4. Remove the adjustable jack from the engine block lifting tab (1). Fig. 52: View Of Engine Mount To Frame Bolts 5. Install the engine mount to frame bolts (1). Tighten: Tighten the bolts to 65 N.m (48 lb ft) starting with the middle bolt then either side 6. Install the starter motor. Refer to Starter Motor Replacement (4.8L, 5.3L, 6.0L, and 6.2L) .
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 53: View Of Engine Mount To Engine Bolts 7. Install the two lower engine mount to engine bolts (1). Tighten: Tighten the bolts to 50 N.m (37 lb ft). 8. If the vehicle is equipped with 4WD, Install the front drive axle. Refer to Differential Carrier Assembly Replacement (1500 FWD) or Differential Carrier Assembly 9. Install the upper intake manifold sight shield. Refer to Upper Intake Manifold Cover Replacement.
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
ENGINE MOUNT REPLACEMENT - RIGHT SIDE (2500 LY6) Removal Procedure Fig. 54: View Of Engine Mount To Engine Bolts NOTE: When raising or supporting the engine for any reason, do not use a
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
1. Remove the upper intake manifold sight shield. Refer to Upper Intake Manifold Cover Replacement. 2. If the vehicle is equipped with four wheel drive (4WD), remove the front drive axle. Refer to Differential Carrier Assembly Replacement (1500 FWD) or Differential Carrier 3. Remove the two lower engine mount to engine bolts (1). 4. Remove the starter motor. Refer to Starter Motor Replacement (4.8L, 5.3L, 6.0L, and 6.2L) .
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
