Figure 95 Fuel temperature sensor Specifications Supplier BOSCH Max. tightening torque 35 Nm TECNICAL VIEW 8527 8528 WIRING DIAGRAM PERSPECTIVE VIEW 8529 8530 RESISTANCE TREND SECTION 3 - INDUSTRIAL APPLICATION 39 Pin Function Cable colour 2 To pin 6 of EDC control unit – 3 To pin 11 of EDC control unit – |
