Toyota RAV4 (2018 year). Instruction - part 25

408

5-14. Using the audio system

List screen operation

When a list screen is displayed, use the appropriate buttons to

scroll through the list.

How to scroll

: Select to scroll to the next

or previous page.

: If

appears to the right of

titles, the complete titles are

too long for the display. Select

this button to scroll the title.

Turn the “TUNE•SCROLL” knob to move the cursor box to select a

desired item from the list, and press the knob to play it. The track that

is being played is highlighted.

To return to the top screen, select “Now Playing” on the list screen.

RAV4_OM_OM0R012U_(U)

5-14. Using the audio system

409

Selecting, fast-forwarding and reversing tracks/files/songs

■ Selecting a track/file/song

Press the “SEEK >” button or “< TRACK” button, or turn the

“TUNE•SCROLL” knob to select the desired track/file/song number.

To fast-forward or reverse, press and hold the “SEEK >” button or

“< TRACK” button.

■ Selecting a track/file/song from the track/file/song list

1

Select “Browse” or cover art.

2

Select the desired track/file/

song.

5

When an MP3/WMA/AAC disc or USB memory device is being used,

the folder can be selected. When a Bluetooth® device or iPod is being

used, the album can be selected.

According to the audio device, the following is displayed.

Audio source

List name

Audio CD

Track

MP3/WMA/AAC disc

Folder, File

Bluetooth®

Album, Track

Artist, Album, Song, Genre, Com-

USB

poser

Playlist, Artist, Album,

Genre,

iPod

Audiobook, Composer, Song, Video,

Podcast

RAV4_OM_OM0R012U_(U)

410

5-14. Using the audio system

Optimal use of the audio system

On the “Sound Settings” screen, sound quality (Treble/Mid/

Bass), volume balance can be adjusted.

How to adjust the sound settings and sound quality

1

2

3

Select “-” or “+” to adjust

the treble, mid or bass to

a level between -5 and 5.

4

5

Select

“Front” or

“Rear” to

adjust the front/rear audio

balance.

6

7

Select “L” or “R” to adjust the

left/right audio balance.

RAV4_OM_OM0R012U_(U)

5-15. Using the radio

411

Radio operation

Select “AM” or “FM” on the audio source selection screen to

begin listening to the radio.

Audio control screen

Pressing the “AUDIO” button displays the audio control screen from

any screens of the selected source.

1

Audio source selection screen

appears

2

Preset stations

3

Select to display RBDS text

messages*

4

Scanning for receivable station

5

Select to display a list of receiv-

able stations

5

6

Setting the sound (→P. 410)

*: FM only

Selecting a station

Tune in to the desired station using one of the following methods.

■ Seek tuning

Press the “SEEK >” button or “< TRACK” button.

The radio will begin seeking up or down for a station of the nearest

frequency and will stop when a station is found.

■ Manual tuning

Turn the “TUNE•SCROLL” knob.

■ Preset stations

Select the desired preset station.

RAV4_OM_OM0R012U_(U)

412

5-15. Using the radio

Setting station presets

1

Search for desired stations by turning the “TUNE•SCROLL” knob or

pressing the “SEEK >” button or “< TRACK” button.

2

Select “(add new)”.

To change the preset station to a different one, select and hold the preset

station.

3

Select “Yes”.

4

Select “OK” after setting the new preset station.

■ Refreshing the station list

Select “Refresh” on the “Station List” screen.

1

To cancel the refresh, select “Cancel Refresh”.

■ Reception sensitivity

● Maintaining perfect radio reception at all times is difficult due to the continu-

ally changing position of the antenna, differences in signal strength and sur-

rounding objects, such as trains, transmitters, etc.

● The radio antenna is mounted on the roof.

RAV4_OM_OM0R012U_(U)

5-16. Playing an audio CD and MP3/WMA/AAC discs

413

CD player operation

Insert disc or select “CD” on the audio source selection screen

with a disc inserted to begin listening to a CD.

Audio control screen

Pressing the “AUDIO” button displays the audio control screen from

any screens of the selected source.

1

Audio source selection screen

appears

2

Displaying the track/file list/

folder list

3

Random playback (→P. 399)

4

Repeat play (→P. 399)

5

Pause

Select

to resume play

5

6

Setting the sound (→P. 410)

■ Displaying the title and artist name

If a CD-TEXT disc is inserted, the title of the disc and track will be displayed.

RAV4_OM_OM0R012U_(U)

414

5-16. Playing an audio CD and MP3/WMA/AAC discs

CD player and disc information

Error messages

If the following error messages appear on the screen, refer to the

table and take the appropriate measures. If the problem is not recti-

fied, take the vehicle to your Toyota dealer.

Message

Cause/Correction procedures

• The disc is dirty or damaged. Clean the disc.

• The disc is inserted upside down. Insert the

“Check DISC”

disc correctly.

• The disc is not playable with the player. Con-

firm the disc is playable with the player.

There is a malfunction within the system. Eject

“Disc Error”

the disc.

No playable data is included on the disc. Eject

“No music files found.”

the disc.

CD discs

■ Discs that can be used

Discs with the marks shown below can be used.

Playback may not be possible depending on recording format or

disc features, or due to scratches, dirt or deterioration.

CDs with copy-protection features may not play correctly.

■ CD player protection feature

To protect the internal components, playback is automatically

stopped when a problem is detected.

■ If a disc is left inside the CD player or in the ejected position

for extended periods

Disc may be damaged and may not play properly.

■ Lens cleaners

Do not use lens cleaners. Doing so may damage the CD player.

RAV4_OM_OM0R012U_(U)

5-16. Playing an audio CD and MP3/WMA/AAC discs

419

NOTICE

■ Discs and adapters that cannot be used

Do not use the following types of CDs.

Also, do not use 3 in. (8 cm) CD adapters, DualDiscs or printable discs.

Doing so may damage the CD player and/or the CD insert/eject function.

5

● Discs that have a diameter that is not 4.7 in. (12 cm).

● Low-quality or deformed discs.

● Discs with a transparent or translucent recording area.

● Discs that have tape, stickers or CD-R labels attached to them, or that

have had the label peeled off.

■ Player precautions

Failure to follow the precautions below may result in damage to the discs or

the player itself.

● Do not insert anything other than discs into the disc slot.

● Do not apply oil to the player.

● Store discs away from direct sunlight.

● Never try to disassemble any part of the player.

RAV4_OM_OM0R012U_(U)

420

5-17. Using an external device

iPod player operation

Connecting an iPod enables you to enjoy music from the vehicle

speakers.

Select “iPod” on the audio source selection screen.

When the iPod connected to the system includes iPod video, the

system can only output the sound by selecting the browse

screen.

Connecting an iPod

→P. 397

Audio control screen

Pressing the “AUDIO” button displays the audio control screen from

any screens of the selected source.

1

Audio source selection screen

appears

2

Displays cover art

3

Selecting the play mode

(→P. 421)

4

Shuffle play (→P. 421)

5

Repeat play (→P. 421)

6

Pause

Select

to resume playback

7

Setting the sound (→P. 410)

RAV4_OM_OM0R012U_(U)

5-17. Using an external device

421

Selecting a play mode

1

Select “Browse” on the screen.

2

Select the desired play mode by selecting the “Playlists”, “Artists”,

“Albums”, “Songs”, “Podcasts”, “Audio books”, “Genres”, “Compos-

ers” or “Videos” tab. Then select a song to begin using the selected

play mode.

Shuffle play

Select

to change on/off.

Repeat play

Select

to change on/off.

5

RAV4_OM_OM0R012U_(U)

422

5-17. Using an external device

■About iPod

● “Made for iPod” and “Made for iPhone” mean that an electronic accessory

has been designed to connect specifically to iPod or iPhone, respectively,

and has been certified by the developer to meet Apple performance stan-

dards.

● Apple is not responsible for the operation of this device or its compliance

with safety and regulatory standards. Please note that the use of this acces-

sory with iPod or iPhone may affect wireless performance.

● iPhone, iPod, iPod classic, iPod nano, and iPod touch are trademarks of

Apple Inc., registered in the U.S. and other countries. Lightning is a trade-

mark of Apple Inc.

■iPod cover art

● Depending on the iPod and songs in the iPod, iPod cover art may be dis-

played.

● This function can be changed to on/off. (→P. 403)

● It may take time to display iPod cover art, and the iPod may not be operated

while the cover art display is in process.

● Only iPod cover art that is saved in JPEG format can be displayed.

■iPod functions

● When an iPod is connected and the audio source is changed to iPod mode,

the iPod will resume play from the same point in which it was last used.

● Depending on the iPod that is connected to the system, certain functions

may not be available. If a function is unavailable due to a malfunction (as

opposed to a system specification), disconnecting the device and recon-

necting it may resolve the problem.

● While connected to the system, the iPod cannot be operated with its own

controls. It is necessary to use the controls of the vehicle’s audio system

instead.

● When the battery level of an iPod is very low, the iPod may not operate. If

so, charge the iPod before use.

● Compatible models (→P. 424)

RAV4_OM_OM0R012U_(U)

5-17. Using an external device

423

■ iPod problems

To resolve most problems encountered when using your iPod, disconnect

your iPod from the vehicle iPod connection and reset it. For instructions on

how to reset your iPod, refer to your iPod Owner’s Manual.

■Error messages

If the following error messages appear on the screen, refer to the table and

take the appropriate measures. If the problem is not rectified, take the vehicle

to your Toyota dealer.

Message

Cause/Correction procedures

“Connection error. Please

consult your Owner’s Man-

This indicates a problem in the iPod or its con-

ual for instructions on how

nection.

to connect the iPod.”

This indicates that there is no music data in

“No music files found.”

the iPod.

This indicates that no video files are included

“No videos found.”

in the iPod.

This indicates that the software version is not

“Please check the iPod

compatible.

5

firmware version.”

Please check the compatible models.

(→P. 424)

This indicates that the audio system failed to

“iPod authorization unsuc-

authorize the iPod.

cessful.”

Please check your iPod.

RAV4_OM_OM0R012U_(U)

424

5-17. Using an external device

■ Compatible models

The following iPod®, iPod nano®, iPod classic®, iPod touch® and iPhone®

devices can be used with this system.

● Made for

• iPod touch (5th generation)

• iPod touch (4th generation)

• iPod touch (3rd generation)

• iPod touch (2nd generation)

• iPod touch (1st generation)

• iPod classic

• iPod with video

• iPod nano (7th generation)

• iPod nano (6th generation)

• iPod nano (5th generation)

• iPod nano (4th generation)

• iPod nano (3rd generation)

• iPod nano (2nd generation)

• iPod nano (1st generation)

• iPhone 5s

• iPhone 5c

• iPhone 5

• iPhone 4S

• iPhone 4

• iPhone 3GS

• iPhone 3G

• iPhone

This system only supports audio playback.

Depending on differences between models or software versions etc., some

models might be incompatible with this system.

WARNING

■While driving

Do not connect an iPod or operate the controls.

NOTICE

■ To prevent damage to the iPod or its terminals

● Do not leave the iPod in the vehicle. The temperature inside the vehicle

may become high.

● Do not push down on or apply unnecessary pressure to the iPod while it is

connected.

● Do not insert foreign objects into the port.

RAV4_OM_OM0R012U_(U)

Content   ..  23  24  25  26   ..
