Toyota Verso (2017 year). Instruction - part 5
1-2. Opening, closing and locking the doors
68
VERSO_EE_OM64517E
1-2. Opening, closing and locking the doors
1
69
VERSO_EE_OM64517E
1-2. Opening, closing and locking the doors
70
VERSO_EE_OM64517E
1-2. Opening, closing and locking the doors
1
71
VERSO_EE_OM64517E
1-2. Opening, closing and locking the doors
72
VERSO_EE_OM64517E
1-2. Opening, closing and locking the doors
Side doors
The vehicle can be locked and unlocked using the smart entry &
start system, wireless remote control, key or door lock switch.
■ Smart entry & start system (if equipped)
P. 42
1
■ Wireless remote control
P. 64
■ Key (driver’s door only)
Turning the key operates the doors as follows:
Vehicles without smart entry & start system
Locks all doors
Unlocks all doors
Vehicles with smart entry & start system
The doors can also be locked and unlocked with the mechanical
key. (P. 606)
■ Door lock switch
Locks all doors
Unlocks all doors
73
VERSO_EE_OM64517E
1-2. Opening, closing and locking the doors
■ Inside door lock buttons
Locks the door
Unlocks the door
The front doors can be opened
by pulling the inside handle
even if the inside door lock but-
ton is in the lock position.
Locking the driver’s door from the outside without a key
Move the inside door lock button to the lock position.
Close the door while pulling the door handle.
Vehicles without smart entry & start system
The door cannot be locked if the key is in the engine switch.
Vehicles with smart entry & start system
The door cannot be locked if the “ENGINE START STOP” switch is
in the ACCESSORY or IGNITION ON mode, or the electronic key
is left inside the vehicle.
The key may not be detected correctly and the door may be locked.
74
VERSO_EE_OM64517E
1-2. Opening, closing and locking the doors
Rear door child-protector lock
The door cannot be opened from
inside the vehicle when the lock
is set.
1
Unlock
Lock
These locks can be set to prevent
children from opening the rear
doors. Push down the each rear
door switch to lock both rear
doors.
75
VERSO_EE_OM64517E
1-2. Opening, closing and locking the doors
Automatic door locking and unlocking systems
The following functions can be set or canceled:
Function
Operation
Shift position linked
Shifting the shift lever out of “P” locks all
door locking function*1
doors.
Shift position linked
Shifting the shift lever to “P” unlocks all
door unlocking
doors.
function*1
All doors are locked when the vehicle speed
Speed linked door
is approximately 20 km/h (12 mph) or
locking function*2
higher.
Vehicles without smart entry & start
system
All doors are unlocked when the driver’s
door is opened within approximately 45
seconds after turning the engine switch to
Driver’s door linked door
the “LOCK” position.
unlocking function*2
Vehicles with smart entry & start system
All doors are unlocked when the driver’s
door is opened within approximately 45
seconds after turning the “ENGINE
START STOP” switch off.
*1: Vehicles with a Multidrive
*2: Default setting
76
VERSO_EE_OM64517E
1-2. Opening, closing and locking the doors
■ Setting and canceling the functions
Vehicles without Navigation/Multimedia system
To switch between setting and canceling, follow the procedure
below:
1
Vehicles without smart entry & start system: Close all the
doors and turn the engine switch to the “ON” position. (Per-
form
within 10 seconds.)
Vehicles with smart entry & start system: Close all the doors
and turn the “ENGINE START STOP” switch to IGNITION ON
mode. (Perform
within 10 seconds.)
Shift the shift lever to “P” or “N”,
press and hold the door lock
switch (
or
) for about
5
seconds then release.
The shift lever and switch posi-
tions corresponding to the
desired function to be set are
shown as follows.
Use the same procedure to can-
cel the function.
Shift lever
Door lock switch
Function
position
position
Shift position linked door
locking function*
“P”
Shift position linked door
unlocking function*
Speed linked door locking
function
“N”
Driver’s door linked door
unlocking function
*:Vehicles with a Multidrive
77
VERSO_EE_OM64517E
1-2. Opening, closing and locking the doors
When the setting or canceling operation is complete, all doors are
locked and then unlocked.
Vehicles with Navigation/Multimedia system
P. 646
■ Impact detection door lock release system
In the event that the vehicle is subject to a strong impact, all the doors are
unlocked. Depending on the force of the impact or the type of accident, how-
ever, the system may not operate.
■ Using the mechanical key (vehicles with smart entry & start system)
The doors can also be locked and unlocked with the mechanical key.
(P. 606)
■ If a wrong key is used (vehicles with alarm)
The key cylinder rotates freely to inside mechanism.
WARNING
■ To prevent an accident
Observe the following precautions while driving the vehicle.
Failing to do so may result in a door opening and an occupant falling out,
resulting in death or serious injury.
●Always use a seat belt.
● Ensure that all doors are properly closed.
●Do not pull the inside handle of the doors while driving.
The doors may be opened and the passengers are thrown out of the vehi-
cle and it may result in serious injury or death.
Be especially careful for the front doors, as the doors may be opened even
if the inside door lock buttons are in locked position.
● Set the rear door child-protector locks when children are seated in the rear
seat.
78
VERSO_EE_OM64517E
1-2. Opening, closing and locking the doors
Back door
The back door can be locked/unlocked and opened by the following
procedures.
■ Locking and unlocking the back door
Smart entry & start system (if equipped)
1
P. 42
Wireless remote control
P. 64
Key
P. 73
Door lock switch
P. 73
■ Opening the back door from outside the vehicle
Raise the back door while
pushing up the back door
opener switch.
79
VERSO_EE_OM64517E
1-2. Opening, closing and locking the doors
When closing the back door
Lower the back door using the
back door handle, and make
sure to push the back door down
from the outside to close it.
■ Luggage compartment light
The luggage compartment light turns on when the back door is opened with
the luggage compartment light switch on.
On
Off
■ If the back door opener is inoperative or the battery is discharged
P. 605
80
VERSO_EE_OM64517E
1-2. Opening, closing and locking the doors
WARNING
■ Caution while driving
●Keep the back door closed while driving.
If the back door is left open, it may hit near-by objects while driving or lug-
1
gage may be unexpectedly thrown out, causing an accident.
In addition, exhaust gases may enter the vehicle, causing death or a seri-
ous health hazard. Make sure to close the back door before driving.
● Before driving the vehicle, make sure that the back door is fully closed. If
the back door is not fully closed, it may open unexpectedly while driving,
causing an accident.
●Never let anyone sit in the luggage compartment. In the event of sudden
braking or a collision, they are susceptible to death or serious injury.
■ When children are in the vehicle
Observe the following precautions.
Failure to do so may result in death or serious injury.
●Do not allow children to play in the luggage compartment.
If a child is accidentally locked in the luggage compartment, they could
have heat exhaustion or other injuries.
●Do not allow a child to open or close the back door.
Doing so may cause the back door to move unexpectedly, or cause the
child’s hands, head, or neck to be caught by the closing back door.
■ Operating the back door
Observe the following precautions.
Failure to do so may cause parts of the body to be caught, resulting in death
or serious injury.
●Remove any heavy loads, such as snow and ice, from the back door
before opening it. Failure to do so may cause the back door to suddenly
shut again after it is opened.
● When opening or closing the back door, thoroughly check to make sure
the surrounding area is safe.
● If anyone is in the vicinity, make sure they are safe and let them know that
the back door is about to open or close.
●Use caution when opening or closing the back door in windy weather as it
may move abruptly in strong wind.
81
VERSO_EE_OM64517E
1-2. Opening, closing and locking the doors
WARNING
■ Operating the back door
● The back door may suddenly shut if it is
not opened fully. It is more difficult to
open or close the back door on an
incline than on a level surface, so
beware of the back door unexpectedly
opening or closing by itself. Make sure
that the back door is fully open and
secure before using the luggage com-
partment.
● When closing the back door, take extra
care to prevent your fingers etc. from
being caught.
● When closing the back door, make sure
to press it lightly on its outer surface. If
the back door handle is used to fully
close the back door, it may result in
hands or arms being caught.
●Do not pull on the back door damper stay to close the back door, and do
not hang on the back door damper stay.
Doing so may cause hands to be caught or the back door damper stay to
break, causing an accident.
● If a bicycle carrier or similar heavy object is attached to the back door, it
may suddenly shut again after being opened, causing someone’s hands,
head or neck to be caught and injured. When installing an accessory part
to the back door, using a genuine Toyota part is recommended.
82
VERSO_EE_OM64517E
1-2. Opening, closing and locking the doors
NOTICE
■ Back door damper stays
The back door is equipped with damper stays that hold the back door in
place.
1
Observe the following precautions.
Failure to do so may cause damage to the back door damper stay, resulting
in malfunction.
● Do not attach any foreign objects, such
as stickers, plastic sheets, or adhesives
to the damper stay rod.
● Do not touch the damper stay rod with
gloves or other fabric items.
● Do not attach any accessories other
Damper stay rod
than genuine Toyota parts to the back
door.
● Do not place your hand on the damper
stay or apply lateral forces to it.
83
VERSO_EE_OM64517E
1-3. Adjustable components (seats, mirrors, steering wheel)
Front seats
Seat position adjustment
lever
Seatback angle adjustment
lever
Vertical height adjustment
lever (if equipped)
Active head restraints
When the occupant’s lower back
presses against the seatback
during a rear-end collision, the
head restraint moves slightly for-
ward and upward to help reduce
the risk of whiplash on the seat
occupant.
84
