4WD).
DIFFERENTIAL CARRIER ASSEMBLY REPLACEMENT (1500 FWD)
Removal Procedure
1. Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle .
2. Remove the lower control arm crossmember. Refer to Drivetrain and Front Suspension
Frame Front Crossmember Replacement (1500, 2500 LD) .
3. Drain the differential carrier. Refer to Front Axle Lubricant Replacement.
IMPORTANT: If removing the differential carrier assembly to service other
components, it is not necessary to drain the differential
carrier.
2008 Chevrolet Silverado 1500
2008 Driveline/Axle Front Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 100: View Of Differential Carrier Wiring Harness
Courtesy of GENERAL MOTORS CORP.
4. Remove the wiring harness from the differential carrier, if needed.
2008 Chevrolet Silverado 1500
2008 Driveline/Axle Front Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 101: View Of Front Axle Actuator Electrical Connector
Courtesy of GENERAL MOTORS CORP.
5. Remove the electrical connector from the actuator motor.
2008 Chevrolet Silverado 1500
2008 Driveline/Axle Front Drive Axle - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
