH REPLACEMENT
Removal Procedure
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
Fig. 17: Locating HO2S Electrical Connector At Harness (Manual 2WD)
Courtesy of GENERAL MOTORS CORP.
1. Raise and suitably support the vehicle. Refer to Lifting and Jacking the Vehicle .
2. Disconnect the backup lamp switch electrical connector (3).
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
