592

LC200_OM_OM60T03U_(U)

8-1. Specifications

Open splice

Any parting at any junction of tread, sidewall,

or innerliner that extends to cord material

Outer diameter

The overall diameter of an inflated new tire

Overall width

The  linear  distance  between  the  exteriors  of

the sidewalls of an inflated tire, including ele-

vations due to labeling, decorations, or protec-

tive bands or ribs

Passenger car tire

A  tire  intended  for  use  on  passenger  cars,

multipurpose passenger vehicles, and trucks,

that  have  a  gross  vehicle  weight  rating

(GVWR) of 10,000 lb. or less.

Ply

A layer of rubber-coated parallel cords

Ply separation

A  parting  of  rubber  compound  between  adja-

cent plies

Pneumatic tire

A  mechanical  device  made  of  rubber,  chemi-

cals, fabric and steel or other materials, that,

when  mounted  on  an  automotive  wheel,  pro-

vides the traction and contains the gas or fluid

that sustains the load

Radial ply tire

A  pneumatic  tire  in  which  the  ply  cords  that

extend to the beads are laid at substantially 90

degrees to the centerline of the tread

Reinforced tire

A tire designed to operate at higher loads and

at  higher  inflation  pressures  than  the  corre-

sponding standard tire

Section width

The  linear  distance  between  the  exteriors  of

the sidewalls of an inflated tire, excluding ele-

vations due to labeling, decoration, or protec-

tive bands

Sidewall

That  portion  of  a  tire  between  the  tread  and

bead

Sidewall separation

The parting of the rubber compound from the

cord material in the sidewall

Tire related term

Meaning

LC200_OM_OM60T03U_(U)

593

8-1. Specifications

8

Vehi

cl

e specificatio

ns

*

: Table 1



 Occupant loading and distribution for vehicle normal load for

various designated seating capacities

Snow tire

A tire that attains a traction index equal to or

greater  than  110,  compared  to  the ASTM  E-

1136  Standard  Reference  Test  Tire,  when

using  the  snow  traction  test  as  described  in

ASTM  F-1805-00,  Standard  Test  Method  for

Single  Wheel  Driving  Traction  in  a  Straight

Line on Snow-and Ice-Covered Surfaces, and
which is marked with an Alpine Symbol (

)

on at least one sidewall

Test rim

The rim on which a tire is fitted for testing, and

may  be  any  rim  listed  as  appropriate  for  use

with that tire

Tread

That  portion  of  a  tire  that  comes  into  contact

with the road

Tread rib

A  tread  section  running  circumferentially

around a tire

Tread separation

Pulling away of the tread from the tire carcass

Treadwear  indicators

(TWI)

The  projections  within  the  principal  grooves

designed  to  give  a  visual  indication  of  the

degrees of wear of the tread

Wheel-holding fixture

The  fixture  used  to  hold  the  wheel  and  tire

assembly securely during testing

Tire related term

Meaning

Designated seating

capacity, Number of

occupants

Vehicle normal load,

Number of occupants

Occupant distribution

in a normally loaded

vehicle

2 through 4

2

2 in front

5 through 10

3

2 in front, 1 in second

seat

11 through 15

5

2 in front, 1 in second

seat, 1 in third seat, 1

in fourth seat

16 through 20

7

2 in front, 2 in second

seat, 2 in third seat, 1

in fourth seat

594

LC200_OM_OM60T03U_(U)

8-2. Customization

Customizable features

When customizing vehicle features, ensure that the vehicle is parked
in a safe place with the shift lever in P and the parking brake set.

■

Changing by using the navigation system

Press the “SETUP” button on the navigation system.
Select “Vehicle” on the “Setup” screen.

Various setting can be changed. Refer to the list of settings that can
be changed for details.

■

Changing by using the multi-information display

Use the meter control switches to select

 on the multi-infor-

mation display.

Choose the desired item using

, and then press

.

Select  the  desired  setting  by  operating

,  and  then  press

.

To stop the selection, press

 to return to the previous screen.

Your vehicle includes a variety of electronic features that can be
personalized to suit your preferences. The settings of these fea-
tures can be changed by using the navigation system, the multi-
information display, or at your Toyota dealer.

Customizing vehicle features

1

2

1

2

3

LC200_OM_OM60T03U_(U)

595

8-2. Customization

8

Vehi

cl

e specificatio

ns

Some function settings are changed simultaneously with other func-
tions being customized. Contact your Toyota dealer for further details.

Settings that can be changed using the navigation system
Settings that can be changed using the multi-information display
Settings that can be changed by your Toyota dealer

Definition of symbols: O = Available, – =Not available

■

Smart key system (



P. 138)

■

Wireless remote control (



P. 114)

Customizable features

1
2
3

Function

Default setting

Customized

setting

Smart key system

On

Off

— —

O

Smart door unlocking

Driver’s door

All the doors

O

—

O

1

2

3

Function

Default setting

Customized

setting

Wireless remote control

On

Off

— —

O

Unlocking operation

Driver’s door

unlocked in one

step, all doors

unlocked in two

steps

All doors

unlocked in one

step

O

—

O

1

2

3

596

LC200_OM_OM60T03U_(U)

8-2. Customization

*

1

: If equipped

*

2

: This setting enables opening of the power back door when it is locked or

unlocked.

*

3

: This  function  is  available  only  when  a  customized  setting  that  enables

opening  of  the  power  back  door  when  it  is  either  locked  or  unlocked  is
selected. (See

*

2

 above.)

Opening/closing  of  the
power

back

door

*

1

using the

 switch

of  the  wireless  remote
control

Open: Press for

1 second

*

2

Close: Press for

1 second

Off

— —

O

Open: Press for

1 second with
the back door

unlocked

Close: Press for

1 second

Open: One short

press with the

back door

unlocked

Close: One short

press

Open: Press

twice with the

back door

unlocked

Close: Press

twice

Open: Press

twice

*

2

Close: Press

twice

Door unlocked when the
power  back  door

*

1

  is

opened

using

the

  switch  of  the

wireless  remote  con-
trol

*

3

All the doors

Back door

— —

O

Alarm (panic mode)

On

Off

— —

O

Function

Default setting

Customized

setting

1

2

3

LC200_OM_OM60T03U_(U)

597

8-2. Customization

8

Vehi

cl

e specificatio

ns

■

Smart key system (



P. 138) and wireless remote control

(



P. 114)

■

Door lock (



P. 118)

Function

Default setting

Customized

setting

Operation signal (Emer-
gency flashers)

On

Off

O

—

O

Time  elapsed  before
automatic  door  lock
function  is  activated  if
door is not opened after
being unlocked

60 seconds

Off

O

—

O

30 seconds

120 seconds

Operation signal
(Buzzers)

5

Off

O

—

O

1 to 7

Open

door

warning

function  (when  locking
the vehicle)

On

Off

— —

O

1

2

3

Function

Default setting

Customized

setting

Unlocking

using

a

mechanical key

Driver’s door

unlocked in one

step, all doors

unlocked in two

steps

All doors

unlocked in one

step

— —

O

Automatic door lock

Shifting the shift

lever to position

other than P

Off

O

—

O

Vehicle speed is

approximately

12 mph

(20 km/h) or

higher

Automatic door unlock

Shifting the shift

lever to P

Off

O

—

O

Driver’s door is

opened

1

2

3

598

LC200_OM_OM60T03U_(U)

8-2. Customization

■

Power back door

*

1

 (



P. 126)

*

1

: If equipped

*

2

: The operation start buzzer sounds.

■

Power windows (



P. 169)

*

: The settings of the moon roof are changed in conjunction with the settings

of the power windows.

Function

Default setting

Customized

setting

Power back door switch
operation

Push and hold

One short push

— —

O

Back

door

opener

switch  automatic  open
function

On

Off

— —

O

Operation signal

Off

*

2

On

— —

O

1

2

3

Function

Default setting

Customized

setting

Mechanical  key  linked
operation (close)

*

Off

On

— —

O

Mechanical  key  linked
operation (open)

*

Off

On

— —

O

Wireless  remote  control
linked operation (open)

*

Off

On

— —

O

Power  windows  open
warning buzzer

On

Off

— —

O

Buzzer  sounds  if  oper-
ated

using

wireless

remote control

On

Off

— —

O

1

2

3

LC200_OM_OM60T03U_(U)

599

8-2. Customization

8

Vehi

cl

e specificatio

ns

■

Moon roof (



P. 173)

*

: The settings of the power windows are changed in conjunction with the set-

tings of the moon roof.

Function

Default setting

Customized

setting

Mechanical  key  linked
operation (open)

*

Off

On

— —

O

Mechanical  key  linked
operation (close)

*

Off

On

— —

O

Linked

operation

of

components  when  door
key is used

Slide only

Tilt only

— —

O

Wireless  remote  control
linked operation (open)

*

Off

On

— —

O

Linked

operation

of

components when wire-
less

remote

control

used

Slide only

Tilt only

— —

O

Moon roof open warning
buzzer

On

Off

— —

O

1

2

3

600

LC200_OM_OM60T03U_(U)

8-2. Customization

■

Illumination (



P. 414)

Function

Default setting

Customized

setting

Interior  lights  illumina-
tion control

On

Off

— —

O

Time  period  before  the
interior lights turn off

15 seconds

Off

O

—

O

7.5 seconds

30 seconds

Operation

after

the

engine  switch  is  turned
off

On

Off

— —

O

Operation  when  the
doors are unlocked

On

Off

— —

O

Operation  when  you
approach  the  vehicle
with  the  electronic  key
on  your  person  (When
the  interior  light  switch
is door position)

On

Off

— —

O

Footwell lights

On

Off

— —

O

Door  trim  lights  and
footwell  lights  illumina-
tion control

On

Off

— —

O

Door trim lights

On

Off

— —

O

Sensitivity  of  the  ambi-
ent light sensor used for
dimming

the

meter

lights etc.

Standard

-2 to 2

— —

O

Sensitivity  of  the  ambi-
ent light sensor used for
brightening  the  meter
lights etc.

Standard

-2 to 2

— —

O

1

2

3

LC200_OM_OM60T03U_(U)

601

8-2. Customization

8

Vehi

cl

e specificatio

ns

■

Automatic light control system (



P. 226)

■

Intuitive parking assist (



P. 292)

■

Automatic air conditioning system (



P. 394)

Function

Default setting

Customized

setting

Light sensor sensitivity

Standard

-2 to 2

O

—

O

Daytime  running  light
system

On

Off

O

—

O

Time  elapsed  before
headlights

automati-

cally turn off after doors
are closed

30 seconds

Off

O

—

O

60 seconds

90 seconds

Welcome  lighting  illumi-
nation control

On

Off

— —

O

1

2

3

Function

Default setting

Customized

setting

Detection  distance  of
the rear center sensor

Far

Near

O

—

O

Alert  Volume  (alert  vol-
ume can be adjusted)

3

1 to 5

O

—

O

Display  setting  (when
intuitive parking assist is
operating)

All sensors dis-

played

Display off

O

—

O

1

2

3

Function

Default setting

Customized

setting

A/C  Auto  switch  opera-
tion

Auto

Manual

O

—

O

1

2

3

602

LC200_OM_OM60T03U_(U)

8-2. Customization

■

Outside rear view mirrors (



P. 165)

■

Front seat heaters and ventilators (



P. 411)

■

Driving position memory (



P. 154)

Function

Default setting

Customized

setting

Automatic

folding/

extending operation

Linked to lock-

ing/unlocking of

the doors

Off

— —

O

Linked to engine

switch operation

1

2

3

Function

Default setting

Customized

setting

Adjustment  of  the  front
seat  heater  tempera-
ture or the ventilator fan
speed  during  automatic
operation

(individual

seat  adjustment  avail-
able)

Level 3

(standard)

Level 1 (low) to

level 5 (high)

— —

O

1

2

3

Function

Default setting

Customized

setting

Selection  the  door  link-
ing

driving

position

memory

with

door

unlock operation

Driver’s door

All doors

— —

O

1

2

3

LC200_OM_OM60T03U_(U)

603

8-2. Customization

8

Vehi

cl

e specificatio

ns

■

Multi-information display (



P. 101)

*

1

: The default setting varies according to countries.

*

2

: Some status screens cannot be registered (indicated on the multi-informa-

tion display)

*

3

: 2 of the following items: current fuel consumption, average fuel economy

(after  reset),  average  fuel  economy  (after  refuel),  average  fuel  economy
(after  start),  average  vehicle  speed  (after  reset),  average  vehicle  speed
(after  start),  distance  (driving  range),  distance  (after  start),  elapsed  time
(after reset), elapsed time (after start), blank

Function

Default

setting

Customized

setting

Language

*

1

English

French

O

O

—

Spanish

Units

*

1

miles

(MPG US)

miles

(MPG Imperial)

O

O

—

km (L/100 km)

km (km/L)

Eco Driving Indicator Light

On

Off

—

O

–

 switch settings

Drive

information 1

Desired status

screen

*

2

—

O

—

Drive  information  screen
displayed  on  the  first

screen of



(Drive information 1)

Current fuel

consumption

*

3

—

O

—

Average fuel

economy

(after reset)

Drive  information  screen
displayed  on  the  second

screen of



(Drive information 2)

Distance

(range)

*

3

—

O

—

Average speed

(after reset)

Pop-up display

On

Off

—

O

—

Accent color

Color 1

Color 1 to

color 4

O

O

—

1

2

3

604

LC200_OM_OM60T03U_(U)

8-2. Customization

■

LDA (Lane Departure Alert)

*

 (



P. 267)

*

:

If equipped

■

BSM (Blind Spot Monitor)

*

 (



P. 363)

*

:

If equipped

Function

Default

setting

Customized

setting

Alert sensitivity

Standard

High

—

O

—

Vehicle sway warning

On

Off

—

O

—

Vehicle  sway  warning
sensitivity

Standard

Low

—

O

—

High

1

2

3

Function

Default

setting

Customized

setting

BSM (Blind Spot Monitor)

On

Off

—

O

—

RCTA  (Rear  Cross  Traffic
Alert function)

On

Off

—

O

—

Outside  rear  view  mirror
indicator brightness

Bright

Dim

—

—

O

Alert  timing  for  presence
of  approaching  vehicle
(BSM function only)

Intermediate

Early

—

—

O

Late

Only when in

blind spot

RCTA buzzer volume

Level 2

Level 1

—

—

O

Level 3

1

2

3

LC200_OM_OM60T03U_(U)

605

8-2. Customization

8

Vehi

cl

e specificatio

ns

■

Vehicle customization

●

If the smart key system is turned off, unlock door cannot be selected.

●

If the doors are not opened after unlocking and are then automatically re-
locked,  a  signal  will  be  given  if  Operation  signal  (Emergency  flashers)  or
Operation signal (Buzzer) are set to on.

■

When setting using the multi-information display

When using the multi-information display to set an item that can also be set
using the navigation system, the item displayed on the navigation system will
not change immediately.
If the engine switch is first turned off, the screen display will change once the
engine switch is turned to IGNITION ON mode again.

■

When customizing using the navigation system

Stop the vehicle in a safe place, apply the parking brake, and shift the shift
lever to P. Also, to prevent battery discharge, leave the engine running while
customizing the features.

WARNING

■

During customization

As  the  engine  needs  to  be  running  during  customization,  ensure  that  the
vehicle is parked in a place with adequate ventilation. In a closed area such
as a garage, exhaust gases including harmful carbon monoxide (CO) may
collect  and  enter  the  vehicle. This  may  lead  to  death  or  a  serious  health
hazard.

NOTICE

■

During customization

To prevent battery discharge, ensure that the engine is running while cus-
tomizing features.

606

LC200_OM_OM60T03U_(U)

8-3. Initialization

Items to initialize

*

: If equipped

The following item must be initialized for normal system opera-
tion after such cases as the battery being reconnected, or main-
tenance being performed on the vehicle:

Item

When to initialize

Reference

Message  indicating  mainte-
nance is required

After  the  maintenance  is  per-
formed

P. 460

Tire pressure warning sys-

tem

• When  rotating  the  tires  on

vehicles  differing  with  front

and  rear  tire  inflation  pres-

sures.

• When  changing  the  tire

inflation

pressure

by

changing  traveling  speed

or load weight, etc.

• When  changing  the  tire

size.

P. 483

Power back door

*

• After

reconnecting

or

changing  the  battery  with

power back door opened

• After  changing  a  fuse  with

power back door opened

P. 131

Multi-terrain Monitor

*

After  reconnecting  or  chang-
ing the battery

P. 313

Engine  oil  maintenance
data

*

After  the  maintenance  is  per-
formed

P. 471

607

LC200_OM_OM60T03U_(U)

9

For U.S. owners

Reporting safety defects

for U.S. owners........................ 608

608

LC200_OM_OM60T03U_(U)

Reporting safety defects for U.S. owners

If  you  believe  that  your  vehicle  has  a  defect  which  could  cause  a
crash or could cause injury or death, you should immediately inform
the National Highway Traffic Safety Administration (NHTSA) in addi-
tion  to  notifying Toyota  Motor  Sales,  U.S.A.,  Inc.  (Toll-free:  1-800-
331-4331).
If NHTSA receives similar complaints, it may open an investigation,
and if it finds that a safety defect exists in a group of vehicles, it may
order  a  recall  and  remedy  campaign.  However,  NHTSA  cannot
become involved  in individual problems between you,  your dealer,
or Toyota Motor Sales, U.S.A., Inc.
To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at
1-888-327-4236 (TTY: 1-800-424-9153); go to

http://www.safercar.gov

 ;

or write to: Administrator, NHTSA, 1200 New Jersey Ave. SE., Wash-
ington, DC 20590. You can also obtain other information about motor
vehicle safety from

http://www.safercar.gov

.

609

LC200_OM_OM60T03U_(U)

Index

What to do if...

(Troubleshooting) .................... 610

Alphabetical index ..................... 614

For  vehicles  with  a  navigation  system  or  a  multimedia
system, refer to the “NAVIGATION SYSTEM OWNER’S
MANUAL” for information regarding the equipment listed
below.
• Navigation system
• Audio/video system
• Rear seat entertainment system
• Hands-free system (for cellular phone)

610

What to do if... (Troubleshooting)

LC200_OM_OM60T03U_(U)

What to do if... (Troubleshooting)

●

If  you lose your mechanical  keys,  new  genuine mechanical  keys  can be
made by your Toyota dealer. (



P. 115)

●

If you lose your electronic keys, the risk of vehicle theft increases signifi-
cantly. Contact your Toyota dealer immediately. (



P. 117)

●

Is the electronic key battery weak or depleted? (



P. 499)

●

Is the engine switch in IGNITION ON mode?
When locking the doors, turn the engine switch off. (



P. 213)

●

Is the electronic key left inside the vehicle?
When  locking  the  doors,  make  sure  that  you  have  the  electronic  key  on
your person.

●

The  function  may  not  operate  properly  due  to  the  condition  of  the  radio
wave. (



P. 140)

●

Is the child-protector lock set?
The rear door cannot be opened from inside the vehicle when the lock is
set. Open the rear door from outside and then unlock the child-protector
lock. (



P. 121)

If  you  have  a  problem,  check  the  following  before  contacting
your Toyota dealer.

The doors cannot be locked, unlocked, opened or closed

You lose your keys

The doors cannot be locked or unlocked

The rear door cannot be opened

611

What to do if... (Troubleshooting)

LC200_OM_OM60T03U_(U)

●

Did you press the engine switch while firmly depressing the brake pedal?
(



P. 211)

●

Is the shift lever in P? (



P. 215)

●

Is the electronic key anywhere detectable inside the vehicle? (



P. 139)

●

Is the steering wheel unlocked? (



P. 215)

●

Is the electronic key battery weak or depleted?
In this case, the engine can be started in a temporary way. (



P. 561)

●

Is the battery discharged? (



P. 563)

●

Is the engine switch in IGNITION ON mode?
If you cannot release the shift lever by depressing the brake pedal with the
engine switch in IGNITION ON mode (



P. 222)

●

It is locked automatically to prevent theft of the vehicle. (



P. 215)

●

Is the window lock switch pressed?
The power window except for the one at the driver’s seat cannot be oper-
ated if the window lock switch is pressed. (



P. 169)

If you think something is wrong

The engine does not start

The shift lever cannot be shifted from P even if you depress
the brake pedal

The  steering  wheel  cannot  be  turned  after  the  engine  is
stopped

The windows do not open or close by operating the power
window switches

612

What to do if... (Troubleshooting)

LC200_OM_OM60T03U_(U)

●

The auto power off function will be operated if the vehicle is left in ACCES-
SORY or IGNITION ON mode (the engine is not running) for a period of
time. (



P. 214)

●

The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts?
(



P. 532)

●

The parking brake indicator is on
Is the parking brake released? (



P. 225)

Depending on the situation, other types of warning buzzer may also sound.
(



P. 530, 539)

●

Did anyone inside the vehicle open a door during setting the alarm?
The sensor detects it and the alarm sounds. (



P. 87)

To stop the alarm, turn the engine switch to IGNITION ON mode or start the
engine.

The engine switch is turned off automatically

A warning buzzer sounds during driving

An alarm is activated and the horn sounds

613

What to do if... (Troubleshooting)

LC200_OM_OM60T03U_(U)

●

Is the electronic key left inside the vehicle or the moon roof opened?
Check the message on the multi-information display. (



P. 539)

●

When a warning light turns on or a warning message is displayed, refer to
P. 530, 539.

●

Stop the vehicle in a safe place and replace the flat tire with the spare
tire. (



P. 544)

●

Try  the  procedure  for  when  the  vehicle  becomes  stuck  in  mud,  dirt,  or
snow. (



P. 569)

A warning buzzer sounds when leaving the vehicle

A warning light turns on or a warning message is displayed

When a problem has occurred

If you have a flat tire

The vehicle becomes stuck

632

LC200_OM_OM60T03U_(U)

GAS STATION INFORMATION

Fuel filler door

Auxiliary catch lever

P. 245

P. 468

Tire inflation

pressure

Fuel filler door opener

Hood lock release

lever

P. 578

P. 245

P. 468

Fuel tank capacity
(Reference)

24.5 gal. (93 L, 20.4 Imp.gal)

Fuel type

Unleaded gasoline only

P. 574

Cold tire inflation

pressure

P. 578

Engine oil capacity
(Drain and refill —
reference)

With filter
Without filter

8.5 qt. (8.0 L, 7.0 Imp.qt.)
7.9 qt. (7.5 L, 6.6 Imp.qt.)

Engine oil type

“Toyota Genuine Motor Oil” or equivalent

P. 574
