1. Ensure the reservoir is filled to the fill line with new hydraulic clutch fluid. Add fluid if required. Use hydraulic clutch fluid GM P/N 12345347 (Canadian P/N 10953517). 2. Press the clutch pedal in completely to the floor panel. 3. Open the bleeder screw in order to purge the air from the system. 4. Close the bleeder and release the clutch pedal. 5. Repeat steps 2, 3, and 4 until all the air is out of the clutch system. 1. Check and refill the reservoir as needed while bleeding. 2. After bleeding, pump the clutch pedal several times. If clutch engagement is not satisfactory, repeat the bleed procedure. 6. If the previous procedures are unsuccessful, perform the following steps. 1. Pump the clutch pedal very fast with full strokes for 30 seconds. 2. Stop pumping and let the air escape into the reservoir while moving the rubber pad up and down 12 mm (0.5 in) for 30 seconds. 3. Repeat this procedure, as necessary. CLUTCH PEDAL ENGINE START SWITCH REPLACEMENT Removal Procedure NOTE: DO NOT use fluid which has been bled from a hydraulic clutch IMPORTANT: Ensure no air is drawn into the clutch system.
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Clutch - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 15: Clutch Pedal Position Switch Electrical Connector 1. Disconnect the clutch pedal position switch electrical connector (1).
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Clutch - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 16: Clutch Pedal Engine Start Switch 2. Remove the plastic retainer (1) tabs from the clutch pedal position switch (2). 3. Remove the clutch pedal position switch (2) from the pushrod. Installation Procedure
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Clutch - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 17: Clutch Pedal Engine Start Switch 1. Install the clutch pedal position switch (2) to the pushrod. 2. Install the plastic retainer (1) tabs to the clutch pedal position switch (2).
2008 Chevrolet Silverado 1500 2008 TRANSMISSION Clutch - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
