8. Install the engine electrical wiring harness clip to the fuel pipe bracket.
9. Connect the electrical wiring harness connector to the backup lamp switch.
10. Connect the electrical wiring harness connector to the vehicle speed sensor.
IMPORTANT: DO NOT rely on an audible click or a visual verification on
the clutch hydraulic hose quick connect fitting connection.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 26: Clutch Master Cylinder To Clutch Actuator Cylinder Quick Connect Fitting
Courtesy of GENERAL MOTORS CORP.
11. Connect the clutch actuator cylinder hose to the clutch master cylinder hose.
12. Push together the clutch hydraulic hose quick connect fittings, then pull back on the fittings
to verify engagement.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
13. Check the clutch hydraulic hose for kinks or twists.
14. Install the propeller shaft. Refer to One-Piece Propeller Shaft Replacement or Two-
Piece Propeller Shaft Replacement .
15. Fill the transmission with the proper fluid to the correct level.
16. Install the shift lever. Refer to Transmission Control Lever Knob Replacement.
17. Bleed the clutch hydraulic system. Refer to Hydraulic Clutch Bleeding .
POWER TAKE-OFF COVER REPLACEMENT
Fig. 27: Power Take-Off Cover
Courtesy of GENERAL MOTORS CORP.
Callout
Component Name
Preliminary Procedures
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
MAIN SHAFT SEAL REPLACEMENT
Fig. 28: Main Shaft Seal
Courtesy of GENERAL MOTORS CORP.
1. Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle .
2. Drain the transmission fluid. Refer to Transmission Fluid Replacement.
1
Power Take Off Cover Bolts (Qty: 6)
Tighten:: 30 N.m (22 lb ft).
NOTE:
Refer to Fastener Notice .
2
Power Take Off Cover
3
Power Take Off Cover Gasket
Callout
Component Name
Preliminary Procedures
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (M96) - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
