Fig. 210: View Of Ground Strap Nut At Front Of Dash Stud
Courtesy of GENERAL MOTORS CORP.
3. Remove the ground strap nut from the stud at the front of dash.
4. Remove the ground strap from the stud.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Installation Procedure
Fig. 211: View Of Ground Strap Nut At Front Of Dash Stud
Courtesy of GENERAL MOTORS CORP.
NOTE:
Refer to Fastener Notice .
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
1. Install the ground strap to the stud.
2. Install the ground strap nut to the stud at the front of dash.
Tighten: Tighten the nut to 9 N.m (80 lb in).
Fig. 212: View Of Ground Strap Bolt
Courtesy of GENERAL MOTORS CORP.
3. Position the ground strap to the rear of the left cylinder head.
4. Install the ground strap bolt.
Tighten: Tighten the bolt to 16 N.m (12 lb ft).
ENGINE GROUND STRAP REPLACEMENT (4.8L, 5.3L, 6.0L, AND 6.2L)
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Removal Procedure
Fig. 213: View Of Ground Cable Bolt At Engine Block
Courtesy of GENERAL MOTORS CORP.
1. Remove the engine wiring harness ground bolt.
2. Reposition the engine wiring harness ground and ground strap.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
