Connection (w/Dual Batteries). STARTER MOTOR REPLACEMENT (6.6L) Removal Procedure Fig. 254: View Of Starter Solenoid Cable & Components 1. Disconnect the negative battery cable. Refer to Battery Negative Cable Disconnection and Connection (w/Single Battery) or Battery Negative Cable Disconnection and CAUTION: Refer to BATTERY DISCONNECT CAUTION .
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Connection (w/Auxiliary Battery) or Battery Negative Cable Disconnection and 2. Remove the wheelhouse liner. Refer to Front Wheelhouse Liner Replacement - Right Side (GMC) or Front Wheelhouse Liner Replacement - Right Side (Chevrolet) . 3. Working through the wheelhouse, remove the starter solenoid cable nut (6) from the starter. 4. Remove the starter solenoid cable (7) from the starter. Fig. 255: View Of Starter Solenoid Cable Terminal, Bracket & Bolts
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
5. Working through the wheelhouse, remove the engine wiring harness lead nut (3). 6. Remove the engine wiring harness lead (2) from the starter motor. 7. Remove the turbocharger exhaust pipe. Refer to Turbocharger Exhaust Pipe Replacement (6.6L) . Fig. 256: View Of Starter Motor & Bolts 8. From under the vehicle, remove the starter motor bolts (1). 9. Remove the starter motor.
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Installation Procedure Fig. 257: View Of Starter Motor & Bolts 1. Install the starter motor. 2. Install the starter motor bolts (1). Tighten: Tighten the bolts to 85 N.m (63 lb ft). NOTE: Refer to Fastener Notice .
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
