Wing to front lid Location Explanation Type Basic value Tolerance 1 Tolerance 2 Wing to front lid Determine left and right gap Gap dimension A 4 mm +1 mm Wing to front lid Only lowered Gap dimension B 0.5 mm Filler flap to wing Location Explanation Type Basic value Tolerance 1 Tolerance 2 Filler flap to wing All the way round Gap dimension A 3.5 mm +/-0.5 mm Diagnostic system: reading out fault memory and activating systems Gap dimensions, body front 4605 |
