Chevrolet Silverado / GMC Sierra. Manual - part 1769
Fig. 250: View Of Starter & Bolts (4.8L, 5.3L & 6.0L)
Courtesy of GENERAL MOTORS CORP.
9. Position the starter into place.
10. Install the starter bolts.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Tighten: Tighten the bolts to 50 N.m (37 lb ft).
11. Install the right front wheelhouse liner. Refer to Front Wheelhouse Liner Replacement -
Right Side (GMC) or Front Wheelhouse Liner Replacement - Right Side
(Chevrolet) .
12. Install the right front wheel and tire. Refer to Tire and Wheel Removal and Installation .
13. Raise and support the vehicle.
Fig. 251: View Of Engine Wiring Harness Electrical Connector & Components
Courtesy of GENERAL MOTORS CORP.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
14. Connect the engine wiring harness electrical connector (4) to the oil level sensor.
Fig. 252: View Of Transmission Cover Bolt
Courtesy of GENERAL MOTORS CORP.
15. Install the transmission cover bolt.
Tighten: Tighten the bolt to 9 N.m (80 lb in).
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 253: View Of Oil Pan Skid Plate & Bolts
Courtesy of GENERAL MOTORS CORP.
16. For 2500 series vehicles, install the oil pan skid plate and tighten the rear 2 bolts and install
and tighten the front 2 bolts, if equipped.
Tighten: Tighten the bolts to 28 N.m (21 lb ft).
17. Lower the vehicle.
18. Connect the negative battery cable. Refer to Battery Negative Cable Disconnection and
Connection (w/Single Battery) or Battery Negative Cable Disconnection and
Connection (w/Auxiliary Battery) or Battery Negative Cable Disconnection and
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
