Chevrolet Silverado / GMC Sierra. Manual - part 1917
Fig. 48: View Of Engine Mount
Courtesy of GENERAL MOTORS CORP.
9. Remove the engine mount.
Installation Procedure
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 49: View Of Engine Mount
Courtesy of GENERAL MOTORS CORP.
1. Position the engine mount to the engine.
NOTE:
Refer to Fastener Notice .
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 50: View Of Engine Mount To Engine Bolts
Courtesy of GENERAL MOTORS CORP.
2. Install the two top engine mount to engine bolts (1).
Tighten: Tighten the bolts to 50 N.m (37 lb ft).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
Fig. 51: Locating Tab On Engine Block
Courtesy of GENERAL MOTORS CORP.
3. Using the adjustable jack, lower the engine until the engine mount is sitting flush on the
frame.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado,
Sierra & Silverado
