Chery Tiggo T11 LHD. Manual - part 17

Chery T11 Service Manual

Body and Accessories

-66-

Crosssection C3-C3, requirements on clearance and levelness.

Crosssection C4-C4, requirements on clearance and levelness.

Side wall

Rear
bumper

Rear
headlight

Chery T11 Service Manual

Body and Accessories

-67-

Crosssection C5-C5, requirements on clearance and levelness.

Side wall

Fuel

tank

cover

Chery T11 Service Manual

Body and Accessories

-68-

Rear View

Chery T11 Service Manual

Body and Accessories

-69-

Crosssection C1-C1, requirements on clearance and levelness.

Crosssection C2-C2, requirements on clearance and levelness.

Crosssection C3-C3, requirements on clearance and levelness.

Rear

back

door

Side wall

Rear

back

door

Rear

back

door

Head cover
