Toyota RAV4 (2018 year). Instruction - part 27

442

5-18. Connecting Bluetooth®

Editing the Bluetooth* PIN

You can change the PIN-code that is used to register your Bluetooth®

devices in the system.

1

Select “Bluetooth* PIN”.

2

Input a PIN-code, and select “OK”.

*: Bluetooth is a registered trademark of Bluetooth SIG, Inc.

RAV4_OM_OM0R012U_(U)

5-19. Bluetooth® Audio

443

Listening to Bluetooth® Audio

The Bluetooth® audio system enables the user to enjoy music

played on a portable player from the vehicle speakers via wire-

less communication.

When a Bluetooth® device cannot be connected, check the connec-

tion status on the “Bluetooth* Audio” screen. If the device is not con-

nected, either register or reconnect the device. (→P. 438)

*: Bluetooth is a registered trademark of Bluetooth SIG, Inc.

Status display

You can check such indicators as signal strength and battery charge

on the screen.

1

Connection status

2

Battery charge

The battery charge indicator may

5

not be displayed depending on the

connected device.

Indicators

Conditions

Good

Not connected

Connection status

Full

Empty

Battery charge

RAV4_OM_OM0R012U_(U)

444

5-19. Bluetooth® Audio

Playing Bluetooth® audio

Select

or

to Play/Pause.

For details on “Bluetooth* Audio” screen operation methods, refer to

Basic Audio Operations. (→P. 398)

For details on how to select a track or album, refer to selecting, fast-

forwarding and reversing tracks/files/songs. (→P. 409)

*: Bluetooth is a registered trademark of Bluetooth SIG, Inc.

RAV4_OM_OM0R012U_(U)

5-20. Bluetooth® Phone

445

Using a Bluetooth® Phone

The hands-free system is a function that allows you to use your

cellular phone without touching it.

This system supports Bluetooth®. Bluetooth® is a wireless data

system that allows the cellular phone to wirelessly connect to

the hands-free system and make/receive calls.

Before making a phone call, check the connection status, battery

charge, call area and signal strength. (→P. 446)

If a Bluetooth® device cannot be connected, check the connection

status on the phone screen. If the device is not connected, either

register or reconnect it. (→P. 438)

Phone screen

To display the screen shown below, press the

switch on the steer-

ing wheel or the

button.

5

Several functions are available to operate on each screen that is dis-

played by selecting the 4 tabs.

1

Device name

2

Bluetooth® connection status

RAV4_OM_OM0R012U_(U)

446

5-20. Bluetooth® Phone

■ Telephone switch (→P. 459)

■ Microphone

The vehicle’s built in micro-

phone is used when talking on

the phone.

The person you are speaking to

can be heard from the front

speakers.

To use the hands-free system,

you must register your

Bluetooth® phone in the sys-

tem. (→P. 436)

Status display

You can check indicators such as signal strength and battery charge

on the phone screen.

1

Connection status

2

Signal strength

3

Battery charge

Indicators

Conditions

Good

Poor

Not connected

Connection status

Full

Empty

Battery charge

Call area

“Rm”: Roaming area

Excellent

Poor

Signal strength

RAV4_OM_OM0R012U_(U)

5-20. Bluetooth® Phone

447

Making a call

Once a Bluetooth® phone is registered, you can make a call

using the following procedure:

Dialing

1

Display the phone screen. (→P. 445)

2

Select the “Dial Pad” tab and enter a phone number.

To delete the input phone number, select

For the first digit, you can enter “+” by selecting “∗” for a while.

3

Press the

switch on the steering wheel or select

Dialing from the contacts list

You can dial a number from the contact data imported from your cellu-

lar phone. The system has one contact list for each registered phone.

Up to 2500 contacts may be stored in each contact list.

5

1

Display the phone screen. (→P. 445)

2

Select “Contacts” tab.

3

Choose the desired contact to call from the list.

4

Choose the number and then press the

switch on the steering

wheel or select

When the contact is empty

You can transfer the phone numbers in a Bluetooth® phone to the sys-

tem.

Operation methods differ between PBAP (Phone Book Access Profile)

compatible and PBAP incompatible Bluetooth® phones. If the cellular

phone does not support either PBAP or OPP (Object Push Profile)

service, you cannot transfer contacts.

RAV4_OM_OM0R012U_(U)

448

5-20. Bluetooth® Phone

■ For PBAP compatible Bluetooth® phones

 When “Automatic Contact/History Transfer” is set to off

1

Select the desired item.

1

Select to transfer new con-

tacts from a cellular phone,

select

“Always” and then

enable

“Automatic Con-

tact/History Transfer”.

Select to transfer all the

2

contacts from a connected

cellular phone only once.

3

Select to cancel transferring.

■ For PBAP incompatible but OPP compatible Bluetooth®

phones

1

Select the desired item.

1

Select to transfer the con-

tacts from the connected

cellular phone.

2

Select to add a new con-

tact manually.

3

Select to cancel transfer-

ring.

 When “Transfer” is selected

2

Follow the steps in “Update contacts from phone” from

2

(→P. 463)

 When “Add” is selected

2

Follow the steps in “Registering a new contact to the contacts

list” from

2

. (→P. 465)

RAV4_OM_OM0R012U_(U)

5-20. Bluetooth® Phone

449

Calling using favorites list

You can make a call using numbers registered in the contact.

1

Display the phone screen. (→P. 445)

2

Select “Favorites” tab.

3

Select the desired number to make a call.

Dialing from call history

You can make a call using the call history, which has the 3 functions

below.

: calls which you missed

: calls which you received

: calls which you made

1

Display the phone screen. (→P. 445)

2

Select “Call History” tab.

3

Select

or the desired entry from the list.

5

 When is selected

4

Check that the “Call” screen is displayed.

 When the desired contact is selected

4

Select the desired number.

5

Check that the “Call” screen is displayed.

■ Call history list

● If you make a call to or receive a call from a number registered in the contact

list, the name is displayed in the call history.

● If you make multiple calls to the same number, only the last call made is dis-

played in the call history.

■International calls

You may not be able to make international calls, depending on the mobile

phone in use.

RAV4_OM_OM0R012U_(U)

450

5-20. Bluetooth® Phone

Receiving a call

When a call is received, the following screen is displayed

together with a sound.

To answer the phone

Press the

switch on the steer-

ing wheel or select

To refuse a call

Press the

switch on the steering wheel or select

To adjust the incoming call volume

Turn the “PWR VOL” knob. You can also adjust the volume using the

steering switches.

■International calls

Received international calls may not be displayed correctly depending on the

cellular phone in use.

RAV4_OM_OM0R012U_(U)

5-20. Bluetooth® Phone

451

Speaking on the phone

The following screen is displayed when speaking on the phone.

To adjust the call volume

Select “-” or “+”. You can also adjust the volume using the steering

switches or the volume knob.

To prevent the other party from hearing your voice

5

Select “Mute”.

Inputting tones

When using phone services such as an answering service or a bank,

you can store phone numbers and code numbers in the contact list.

1

Select “0-9”.

2

Input the number.

■ Release Tones

“Release Tones” appear when a continuous tone signal(s) contain-

ing a (w) is registered in the contact list.

Select “Release Tones”.

RAV4_OM_OM0R012U_(U)

452

5-20. Bluetooth® Phone

■ Release Tones

● A continuous tone signal is a character string that consists of numbers and

the characters p or w. (e.g.056133w0123p#1∗)

● When the “p” pause tone is used, the tone data up until the next pause tone

will be automatically sent after 2 seconds have elapsed. When the “w”

pause tone is used, the tone data up until the next pause tone will be auto-

matically sent after a user operation is performed.

● Release tones can be used when automated operation of a phone based

service such as an answering machine or bank phone service is desired. A

phone number with continuous tone signals can be registered in the contact

list.

● Tone data after a “w” pause tone can be operated on voice command during

a call.

To transfer a call

Turn the “Handset mode” on to switch from a hands-free call to a cel-

lular phone call.

Turn the “Handset mode” off to switch from a cellular phone call to a

hands-free call.

Transmit volume setting

1

Select “Transmit Volume”.

2

Select the desired level for the transmit volume.

3

Select “OK”.

To hang up

Press the

switch on the steering wheel or select

RAV4_OM_OM0R012U_(U)

5-20. Bluetooth® Phone

453

Call waiting

When a call is interrupted by a third party while talking, an incoming

call message will be displayed.

To talk with the other party:

• Press the

switch on the

steering wheel.

• Select

To refuse the call:

• Press the

switch on the

steering wheel.

• Select

Every time you press the

switch on the steering wheel or select

during call waiting, you will be switched to the other party.

■ Transferring calls

● If you transfer from the cellular phone to hands-free, the hands-free screen

will be displayed, and you can operate the system using the screen.

5

● Transfer method and operation may vary according to the cellular phone

used.

● For operation of the cellular phone in use, see the phone’s manual.

■ Call waiting operation

Call waiting operation may differ depending on your phone company and cel-

lular phone.

RAV4_OM_OM0R012U_(U)

454

5-20. Bluetooth® Phone

Bluetooth® phone message function

Received messages can be forwarded from the connected

Bluetooth® phone, enabling checking and replying using the

audio system.

Depending on the type of Bluetooth® phone connected, received

messages may not be transferred to the message inbox.

If the phone does not support the message function, this func-

tion cannot be used.

Displaying “Message Inbox” screen

1

Press the

button.

2

Select

Receiving a message

When an e-mail/SMS/MMS is received, the incoming message screen

pops up with sound and is ready to be operated on the screen.

1

Select to check the message.

2

Select to refuse the message.

3

Select to call the message

sender.

RAV4_OM_OM0R012U_(U)

456

5-20. Bluetooth® Phone

Checking the messages

1

Display the “Message Inbox” screen. (→P. 454)

2

Select the desired message from the list.

3

Check that the message is displayed.

1

E-mails:

Select

“Mark

Unread” or “Mark Read” to

mark mail unread or read on

the message inbox screen.

This function is available when

“Update Message Read Status

on Phone” is set to on (→P. 470)

2

Select to make a call to the

sender.

3

Select to have messages read out. To cancel this function, select

“Stop”.

4

Select to display the previous or next message.

5

Select to reply the message.

RAV4_OM_OM0R012U_(U)

5-20. Bluetooth® Phone

457

■ Check the messages

● Depending on the type of Bluetooth® phone being connected, it may be nec-

essary to perform additional steps on the phone.

● Messages are displayed in the appropriate connected Bluetooth® phone’s

registered mail address folder.

Select the tab of the desired folder to be displayed.

● Only received messages on the connected Bluetooth® phone can be dis-

played.

● The text of the message is not displayed while driving.

● When “Automatic Message Readout” is set to on, messages will be auto-

matically read out. (→P. 470)

● Turn the “PWR VOL” knob, or use the volume switch on the steering wheel

to adjust the message read out volume.

● The message read out function is available even while driving.

Replying to a message

1

Display the “Message Inbox” screen. (→P. 454)

2

Select the desired message from the list.

5

3

Select “Quick Message”.

4

Select the desired message.

5

Select “Send”.

If an error message is displayed, follow the guidance on the screen to try

again.

■ Editing quick reply message

1

Select “Quick Message”.

2

Select

corresponding to the desired message to edit.

3

Select “OK” when editing is completed.

RAV4_OM_OM0R012U_(U)

458

5-20. Bluetooth® Phone

Calling the message sender

Calls can be made to an e-mail/SMS/MMS message sender’s phone

number.

1

Display the “Message Inbox” screen. (→P. 454)

2

Select the desired message.

3

Select

4

Check that the “Call” screen is displayed.

■ Calling from a number within a message

Calls can be made to a number identified in a message’s text area.

This operation cannot be performed while driving.

1

Display the “Message Inbox” screen. (→P. 454)

2

Select the desired message.

3

Select the text area.

4

Select

corresponding to the desired number.

5

Check that the “Call” screen is displayed.

■ Calling from the incoming message screen

→P. 453

RAV4_OM_OM0R012U_(U)

Content   ..  25  26  27  28   ..
