Volkswagen Golf / Golf GTI / Golf Variant. Manual - part 210

Step

Procedure

Result / Action to Take

4

• Final Procedure
• Perform a road test to verify repair.
• Do any DTC’s return:

– YES:

♦ Check the DTC memory. Refer to

⇒ “3.3.4 Diagnostic Mode 04 - Erase DTC

Memory”, page 26

 .

♦ Perform the diagnostic procedure for that DTC.
– NO:

♦ Repair is complete. Generate readiness code.

Refer to

⇒ “3.2 Readiness Codes”, page 19

 .

♦ Return vehicle to Customer.

3.6.27

Oxygen Sensor 1 After Catalytic Con‐

verter - GX7- , Checking

General Description
The Oxygen Sensor 1 After Catalytic Converter - GX7- down‐

stream of the primary catalytic converter supplies the Engine

Control Module - J623- with a voltage signal (nonlinear) indicating

“rich” or “lean. If the primary catalytic converter is supersaturated

with oxygen (lean mixture), Oxygen Sensor 1 After Catalytic Con‐

verter - GX7- will send the Engine Control Module - J623- a

nonlinear signal indicating the lean mixture condition. The mixture

is then enriched with fuel until the oxygen has been “displaced”

from the catalytic converter. This condition, in turn, is registered

by Oxygen Sensor 1 After Catalytic Converter - GX7- as a non‐

linear signal indicating the rich mixture condition. The mixture is

then leaned out by the Engine Control Module - J623- . If the

nonlinear signal is received again, the mixture will again be en‐

riched. The frequency, or period, during which the mixture is

enriched or leaned out is variable, being dependent on the gas

flow rate (engine load) at that moment.
Note the Oxygen Sensor 1 After Catalytic Converter - GX7- is also

referred to as the Oxygen Sensor After Three Way Catalytic Con‐

verter - G130- .
The Oxygen Sensor 1 After Catalytic Converter - GX7- contains

the following components:
♦ Oxygen Sensor After Three Way Catalytic Converter - G130-
♦ Heater For Oxygen Sensor 1 After Catalytic Converter - Z29-
The Oxygen Sensor 1 After Catalytic Converter - GX7- compo‐

nents cannot be serviced separately, it must be serviced as a unit.
Special tools and workshop equipment required
♦ Multimeter.
♦ Wiring Diagram.
♦ Scan Tool.
Test requirements
• Fuses OK.
• Battery voltage OK.
• Switch OFF all electrical and electronic accessories.
• Vehicles with Auto. Transmission, ensure Selector Lever po‐

sition is in “P”.

• Vehicles with Man. Transmission, ensure Shifter Lever posi‐

tion is in “N” with Parking Brake applied.

GTI 2014 ➤

Generic Scan Tool - Edition 04.2015

3. Diagnosis and Testing

513

Pro

te

c

t

ed

  b

y

  co

p

y

rig

h

t.

C

o

p

y

in

g

  fo

r

pr

iv

a

t

e

 o

r

 c

o

m

m

e

r

c

ia

l

p

u

rp

o

s

e

s

,

 i

n

 p

a

rt

o

r i

n

 w

h

o

le

,

is

 n

o

t

 p

e

r

m

it

t

e

d

 u

n

l

e

s

s

 a

ut

ho

r

i

s

ed

 b

y

 V

olk

sw

a

ge

n AG

.



V

olk

s

w

a

g

en

 AG do

es

n

ot g

uar

ante

e

 or a

c

c

ep

t

 a

ny



li

a

b

i

li

t

y

 w

ith

 r

e

s

p

e

c

t

 t

o



th

e

 c

o

rr

e

c

t

n

e

s

s



o

f

in

fo

r

m

a

tio

n

 in

 th

is

 d

o

c

um

en

t.

C

o

py

rig

ht b

y



V

olk

sw

a

ge

n



A

G.
