Fig. 59: View Of Engine Mount 1. Position the engine mount to the engine. NOTE: Refer to Fastener Notice .
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 60: View Of Engine Mount To Engine Bolts 2. Install the two top engine mount to engine bolts (1). Tighten: Tighten the bolts to 50 N.m (37 lb ft).
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 61: Locating Tab On Engine Block 3. Using the adjustable jack, lower the engine until the engine mount is sitting flush on the frame.
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
4. Remove the adjustable jack from the engine block lifting tab (1). Fig. 62: View Of Engine Mount To Frame Bolts 5. Install the engine mount to frame bolts (1). Tighten: Tighten the bolts to 65 N.m (48 lb ft) starting with the middle bolt then either side 6. Install the starter motor. Refer to Starter Motor Replacement (4.8L, 5.3L, 6.0L, and 6.2L) .
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Mechanical - 4.8L, 5.3L, 6.0L, 6.2L, or 7.0L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
