MOBILE TELEPHONE AND NAVIGATION ANTENNA COAXIAL CABLE REPLA Fig. 25: Mobile Telephone and Navigation Antenna Coaxial Cable Replacement Trim Panel with Windshield Defroster Nozzle Grille Replacement (without 2. Remove the radio. Refer to Radio Replacement (without RPO SLT) or Radio Replacement (with RPO SLT). 3. Remove the instrument panel upper compartment. Refer to Instrument Panel Upper Compartment Replacement . 1 Radio Antenna Extension Cable Assembly Disconnect the extension cable from the antenna. Disconnect the extension cable from the radio. Disconnect the extension cable from the center HVAC duct. Callout Component Name Preliminary Procedure
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Cellular, Entertainment, and Navigation - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
AUDIO SYSTEM TRANSCEIVER MODULE REPLACEMENT Fig. 26: Audio System Transceiver Module Replacement 1. Lower the front of the headliner. Refer to Headlining Trim Panel Replacement (Regular Cab) or Headlining Trim Panel Replacement (Crew Cab) or 2. Remove the upper instrument panel (I/P) defroster grille. Refer to Instrument Panel Upper Trim Panel with Windshield Defroster Nozzle Grille Replacement 3. Remove the instrument panel compartment door. Refer to Instrument Panel Storage Compartment Replacement . 4. Remove the interface communication module. Refer to Communication Interface Module Replacement (without RPO SLT) or Communication Interface Module 1 Navigation/Cellular Coaxial Cable 1. If the coaxial antenna cable is taped in the wiring harness then just cut the ends off at the interface communication module and the antenna 2. If needed use a piece of mechanics wire or suitable equivalent to route new cable through windshield pillar and I/P area.
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Cellular, Entertainment, and Navigation - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Courtesy of GENERAL MOTORS CORP. VIDEO DISPLAY REPLACEMENT (SECOND ROW) Fig. 27: Video Display Replacement (Second Row) Callout Component Name Preliminary Procedure: 1 Roof Console Assembly 2 Audio System Transceiver Module Assembly 1. Disconnect the electrical connector. 2. Use a flat bladed tool to release the tabs that secure the module to the roof console on each side of the module. 3. Slide forward and up to release from the roof console. Callout Component Name Video Display Assembly Screws (Qty: 4)
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Cellular, Entertainment, and Navigation - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
REAR SEAT AUDIO CONTROL REPLACEMENT Fig. 28: Rear Seat Audio Control Replacement 1 Tighten: 2 N.m (18 lb in) NOTE: Refer to Fastener Notice . 2 Video Display Assembly 1. Pull down to disengage the retainer clip and remove from the vehicle. 2. Disconnect the electrical connector. Callout Component Name
2008 Chevrolet Silverado 1500 2008 ACCESSORIES & EQUIPMENT Cellular, Entertainment, and Navigation - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
