Chevrolet Silverado / GMC Sierra. Manual - part 2245
RADIO FRONT SPEAKER GRILLE REPLACEMENT
Fig. 29: Radio Front Speaker Grille Replacement
Courtesy of GENERAL MOTORS CORP.
1
Front Floor Console Compartment Bezel Assembly
Refer to Front Floor Console Compartment Bezel Replacement .
2
Rear Radio Control Assembly Screw (Qty: 4)
Tip: Tighten the fasteners equally to ensure the control assembly seats evenly.
Tighten: 1.5 N.m (13 lb in)
NOTE:
Refer to Fastener Notice .
3
Rear Radio Control Assembly
Procedure:
Disconnect the electrical connectors from the rear radio control assembly.
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Cellular, Entertainment, and Navigation - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
RADIO FRONT SPEAKER REPLACEMENT
Fig. 30: Radio Front Speaker Replacement
Courtesy of GENERAL MOTORS CORP.
Callout
Component Name
1
Front Speaker Grille
2
Front Speaker Grille Retainer Clip (Qty: 4)
Callout
Component Name
Preliminary Procedure:
Remove the front speaker grille. Refer to Radio Front Speaker Grille Replacement.
1
Front Speaker Screw (Qty: 2)
Tighten: 6 N.m (53 lb in)
NOTE:
Refer to Fastener Notice .
2
Front Speaker Assembly
Tip: Disconnect the electrical connector.
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Cellular, Entertainment, and Navigation - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
FRONT UPPER SPEAKER REPLACEMENT
Fig. 31: Front Upper Speaker Replacement
Courtesy of GENERAL MOTORS CORP.
RADIO FRONT SIDE DOOR SPEAKER REPLACEMENT
Callout
Component Name
Preliminary Procedure:
Remove the windshield pillar garnish molding. Refer to Windshield Pillar Garnish
Molding Replacement .
1
Radio Windshield Side Garnish Molding Speaker Assembly
Tip: Press in the tabs on the speaker to release from the windshield pillar.
2
Radio Windshield Side Garnish Molding Speaker Grille
Tip: Press in on the tabs of the speaker grille to release from the windshield
pillar.
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Cellular, Entertainment, and Navigation - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
Fig. 32: Radio Front Side Door Speaker Replacement
Courtesy of GENERAL MOTORS CORP.
Callout
Component Name
Preliminary Procedure:
Remove the front door inner trim panel. Refer to Front Side Door Trim Panel
Replacement (YE9) or Front Side Door Trim Panel Replacement (SLT) .
1
Front Door Speaker Screw
Tighten: 3 N.m (25 lb in)
NOTE:
Refer to Fastener Notice .
2
Front Door Speaker
Tip: Disconnect the electrical connectors.
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Cellular, Entertainment, and Navigation - Cab & Chassis Sierra, Cab & Chassis
Silverado, Sierra & Silverado
