Toyota RAV4 (2018 year). Instruction - part 28

5-20. Bluetooth® Phone

459

Using the steering wheel switches

The steering wheel switches can be used to operate a connected

cellular phone.

Operating a telephone using the steering wheel switches

1

Volume switch

• Increase/Decrease the vol-

ume

• Press and hold:

Continuously

increase/

decrease the volume

2

Off hook switch

• Make a call

• Receive a call

• Display “Phone” screen

5

3

On hook switch

• End a call

• Refuse a call

RAV4_OM_OM0R012U_(U)

460

5-20. Bluetooth® Phone

Bluetooth® phone settings

You can adjust the hands-free system to your desired settings.

“Phone/Message Settings” screen

To display the screen shown below, press the “SETUP” button, and

select “Phone” on the “Setup” screen.

1

Set the phone connection

(→P. 436)

2

Setting the sound (→P. 461)

3

Contact/Call History Settings

(→P. 462)

4

Set the message settings

(→P. 470)

5

Set the phone display

(→P. 471)

RAV4_OM_OM0R012U_(U)

5-20. Bluetooth® Phone

461

Sound setting

1

Display the “Phone/Message Settings” screen. (→P. 460)

2

Select “Sound Settings” on the “Phone/Message Settings” screen.

1

Set the desired ringtone.

2

Adjust the ringtone volume.

3

Adjust the message readout

volume.

4

Set the desired incoming

SMS/MMS tone.

5

Adjust the incoming SMS/

MMS tone volume.

6

Set the incoming e-mail tone.

7

Adjust the incoming e-mail

tone volume.

8

Adjust the default volume of the other party’s voice.

5

■ To return to the default settings

Select “Default”, and then “Yes”.

RAV4_OM_OM0R012U_(U)

462

5-21. Phonebook

Contact/Call History Settings

The contact can be transferred from a Bluetooth® phone to the

system. The contact also can be added, edited and deleted.

The call history can be deleted and contact and favorites can be

changed.

“Contact/Call History Settings” screen

1

Display the “Phone/Message Settings” screen. (→P. 460)

2

Select “Contact/Call History Settings”.

3

Select the desired item to be set.

1

For

PBAP compatible

Bluetooth® phones, select

to set

“Automatic Transfer”

on/off. When set to on, the

phone’s contact data and

history are automatically

transferred.

Select to update contacts

2

from the connected phone.

(→P. 463)

3

Select to sort contacts by the

first name or last name field.

4

Select to add contacts to the favorites list. (→P. 467)

5

Select to delete contacts from the favorites list. (→P. 469)

6

Select to display contact images.

7

Select to clear contacts from the call history.*

8

Select to add new contacts to the contact list.* (→P. 465)

9

Select to edit contacts in the contact list.* (→P. 466)

10

Select to delete contacts from the contact list.* (→P. 467)

11

Select to reset all setup items.

*: For PBAP compatible Bluetooth® phones only, this function is available

when “Automatic Contact/History Transfer” is set to off.

RAV4_OM_OM0R012U_(U)

5-21. Phonebook

463

Update contacts from phone

Operation methods differ between PBAP compatible and PBAP

incompatible but OPP compatible Bluetooth® phones.

If your cellular phone is neither PBAP nor OPP compatible, the con-

tacts cannot be transferred.

■ For PBAP compatible Bluetooth® Phones

Select “Update Contacts from Phone”.

1

2

Check that a confirmation screen is displayed when the opera-

tion is complete.

This operation may be unnecessary depending on the type of cellular

phone.

Depending on the type of cellular phone, OBEX authentication may be

required when transferring contact data. Enter

“1234” into the

Bluetooth® phone.

If another Bluetooth® device is connected when transferring contact

data, depending on the phone, the connected Bluetooth® device may

need to be disconnected.

5

Depending on the type of Bluetooth® phone being connected, it may be

necessary to perform additional steps on the phone.

RAV4_OM_OM0R012U_(U)

5-21. Phonebook

465

Registering a new contact to the contact list

New contact data can be registered. Up to 4 numbers per person can

be registered. For PBAP compatible Bluetooth® phones, this function

is available when “Automatic Contact/History Transfer” is set to off.

(→P. 462)

1

Select “New Contact”.

2

Enter the name and select “OK”.

3

Enter the phone number and select “OK”.

4

Select the phone type for the phone number.

5

To add another number to this contact, select “Yes”.

■ Registering a new contact in a different way (From the “Call

History” screen)

1

Display the phone screen. (→P. 445)

2

Select the “Call History” tab and select a contact not yet regis-

tered in the contact list.

3

Select “Add to Contacts”.

5

4

Follow the steps in “Registering a new contact to the contacts

list” from

3

RAV4_OM_OM0R012U_(U)

466

5-21. Phonebook

Editing the contact data

For PBAP compatible Bluetooth® phones, this function is available

when “Automatic Contact/History Transfer” is set to off. (→P. 462)

1

Select “Edit Contact”.

2

Select the desired contact.

3

Select

corresponding to the desired name or number.

 For editing the name

4

Follow the steps in “Registering a new contact to the contacts list”

from

2

. (→P. 465)

 For editing the number

4

Follow the steps in “Registering a new contact to the contacts list”

from

3

. (→P. 465)

■ Editing the contacts in a different way (From the “Contact

Details” screen)

1

Display the phone screen. (→P. 445)

2

Select the “Contacts”, “Call History” tab or the “Favorites” tab and

select the desired contact.

3

Select “Edit Contact”.

“E-mail Addresses”: Select to display all registered e-mail addresses for

the contact.

Follow the steps in “Editing the contact data” from

4

4

RAV4_OM_OM0R012U_(U)

5-21. Phonebook

467

Deleting the contact data

For PBAP compatible Bluetooth® phones, this function is available

when “Automatic Contact/History Transfer” is set to off. (→P. 462)

1

Select “Delete Contacts”.

2

Select the desired contact and select “Delete”.

3

Select “Yes” when the confirmation screen appears.

■ Deleting the contact in a different way (From the “Contact

Details” screen)

1

Display the phone screen. (→P. 445)

2

Select the “Contacts”, “Call history” tab or the “Favorites” tab and

select the desired contact.

3

Select “Edit Contact”.

4

Select “Yes” when the confirmation screen appears.

Favorites list setting

Up to 15 contacts (maximum of 4 numbers per contact) can be regis-

5

tered in the favorites list.

■ Registering the contacts in the favorites list

1

Select “Add Favorite”.

2

Select the desired contact to add to the favorites list.

Dimmed contacts are already stored as a favorite.

3

Check that a confirmation screen is displayed when the opera-

tion is complete.

RAV4_OM_OM0R012U_(U)

468

5-21. Phonebook

 When 15 contacts have already been registered to the favorites

list

When 15 contacts have already been registered to the favorites

1

list, a registered contact needs to be replaced.

Select “Yes” when the confirmation screen appears to replace a

contact.

2

Select the contact to be replaced.

3

Check that a confirmation screen is displayed when the opera-

tion is complete.

 Registering contacts in the favorites list in a different way (from

the “Contacts” screen)

1

Display the phone screen. (→P. 445)

2

Select the “Contacts” tab.

3

Select

at the beginning of the desired contact list name to be

registered in the favorites list.

When selected,

is changed to

, and the contact is registered in

the favorites list.

 Registering contacts in the favorites list in a different way (from

the “Contact Details” screen)

1

Display the phone screen. (→P. 445)

2

Select the “Contacts” tab or the “Call History” tab and select the

desired contact.

3

Select “Add Favorite”.

4

Check that a confirmation screen is displayed when the opera-

tion is complete.

RAV4_OM_OM0R012U_(U)

5-21. Phonebook

469

■ Deleting the contacts in the favorites list

1

Select “Remove Favorite”.

2

Select the desired contacts and select “Remove”.

3

Select “Yes” when the confirmation screen appears.

4

Check that a confirmation screen is displayed when the opera-

tion is complete.

 Deleting contacts in the favorites list in a different way (from the

“Contacts” screen)

1

Display the phone screen. (→P. 445)

2

Select the “Contacts” tab.

3

Select

at the beginning of the contact list name to be deleted

from the favorites. list.

When selected,

is changed to

, and the data is deleted from the

list.

 Deleting contacts in the favorites list in a different way (from the

“Contact Details” screen)

5

1

Display the phone screen. (→P. 445)

2

Select the “Contacts”, “Call History” tab or the “Favorites” tab and

select the desired contact to delete.

3

Select “Remove Favorite”.

4

Select “Yes” when the confirmation screen appears.

5

Check that a confirmation screen is displayed when the opera-

tion is complete.

RAV4_OM_OM0R012U_(U)

470

5-21. Phonebook

Message Settings

1

Display the “Phone/Message Settings” screen. (→P. 460)

2

Select “Messaging Settings”.

3

Select the desired item to be set.

1

Set automatic message

transfer on/off.

2

Set automatic message

readout on/off.

3

Set the SMS/MMS notifica-

tion popup on/off.

4

Set the e-mail notification

popup on/off.

5

Set adding the vehicle signa-

ture to outgoing messages

on/off.

6

Set updating message read status on phone on/off.

7

Change the incoming SMS/MMS display.

“Full Screen”: When an SMS/MMS message is received, the incoming

SMS/MMS display screen is displayed and can be operated on the

screen.

“Drop-Down”: When an SMS/MMS message is received, a message is

displayed on the upper side of the screen.

Change the incoming e-mail display.

8

“Full Screen”: When an e-mail is received, the incoming e-mail display

screen is the displayed and can be operated on the screen.

“Drop-Down”: When an e-mail is received, a message is displayed on

the upper side of the screen.

Set display of messaging account names on the inbox tab on/off.

9

When set to on, messaging account names used on the cellular phone

will be displayed.

■ To return to the default settings

Select “Default”, and then “Yes”.

RAV4_OM_OM0R012U_(U)

5-21. Phonebook

471

■ Displaying the “Messaging Settings” screen in a different way

1

Display the phone screen. (→P. 445)

2

Select

3

Select “Settings”.

4

Select “Message Settings”.

Phone Display Settings

1

Display the “Phone/Message Settings” screen. (→P. 460)

2

Select “Phone Display Settings”.

3

Select the desired item to be set.

1

Change the incoming call

display.

“Full Screen”: When a call is

received, the hands-free screen

is displayed and can be oper-

ated on the screen.

“Drop-Down”: A message is dis-

5

played on the upper side of the

screen.

Set display of the contact/

2

history transfer completion

message on/off.

■ To return to the default settings

Select “Default”, and then “Yes”.

RAV4_OM_OM0R012U_(U)

472

5-22. Bluetooth®

What to do if... (Troubleshooting)

If there is a problem with the hands-free system or a Bluetooth®

device, first check the table below.

 When using the hands-free system with a Bluetooth® device

The hands-free system or Bluetooth® device does not work.

The connected device may not be a compatible Bluetooth® cellular phone.

→ For a list of specific devices which operation has been confirmed

on this system, check with your Toyota dealer or the following web-

site: http://www.toyota.com/entune/

The Bluetooth version of the connected cellular phone may be older than

the specified version.

→ Use a cellular phone with Bluetooth version 2.0 or higher (recom-

mended: Ver. 3.0 with EDR or higher). (→P. 476)

RAV4_OM_OM0R012U_(U)

5-22. Bluetooth®

473

 When registering/connecting a cellular phone

A cellular phone cannot be registered.

An incorrect passcode was entered on the cellular phone.

→ Enter the correct passcode on the cellular phone.

The registration operation has not been completed on the cellular phone

side.

→ Complete the registration operation on the cellular phone (approve

registration on the phone).

Old registration information remains on either this system or the cellular

phone.

→ Delete the existing registration information from both this system

and the cellular phone, then register the cellular phone you wish to

connect to this system. (→P. 437)

A Bluetooth® connection cannot be made.

Another Bluetooth® device is already connected.

→ Manually connect the cellular phone you wish to use to this sys-

tem. (→P. 439)

Bluetooth® function is not enabled on the cellular phone.

5

→ Enable the Bluetooth® function on the cellular phone.

Automatic Bluetooth® connection on this system is set to off.

→ Set automatic Bluetooth® connection on this system to on when

the engine switch is turned to the “ACC” or “ON” position (vehicles

without smart key system) or ACCESSORY or IGNITION ON mode

(vehicles with smart key system). (→P. 439)

“Please check your device settings.” message is displayed.

Bluetooth® function is not enabled on the cellular phone.

→ Enable the Bluetooth® function on the cellular phone.

Old registration information remains on either this system or the cellular

phone.

→ Delete the existing registration information from both this system

and the cellular phone, then register the cellular phone you wish to

connect to this system. (→P. 437)

 When making/receiving a call

A call cannot be made/received.

Your vehicle is in a “Out of cellular service area. Please try again later.”

area.

→ Move to where “Out of cellular service area. Please try again later.”

no longer appears on the display.

RAV4_OM_OM0R012U_(U)

474

5-22. Bluetooth®

 When using the contact list

Contact data cannot be transferred manually/automatically.

The profile version of the connected cellular phone may not be compatible

with transferring contact data.

→ For a list of specific devices which operation has been confirmed

on this system, check with your Toyota dealer or the following web-

site: http://www.toyota.com/entune/

Automatic contact transfer function on this system is set to off.

→ Set automatic contact transfer function on this system to on.

(→P. 462)

Passcode has not been entered on the cellular phone.

→ Enter the passcode on the cellular phone if requested (default pass-

code: 1234).

Transfer operation on the cellular phone has not completed.

→ Complete transfer operation on the cellular phone (approve trans-

fer operation on the phone).

Contact data cannot be edited.

Automatic contact transfer function on this system is set to on.

→ Set automatic contact transfer function on this system to off.

(→P. 462)

 When using the Bluetooth® message function

Messages cannot be viewed.

Message transfer is not enabled on the cellular phone.

→ Enable message transfer on the cellular phone (approve message

transfer on the phone).

Automatic transfer function on this system is set to off.

→ Set automatic transfer function on this system to on. (→P. 470)

New message notifications are not displayed.

Notification of SMS/MMS/E-mail reception on this system is set to off.

→ Set notification of SMS/MMS/E-mail reception on this system to on.

(→P. 470)

Automatic message transfer function is not enabled on the cellular phone.

→ Enable automatic transfer function on the cellular phone. (→P. 470)

RAV4_OM_OM0R012U_(U)

5-22. Bluetooth®

475

 In other situations

The Bluetooth® connection status is displayed at the top of the screen each

time the engine switch is turned to the “ACC” or “ON” position (vehicles

without smart key system) or ACCESSORY or IGNITION ON mode (vehi-

cles with smart key system).

Connection confirmation display on this system is set to on.

→ To turn off the display, set connection confirmation display on this

system to off. (→P. 441)

Even though all conceivable measures have been taken, the symptom sta-

tus does not change.

The cellular phone is not close enough to this system.

→ Bring the cellular phone closer to this system.

The cellular phone is the most likely cause of the symptom.

→ Turn the cellular phone off, remove and reinstall the battery pack,

and then restart the cellular phone.

→ Enable the cellular phone’s Bluetooth® connection.

→ Stop the cellular phone’s security software and close all applica-

tions.

→ Before using an application installed on the cellular phone, care-

5

fully check its source and how its operation might affect this sys-

tem.

RAV4_OM_OM0R012U_(U)

Content   ..  26  27  28  29   ..
