Fig. 199: View Of Battery Tray, Brackets & Nuts 4. Remove the nut securing the battery tray to the front fender inner panel. 5. Remove the 3 nuts securing the battery tray to the battery tray bracket. 6. Remove the battery tray from the vehicle. Installation Procedure
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 200: View Of Battery Tray, Brackets & Nuts 1. Install the battery tray to the vehicle. 2. Install the 3 nuts securing the battery tray to the battery tray bracket. Tighten: Tighten the nuts to 20 N.m (15 lb ft). 3. Install the nut securing the battery tray to the front fender inner panel. Tighten: Tighten the nut to 9 N.m (80 lb in). NOTE: Refer to Fastener Notice .
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 201: View Of Battery Tray Front Support & Bolts 4. Install the battery tray front support. 5. Install the battery tray front support bolts. Tighten: Tighten the bolts to 20 N.m (15 lb ft). 6. Install the battery. Refer to Battery Replacement. AUXILIARY BATTERY TRAY REPLACEMENT (6.2L, AND 6.6L)
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 202: Auxiliary Battery Tray Replacement (6.2L, and 6.6L) Callout Component Name Preliminary Procedure:
2008 Chevrolet Silverado 1500 2008 ENGINE Engine Electrical - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
