DTC / Descrip‐ tion Monitor Strategy Descrip‐ tion Malfunction Crite‐ ria and Threshold Value Secondary Parame‐ ters with Enable Conditions Monitoring Time Length MIL Il‐ lum. Component Diag‐ nostic Procedure P0326 Knock/ Com‐ bustion Vibra‐ tion Sensor 1 Circuit Range/ Per‐ for‐ mance Bank 1 or Single Sensor Knock Sensor Rationali‐ ty Check Low • Difference be‐ tween knock sensor signal and average knock sensor signal < 0.00 – 0.12 V • ECT @ cylinder head > 60° C • MAF > 229.00 mg/rev • 4.3 s uous • 2 DCY – Check the Knock Sensor 1 - G61- . Refer to P0327 Knock/ Com‐ bustion Vibra‐ tion Sensor 1 Circuit Low Bank 1 or Single Sensor Knock Sensor Out Of Range • Sensor signal < 0.12 – 0.31 V • ECT @ cylinder head > 60° C • MAF > 229.00 mg/rev • Engine speed > 2,016 RPM • 4.0 s uous • 2 DCY – Check the Knock Sensor 1 - G61- . Refer to GTI 2014 ➤ Generic Scan Tool - Edition 04.2015 3. Diagnosis and Testing 101 |
