1. Remove the upper intake manifold sight shield. Refer to Upper Intake Manifold Cover Replacement. 2. If the vehicle is equipped with four wheel drive (4WD), remove the front drive axle. Refer to Differential Carrier Assembly Replacement (1500 FWD) or Differential Carrier 3. Remove the two lower engine mount to engine bolts (1). 4. Remove the starter motor. Refer to Starter Motor Replacement (4.8L, 5.3L, 6.0L, and 6.2L) .
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 45: Locating Tab On Engine Block IMPORTANT: DO NOT raise and/or support the engine by the crankshaft balancer or oil pan.
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
5. Place an adjustable (screw type) jack to the tab (1) located on the engine block. Fig. 46: View Of Engine Mount To Frame Bolts 6. Remove the engine mount to frame bolts (1).
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 47: View Of Engine Mount To Engine Bolts 7. Remove the two top engine mount to engine bolts (1). 8. Using the adjustable jack, raise the engine slightly until there is enough clearance to remove the engine mount.
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
