Chevrolet Silverado / GMC Sierra. Manual - part 1350
Fig. 107: View Of Differential Carrier Assembly
Courtesy of GENERAL MOTORS CORP.
2. Install the differential carrier assembly.
2008 Chevrolet Silverado 1500
2008 Driveline/Axle Front Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 108: View Of Right Differential Carrier Mounting Nuts & Washers
Courtesy of GENERAL MOTORS CORP.
3. Install the right mounting nuts and washers.
Tighten: Tighten the mounting nuts to 100 N.m (75 lb ft).
NOTE:
Refer to Fastener Notice .
2008 Chevrolet Silverado 1500
2008 Driveline/Axle Front Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 109: View Of Left Differential Carrier Mounting Bolts
Courtesy of GENERAL MOTORS CORP.
4. Install the left mounting bolts for the differential carrier.
Tighten: Tighten the mounting nuts to 100 N.m (75 lb ft).
5. Remove the transmission jack stand.
2008 Chevrolet Silverado 1500
2008 Driveline/Axle Front Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 110: View Of Differential Carrier Wiring Harness
Courtesy of GENERAL MOTORS CORP.
6. Install the wiring harness on the differential carrier, if needed.
2008 Chevrolet Silverado 1500
2008 Driveline/Axle Front Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
