3. Install the turbocharger exhaust pipe. Refer to Turbocharger Exhaust Pipe Replacement (6.6L) . Fig. 258: View Of Starter Solenoid Cable Terminal, Bracket & Bolts 4. Install the engine wiring harness lead (2) to the starter motor. 5. Install the engine wiring harness lead nut (3). Tighten: Tighten the nut to 3.4 N.m (30 lb in).
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 259: View Of Starter Solenoid Cable & Components 6. Install the starter solenoid cable (7) to the starter. 7. Install the starter solenoid cable nut (6) to the starter. Tighten: Tighten the nut to 9 N.m (80 lb in). 8. Install the wheelhouse liner. Refer to Front Wheelhouse Liner Replacement - Right Side (GMC) or Front Wheelhouse Liner Replacement - Right Side (Chevrolet) . 9. Connect the negative battery cable. Refer to Battery Negative Cable Disconnection and Connection (w/Single Battery) or Battery Negative Cable Disconnection and
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Connection (w/Dual Batteries). STARTER MOTOR SOLENOID REPLACEMENT (6.6L) Removal Procedure Fig. 260: View Of M-Terminal Stud Weather Cover & Epoxy Coating (6.6L (LB7) 1. Remove the starter motor. Refer to Starter Motor Replacement (4.3L) or Starter Motor Replacement (4.8L, 5.3L, 6.0L, and 6.2L) or Starter Motor Replacement (6.6L). 2. Reposition the M-terminal stud weather cover (1). 3. Clean the epoxy coating (2) from the M-terminal stud.
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 261: View Of M-Terminal Stud, Nut & Cable (6.6L (LB7) Engine) 4. Loosen the M-terminal stud nut. 5. Remove the cable from the M-terminal stud.
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
