Volkswagen Golf / Golf GTI / Golf Variant. Manual - part 769

Rear Brakes - CL 38 (15”) Torsion Beam Rear Suspension

Item PR Number



1KD

1

Brake Caliper

CI 38 (15”)

2

Brake pad,

thickness

mm

11

Brake pad, wear

limit without

backing plate

mm

3

3

Brake Rotor

diam‐

eter in

mm

253

Brake rotor,

thickness

mm

10

Brake rotor,

wear limit

mm

8

4

Brake caliper,

piston

diam‐

eter in

mm

38

Rear Brakes - CL 38 HRA Torsion Beam Rear Suspension

Item PR Number



1KD

1

Brake Caliper

CI 38 HRA

2

Brake pad,

thickness

mm

11

Brake pad, wear

limit without

backing plate

mm

3

3

Brake Rotor

diam‐

eter in

mm

253

Brake rotor,

thickness

mm

10

Brake rotor,

wear limit

mm

8

4

Brake caliper,

piston

diam‐

eter in

mm

38

Rear Brakes - C 38 Torsion Beam Rear Suspension

Item PR Number



1KD

1

Brake Caliper

C 38

2

Brake pad,

thickness

mm

11

Brake pad, wear

limit without

backing plate

mm

3

3

Brake Rotor

diam‐

eter in

mm

253

Brake rotor,

thickness

mm

10

Brake rotor,

wear limit

mm

8

4

Brake caliper,

piston

diam‐

eter in

mm

38

4

Brakes Inspection

⇒ “4.1 General Information”, page 9
⇒ “4.2 Front Wheel Drive Vehicles, Checking”, page 9

4.1

General Information

♦ The testing takes place on a test stand.
♦ During testing, manual transmission vehicles must be placed

in neutral and automatic transmission vehicles placed in »N«.

♦ Always follow the instructions provided by the test stand man‐

ufacturer.

Note

The brake control systems do not function when the ignition is off.

4.2

Front Wheel Drive Vehicles, Checking

The brake test is to be performed on a one-axle roller test stand.
Do not exceed a test speed of 6 km/h (4 mph).
Volkswagen approved test stands meet these requirements.

45 – Antilock Brake System

1

General Information

⇒ “1.1 ABS Repair Instructions”, page 10

1.1

ABS Repair Instructions

The ABS brake system is divided diagonally (two circuits). The

vacuum brake servo unit boosts the brakes pneumatically.
Models with ABS do not have a mechanical brake pressure reg‐

ulator. A specially coordinated software program inside the ABS

Control Module - J104- determines brake pressure allocation at

the rear axle.
