Toyota Verso (2017 year). Instruction - part 15
2-2. Instrument cluster
■ Setting the clock
Select “CLOCK” on the menu screen.
Press the “DISP” switch to adjust
the hours.
After setting the hours, wait for 5
seconds until the bar disappears,
and confirm that the hour has
been input.
Press the “DISP” switch to adjust
the minutes.
After setting the minutes, wait for
5 seconds until the bar disap-
pears, and confirm that the min-
utes has been input.
■ Setting the clock format
Select “CLOCK FORMAT” on the menu screen.
Select the desired clock format.
Press and hold the “DISP” switch
to input the choice.
238
VERSO_EE_OM64517E
2-2. Instrument cluster
■ Setting the date
Select “DATE” on the menu screen.
Press the “DISP” switch to adjust
the year.
After setting the year, wait for 5
seconds until the bar disappears,
and confirm that the year has
been input.
2
Press the “DISP” switch to adjust
the month.
After setting the month, wait for 5
seconds until the bar disappears,
and confirm that the month has
been input.
Press the “DISP” switch to adjust
the day.
After setting the day, wait for 5
seconds until the bar disappears,
and confirm that the day has
been input.
239
VERSO_EE_OM64517E
2-2. Instrument cluster
■ Setting the date format
Select “DATE FORMAT” on the menu screen.
Select the desired date format.
Press and hold the “DISP” switch
to input the choice.
■ Selecting the language
Select “LANGUAGE” on the menu screen.
Select the desired language.
Press and hold the “DISP” switch
to input the choice.
■ Setting Eco Driving Indicator Light
Select “ECO INDICATOR” on the menu screen.
Select “OFF” from the displayed
items.
Then keep the switch pressed for
a while.
Eco Driving Indicator Light is
deactivated.
(To activate Eco Driving Indicator
Light, select “ON”.)
240
VERSO_EE_OM64517E
2-2. Instrument cluster
■ Selecting the units
Select “UNITS” on the menu screen.
Select the desired unit.
Press and hold the “DISP” switch
to input the choice.
2
■ Returning the previous screen
Select “BACK” on the screen.
Press and hold the “DISP” switch to input the choice.
241
VERSO_EE_OM64517E
2-2. Instrument cluster
■ Eco Driving Indicator Zone Display (if equipped)
Eco Driving Indicator indicates the range
where acceleration is Eco-friendly, “Zone
of Eco driving” and Eco driving ratio
based on acceleration.
Eco Driving Indicator Light
Eco Driving Indicator Zone Display
Zone of Eco driving
Eco driving ratio based on accel-
eration
When the acceleration exceeds the Zone of Eco driving, the system recog-
nizes that the vehicle is not being driven in Eco-friendly manner. Eco Driv-
ing Indicator Light turns off and the right side of Eco Driving Indicator Zone
Display blinks.
Also, the system will not be operated if the following conditions are met
while driving:
●The shift position is anything other than “D”
●The driving mode is set to “SPORT” mode
●The paddle shift switch is operated while the shift lever is in “D”
●The vehicle speed is approximately 130 km/h (80 mph) or higher
■ Outside temperature display
● In the following situations, the correct outside temperature may not be
displayed, or the display may take longer than normal to change.
• When stopped, or driving at low speeds (less than 20 km/h [12 mph])
• When the outside temperature has changed suddenly (at the entrance/
exit of a garage, tunnel, etc.)
● When “--” is displayed, the system may be malfunctioning.
Take your vehicle to any authorized Toyota dealer or repairer, or another
duly qualified and equipped professional.
242
VERSO_EE_OM64517E
2-2. Instrument cluster
■ Liquid crystal display
Small spots or light spots may appear on the display. This phenomenon is
characteristic of liquid crystal displays, and there is no problem to continue
using the display.
NOTICE
■ The multi-information display at low temperatures
Allow the interior of the vehicle to warm up before using the liquid crystal
2
information display. At extremely low temperatures, the information display
monitor may respond slowly, and display changes may be delayed.
243
VERSO_EE_OM64517E
2-2. Instrument cluster
Fuel consumption information
Fuel consumption information can be displayed on the navigation/
multimedia system.
Navigation/multimedia system
Trip information (navigation/multimedia system)
Press the
button on the navi-
gation/multimedia system.
: If equipped
244
VERSO_EE_OM64517E
2-2. Instrument cluster
Select “Trip information”.
Average vehicle speed since
the engine was started.
Cruising range (P. 247)
Fuel consumption in the past
15 minutes
Elapsed time since the engine
was started.
2
Resetting the consumption
data
Vehicles without smart entry & start system:
Average fuel consumption for the past 15 minutes is divided by
color into past averages and averages attained since the engine
switch was last turned to the “ON” position. Use the displayed
average fuel consumption as a reference.
Vehicles with smart entry & start system:
Average fuel consumption for the past 15 minutes is divided by
color into past averages and averages attained since the “ENGINE
START STOP” switch was last turned to IGNITION ON mode. Use
the displayed average fuel consumption as a reference.
These images are examples only, and may vary slightly from actual con-
ditions.
245
VERSO_EE_OM64517E
2-2. Instrument cluster
Past record (navigation/multimedia system)
Press the
button on the navi-
gation/multimedia system.
Select “Past record”.
Best recorded fuel consump-
tion
Previous fuel consumption
record
Average fuel consumption
Updating the average fuel
consumption data
Resetting the past record data
The average fuel consumption history is divided by color into past
averages and the average fuel consumption since the last
updated. Use the displayed average fuel consumption as a refer-
ence.
These images are examples only, and may vary slightly from actual con-
ditions.
246
VERSO_EE_OM64517E
2-2. Instrument cluster
■ Updating the past record data
Update the average fuel consumption by selecting “Update” to measure the
current fuel consumption again.
■ Resetting the data
The fuel consumption data can be deleted by selecting “Clear”.
■ Cruising range
Displays the estimated maximum distance that can be driven with the quan-
tity of fuel remaining.
2
This distance is computed based on your average fuel consumption.
As a result, the actual distance that can be driven may differ from that dis-
played.
247
VERSO_EE_OM64517E
2-3. Operating the lights and wipers
Headlight switch
The headlights can be operated manually or automatically.
The front position, tail,
license plate and
instrument panel lights
turn on.
The headlights and all
lights listed above turn
on.
Vehicles without smart
(if equipped)
entry & start system:
The headlights, front
position lights and so
on turn on and off
automatically
(when
the engine switch is in
the “ON” position.)
Vehicles with smart
entry & start system:
The headlights, front
position lights and so
on turn on and off
automatically
(when
the
“ENGINE START
STOP” switch is in
IGNITION ON mode.)
248
VERSO_EE_OM64517E
2-3. Operating the lights and wipers
Turning on the high beam headlights
With the headlights on, push
the lever forward to turn on the
high beams.
Pull the lever back to the center
position to turn the high beams
off.
2
Pull the lever toward you to
turn on the high beams.
Release the lever to turn them off.
You can flash the high beams
with the headlights on or off.
Manual headlight leveling dial (vehicles with halogen headlights)
The level of the headlights can be adjusted according to the number
of passengers and the loading condition of the vehicle.
Raises the level of the head-
lights
Lowers the level of the head-
lights
249
VERSO_EE_OM64517E
2-3. Operating the lights and wipers
■ Guide to dial settings
Vehicle category M1*
Control switch position
Loading condition
5 SEATER
7 SEATER
Driver only
0
0
Driver + one passenger in the front seat
0
0
Driver + one passenger in the front
seat.
1
1
And all passengers in the rear seats
farthest to the rear.
All passengers
1
2
All passengers + full luggage loading to
3
3
the luggage room.
Driver + full luggage loading to the lug-
4
4
gage room
Vehicle category N1*
Loading condition
Control switch position
Driver only
0
Driver + full luggage loading to the lug-
3
gage room
*: To distinguish the vehicle category, ask any authorized Toyota dealer or
repairer, or another duly qualified and equipped professional.
250
VERSO_EE_OM64517E
2-3. Operating the lights and wipers
Daytime running light system
To make your vehicle more visible to other drivers, the daytime run-
ning lights turn on automatically whenever the engine is started.
(However, the daytime running light system will be canceled when
the headlight switch is operated manually or the automatic headlight
system turns on the tail lights.) Daytime running lights are not
designed for use at night.
2
■ Headlight control sensor (if equipped)
The sensor may not function properly if
anything that blocks the sensor is affixed
to the windshield.
Doing so interferes with the sensor
detecting the level of ambient light and
may cause the automatic headlight sys-
tem to malfunction.
■ Automatic High Beam (if
equipped)
P. 288
251
VERSO_EE_OM64517E
2-3. Operating the lights and wipers
■ Automatic light off system
Vehicles without smart entry & start system
●When the light switch is in the
position, the headlight and all the
lights turn off automatically if the engine switch is turned to the “ACC”
or “LOCK” position.
●When the light switch is in the
or
position, the headlights
and front fog lights turn off automatically if the engine switch is turned
to the “ACC” or “LOCK” position.
To turn the lights on again, turn the engine switch to the “ON” position, or
turn the light switch off once and then back to the
or
position.
Vehicles with smart entry & start system
●When the light switch is in the
position, the headlight and all the
lights turn off automatically if the “ENGINE START STOP” switch is
turned to ACCESSORY mode or turned off.
●When the light switch is in the
or
position, the headlights
and front fog lights turn off automatically if the “ENGINE START STOP”
switch is turned to ACCESSORY mode or turned off.
To turn the lights on again, turn to IGNITION ON mode, or turn the light
switch off once and then back to the
or
position.
■ Light reminder buzzer
Vehicles without smart entry & start system
A buzzer sounds when the engine switch is turned to the “LOCK” or
“ACC” position and the driver’s door is opened while the lights are turned
on.
Vehicles with smart entry & start system
A buzzer sounds when the “ENGINE START STOP” switch is turned off or
to the ACCESSORY mode and the driver’s door is opened while the lights
are turned on.
■ Automatic headlight leveling system (vehicles with discharge head-
lights)
The level of the headlights is automatically adjusted according to the number
of passengers and the loading condition of the vehicle to ensure that the
headlights do not interfere with other road users.
252
VERSO_EE_OM64517E
2-3. Operating the lights and wipers
■ Turning on the low beam headlights when the vehicle is parked in dark
areas
Turn off the engine with the light switch in
or off, and pull the light switch
toward you and release it. The low beam
headlights will turn on for about 30 sec-
onds to light up the area around the vehi-
cle.
The lights are turned off in the following
2
situations.
● Vehicles without smart entry & start
system:
The engine switch is turned to the “ON”
position.
● Vehicles with smart entry & start sys-
tem:
The “ENGINE START STOP” switch is
turned to IGNITION ON mode.
● The light switch is turned on.
● The light switch is pulled toward you
and then released.
■ Customization that can be configured at any authorized Toyota dealer
or repairer, or another duly qualified and equipped professional
Settings of the light sensor sensitivity can be changed.
(Customizable features P. 646)
NOTICE
■ To prevent battery discharge
Do not leave the lights on longer than necessary when the engine is not run-
ning.
253
VERSO_EE_OM64517E
2-3. Operating the lights and wipers
Fog light switch
The fog lights secure excellent visibility in difficult driving condi-
tions, such as in rain and fog.
Turns the front and
rear fog light off
Turns the front fog
lights on
Turns both front and
rear fog lights on
Releasing the switch ring
returns it to
Operating the switch ring again
turns only the rear fog light off.
■ Fog lights can be used when
Front fog lights: The headlights or front position lights are turned on.
Rear fog light: The front fog lights are turned on.
254
VERSO_EE_OM64517E
