Diagnostic Procedure 1. CHECK GROUND CONNECTIONS • Turn ignition switch off. • Loosen and retighten ground screws on the body (See Ground Inspection in Section 03 Electronic Engine Con- trols). • Inspect ground connections E-207 and E-208 mounting position (See Vehicle Wiring Harness Layout - Engine Room Harness (With 1.6L/1.8L Engine) in Section 16 Wiring). Are the ground connections OK? Yes >> Go to the next step. No >> Repair or replace ground connections. 2. CHECK TPS ELECTRICAL CONNECTOR • Disconnect the TPS (1) electrical connector. • Inspect the electrical connector for damage. Is the electrical connector OK? Yes >> Go to the next step. No >> Repair or replace the electrical connector as necessary. DIAGNOSIS & TESTING VISMD030203 03
|
