9 - Shock Absorber with Right Rear Damping Adjustment Valve - N339-
❑ Shock absorber, removing and installing. Refer to
⇒ “6.2 Shock Absorber, Removing and Installing”, page 193
❑ Shock absorber, servicing. Refer to
⇒ “6.3 Shock Absorber, Servicing”, page 200
10 - Shock Absorber with Left Rear Damping Adjustment Valve - N338-
❑ Shock absorber, removing and installing. Refer to
⇒ “6.2 Shock Absorber, Removing and Installing”, page 193
❑ Shock absorber, servicing. Refer to
⇒ “6.3 Shock Absorber, Servicing”, page 200
11 - Shock Absorber with Left Front Damping Adjustment Valve - N336-
❑ Removing and installing the suspension strut. Refer to
⇒ “3.2 Suspension Strut, Removing and Installing”, page 45
❑ Servicing the suspension strut. Refer to
⇒ “3.3 Suspension Strut, Servicing”, page 51
.
1.1.2
Overview - Electronic Damping, Multi-Link Suspension, Golf
1 - Right Front Level Control
Sensor - G289-
❑ Removing and instal‐
ling. Refer to
2 - Right Front Body Accelera‐
tion Sensor - G342-
❑ Removing and instal‐
ling. Refer to
3 - Left Rear Body Acceleration
Sensor - G699-
❑ Component location: in
the luggage compart‐
ment on the left shock
absorber tower behind
the left side trim panel
❑ Removing and instal‐
ling. Refer to
4 - Electronic Damping Control
Module - J250-
❑ Removing and instal‐
ling. Refer to
ule J250 , Removing and Installing, Golf”, page 272
❑ Component location: the Electronic Damping Control Module - J250- is installed in the luggage com‐
partment behind the left side trim panel.
❑ If the Electronic Damping Control Module - J250- is being replaced, the
Replace control module
function must be performed using the
⇒ “3.3 Suspension Strut, Servicing”, page 51
.
