Toyota Verso (2017 year). Instruction - part 6
1-3. Adjustable components (seats, mirrors, steering wheel)
■ Active head restraints
Even small forces applied to the seatback may cause the head restraint to
move. Pushing up a locked head restraint forcibly may show the head
restraint inner structure. These do not indicate problems.
1
During
rear-end
collision
Inner
structure
WARNING
■ Seat adjustment
● Be careful that the seat does not hit passengers or luggage.
● To reduce the risk of sliding under the lap belt during a collision, do not
recline the seat more than necessary.
If the seat is too reclined, the lap belt may slide past the hips and apply
restraint forces directly to the abdomen or your neck may contact the
shoulder belt, increasing the risk of death or serious injury in the event of
an accident.
Adjustments should not be made while driving as the seat may unexpect-
edly move and cause the driver to lose control of the vehicle.
●After adjusting the seat, make sure that the seat is locked in position.
85
VERSO_EE_OM64517E
1-3. Adjustable components (seats, mirrors, steering wheel)
Rear seats
■ Adjusting the second seats
Seat position adjustment
lever
Seatback angle adjustment
lever
: If equipped
86
VERSO_EE_OM64517E
1-3. Adjustable components (seats, mirrors, steering wheel)
■ Adjusting the third seats (if equipped)
Seatback angle adjustment
strap
1
Moving a second seat for third seat access (vehicles with third seats)
■ Getting in the vehicle
Pass the outside seat belt
through the seat belt hanger.
This prevents the shoulder belt
from being damaged.
87
VERSO_EE_OM64517E
1-3. Adjustable components (seats, mirrors, steering wheel)
Pull up the walk-in lever and fold
down the seatback. The seat will
slide forward.
Move the seat to the front-most
position.
■ Getting out of the vehicle
Pass the outside seat belt
through the seat belt hanger.
This prevents the shoulder belt
from being damaged.
Pull up the walk-in lever and fold
down the seatback. The seat will
slide forward.
Move the seat to the front-most
position.
Make sure that no passenger is
seated on the second seat before
operating the walk-in lever.
■ After passengers have entered/exited the vehicle
Lift up the seatback and slide the seat backward until it locks.
Remove the outside seat belt from the seat belt hanger.
88
VERSO_EE_OM64517E
1-3. Adjustable components (seats, mirrors, steering wheel)
Folding down the second seats (vehicles with second seats)
■ Before folding down the second seats
Stow the second center seat belt. (P. 98)
Pass the outside seat belts
1
through the seat belt hangers.
This prevents the shoulder belt
from being damaged.
Adjust the head restraint to the
down-most position.
Raise the armrest.
89
VERSO_EE_OM64517E
1-3. Adjustable components (seats, mirrors, steering wheel)
■ Folding down the second seats
Pull up the seatback angle
adjustment lever and fold down
the seatback.
■ Returning the second seats
Lift up the seatbacks until they lock.
Remove the outside seat belts from the seat belt hangers.
Replace the second center seat belt. (P. 98)
Folding down the third seats (vehicles with third seats)
■ Before folding down the third seats
Stow the seat belt buckles as
shown.
90
VERSO_EE_OM64517E
1-3. Adjustable components (seats, mirrors, steering wheel)
Pass the outside seat belts
through the seat belt hangers.
This prevents the shoulder belt
from being damaged.
1
Adjust the head restraint to the
down-most position.
■ Folding down the third seats
From inside
Pull the seatback angle adjust-
ment strap and fold down the
seatback.
91
VERSO_EE_OM64517E
1-3. Adjustable components (seats, mirrors, steering wheel)
From outside
Open the back door and pull the
lock release strap to fold down
the third seats.
■ Returning the third seats
Lift up the seatbacks until they lock.
Remove the outside seat belts from the seat belt hangers.
WARNING
■ When folding the rear seatbacks down
Observe the following precautions. Failure to do so may result in death or
serious injury.
●Do not fold the seatbacks down while driving.
● Stop the vehicle on level ground, set the parking brake and shift the shift
lever to “P” (Multidrive) or “1” (manual transmission).
●Do not allow anyone to sit on a folded seatback or in the luggage compart-
ment while driving.
●Do not allow children to enter the luggage compartment.
92
VERSO_EE_OM64517E
1-3. Adjustable components (seats, mirrors, steering wheel)
WARNING
■ Seat adjustment
● Be careful not to get your hands pinched between the luggage cover and
the seat.
1
● To reduce the risk of sliding under the lap belt during a collision, do not
recline the seat more than necessary. If the seat is too reclined, the lap
belt may slide past the hips and apply restraint forces directly to the abdo-
men, or your neck may contact the shoulder belt, increasing the risk of
death or serious injury in the event of an accident. Adjustments should not
be made while driving as the seat may unexpectedly move and cause the
driver to lose control of the vehicle.
■ After returning the seatbacks to the upright position
Observe the following precautions. Failure to do so may result in death or
serious injury.
● Make sure the seatback is securely locked by pressing forward and rear-
ward on the top.
●Check that the seat belts are not twisted or caught in the seatback.
NOTICE
■ Stowing the seat belts
The seat belts and the buckles must be stowed before you fold down the
rear seatbacks.
93
VERSO_EE_OM64517E
1-3. Adjustable components (seats, mirrors, steering wheel)
Head restraints
Front seats
Vertical adjustment
Up
Pull the head restraints up.
Down
Lock release
button
Push the head restraint down
while pushing the lock release
button.
Second seats (if equipped)
Vertical adjustment
Up
Pull the head restraints up.
Lock
Down
release
button
Push the head restraint down
while pushing the lock release
button.
Third seats (if equipped)
Vertical adjustment
Up
Pull the head restraints up.
Lock release
Down
button
Push the head restraint down
while pushing the lock release
button.
94
VERSO_EE_OM64517E
1-3. Adjustable components (seats, mirrors, steering wheel)
■ Removing the head restraints
Pull the head restraint up while pressing
the lock release button.
1
■ Adjusting the height of the head restraints
Make sure that the head restraints are
adjusted so that the center of the head
restraint is closest to the top of your ears.
■ Adjusting the rear seat head restraint (vehicles with rear seats)
Always raise the head restraint one level from the stowed position when
using.
WARNING
■ Head restraint precautions
Observe the following precautions regarding the head restraints. Failure to
do so may result in death or serious injury.
●Use the head restraints designed for each respective seat.
● Adjust the head restraints to the correct position at all times.
● After adjusting the head restraints, push down on them and make sure
they are locked in position.
●Do not drive with the head restraints removed.
95
VERSO_EE_OM64517E
1-3. Adjustable components (seats, mirrors, steering wheel)
Seat belts
Make sure that all occupants are wearing their seat belts before driv-
ing the vehicle.
■ Correct use of the seat belts
Extend the shoulder belt so
that it comes fully over the
shoulder, but does not
come into contact with the
neck or slide off the shoul-
der.
Position the lap belt as low
as possible over the hips.
Adjust the position of the
seatback. Sit up straight
and well back in the seat.
Do not twist the seat belt.
■ Fastening and releasing the seat belt
Fastening the belt
Push the plate into the buckle
until a click sound is heard.
96
VERSO_EE_OM64517E
1-3. Adjustable components (seats, mirrors, steering wheel)
Releasing the belt
Press the release button.
1
Release
button
■ Adjusting the seat belt shoulder anchor height (front seats)
Push the seat belt shoulder
anchor down while pressing
the release button.
Push the seat belt shoulder
anchor up.
Move the height adjuster up
and down as needed until you
hear a click.
97
VERSO_EE_OM64517E
1-3. Adjustable components (seats, mirrors, steering wheel)
Center second seat belt (if equipped)
The center second seat belt is a 3-point type restraint with 2 buckles.
Both seat belt buckles must be correctly located and securely latched
for proper operation.
Fastening the belt
Push each of the plates into the
buckles until a click sound is
heard.
■ Release method
The center second seat belt can be completely released when not
required, such as when folding down the second seat.
Releasing the belt
Press each of the release but-
tons.
Release button
Release button
98
VERSO_EE_OM64517E
1-3. Adjustable components (seats, mirrors, steering wheel)
Stow the seat belt tabs in the
cover set in the roof as shown.
1
■ Extracting the belt
Push the tab.
Remove the tabs from the
cover.
99
VERSO_EE_OM64517E
1-3. Adjustable components (seats, mirrors, steering wheel)
Seat belt pretensioners (front seats)
The pretensioner helps the seat
belt to quickly restrain the occu-
pant by retracting the seat belt
when the vehicle is subjected to
certain types of severe frontal
collision.
The pretensioner may not acti-
vate in the event of a minor frontal
impact, a side impact or a rear
impact.
■ Emergency locking retractor (ELR)
The retractor will lock the belt during a sudden stop or on impact. It may also
lock if you lean forward too quickly. A slow, easy motion will allow the belt to
extend so that you can move around fully.
■ Child seat belt usage
The seat belts of your vehicle were principally designed for persons of adult
size.
●Use a child restraint system appropriate for the child, until the child
becomes large enough to properly wear the vehicle’s seat belt. (P. 159)
● When the child becomes large enough to properly wear the vehicle’s
seat belt, follow the instructions on P. 96 regarding seat belt usage.
■ Replacing the belt after the pretensioner has been activated
If the vehicle is involved in multiple collisions, the pretensioner will activate
for the first collision, but will not activate for the second or subsequent colli-
sions.
■ Seat belt regulations
If seat belt regulations exist in the country where you reside, please contact
any authorized Toyota dealer or repairer, or another duly qualified and
equipped professional, for seat belt replacement or installation.
100
VERSO_EE_OM64517E
1-3. Adjustable components (seats, mirrors, steering wheel)
WARNING
Observe the following precautions to reduce the risk of injury in the event of
sudden braking, sudden swerving or an accident.
Failing to do so may cause death or serious injury.
1
■ Wearing a seat belt
● Ensure that all passengers wear a seat belt before driving.
● Always wear a seat belt properly.
●Each seat belt should be used by one person only. Do not use a seat belt
for more than one person at once, including children.
● Toyota recommends that children be seated in the rear seat and always
use a seat belt and/or an appropriate child restraint system.
●Do not recline the seat any more than necessary to achieve a proper seat-
ing position. The seat belt is most effective when the occupants are sitting
up straight and well back in the seats.
●Do not wear the shoulder belt under your arm.
● Always wear your seat belt low and snug across your hips.
■ Pregnant women
Obtain medical advice and wear the seat
belt in the proper way. (P. 96)
Women who are pregnant should position
the lap belt as low as possible over the
hips in the same manner as other occu-
pants. Extend the shoulder belt com-
pletely over the shoulder and position the
belt across the chest. Avoid belt contact
over the rounding of the abdominal area.
If the seat belt is not worn properly, not
only the pregnant woman, but also the
fetus could suffer death or serious injury
as a result of sudden braking or a colli-
sion.
■ People suffering illness
Obtain medical advice and wear the seat belt in the proper way. (P. 96)
101
VERSO_EE_OM64517E
