Chevrolet Silverado / GMC Sierra. Manual - part 1919
Fig. 55: Locating Tab On Engine Block
Courtesy of GENERAL MOTORS CORP.
IMPORTANT: DO NOT raise and/or support the engine by the crankshaft
balancer or oil pan.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
5. Place an adjustable (screw type) jack to the tab (1) located on the engine block.
Fig. 56: View Of Engine Mount To Frame Bolts
Courtesy of GENERAL MOTORS CORP.
6. Remove the engine mount to frame bolts (1).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 57: View Of Engine Mount To Engine Bolts
Courtesy of GENERAL MOTORS CORP.
7. Remove the two top engine mount to engine bolts (1).
8. Using the adjustable jack, raise the engine slightly until there is enough clearance to remove
the engine mount.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 58: View Of Engine Mount
Courtesy of GENERAL MOTORS CORP.
9. Remove the engine mount.
Installation Procedure
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
