Toyota Prius+ (2016 year). Instruction - part 9

136

2. Instrument cluster

Trip information

1

Press the “CAR”. (→P. 133)

2

Select “Trip information” on the

“CAR” screen.

1

Average vehicle speed since

the hybrid system was

started.

2

Cruising range (→P. 137)

3

Fuel consumption in the past

15 minutes

4

Regenerated energy in the past 15 minutes

One symbol indicates 30 Wh.

Up to 5 symbols are shown.

5

Elapsed time since the hybrid system was started.

6

Resetting the consumption data

Average fuel consumption for the past 15 minutes is divided by

color into past averages and averages attained since the power

switch was last turned to ON mode. Use the displayed average fuel

consumption as a reference.

The image is an example only.

PRIUS +_OM_OM47B24E_(EE)

2. Instrument cluster

137

Past record

1

Press the “CAR”. (→P. 133)

2

Select

“Past record” on the

“CAR” screen.

1

Best recorded fuel consump-

tion

2

Previous fuel consumption

record

2

3

Average fuel consumption

4

Updating the average fuel

consumption data

Resetting the past record data

5

The average fuel consumption history is divided by color into past

averages and the average fuel consumption since the last updated.

Use the displayed average fuel consumption as a reference.

The image is an example only.

■ Updating the past record data

Update the average fuel consumption by selecting “Update” to measure the

current fuel consumption again.

■ Resetting the data

The fuel consumption data can be deleted by selecting “Clear”.

■ Cruising range

Displays the estimated maximum distance that can be driven with the quan-

tity of fuel remaining.

This distance is computed based on your average fuel consumption.

As a result, the actual distance that can be driven may differ from that dis-

played.

PRIUS +_OM_OM47B24E_(EE)

140

3-1. Key information

Keys

The keys

The following keys are provided with the vehicle.

1

Electronic keys

• Operating the smart entry &

start system (→P. 153)

• Operating the wireless remote

control function

2

Mechanical keys

3

Key number plate

Wireless remote control

1

Locks all the doors (→P. 144)

2

Unlocks all the doors (→P. 144)

PRIUS +_OM_OM47B24E_(EE)

3-1. Key information

141

Using the mechanical key

To take out the mechanical key,

press the release button and take

the key out.

After using the mechanical key,

store it in the electronic key. Carry

the mechanical key together with

the electronic key. If the electronic

key battery is depleted or the entry

Release button

function does not operate properly,

you will need the mechanical key.

(→P. 450)

3

■ If you lose your mechanical keys

New genuine mechanical keys can be made by any authorized Toyota dealer

or repairer, or another duly qualified and equipped professional using another

mechanical key and the key number stamped on your key number plate.

Keep the plate in a safe place such as your wallet, not in the vehicle.

■ When riding in an aircraft

When bringing an electronic key onto an aircraft, make sure you do not press

any buttons on the electronic key while inside the aircraft cabin. If you are

carrying an electronic key in your bag etc., ensure that the buttons are not

likely to be pressed accidentally. Pressing a button may cause the electronic

key to emit radio waves that could interfere with the operation of the aircraft.

PRIUS +_OM_OM47B24E_(EE)

3-1. Key information

143

NOTICE

■ To prevent key damage

●Do not drop the keys, subject them to strong shocks or bend them.

●Do not expose the keys to high temperatures for long periods of time.

●Do not get the keys wet or wash them in an ultrasonic washer etc.

●Do not attach metallic or magnetic materials to the keys or place the keys

close to such materials.

●Do not disassemble the keys.

●Do not attach a sticker or anything else to the surface of the electronic key.

●Do not place the keys near objects that produce magnetic fields, such as

TVs, audio systems and induction cookers.

3

●Do not place the keys near medical electrical equipment such as low-fre-

quency therapy equipment or microwave therapy equipment, and do not

receive medical attention with the keys on your person.

■ Carrying the electronic key on your person

Carry the electronic key 10 cm (3.9 in.) or more away from electric appli-

ances that are turned on. Radio waves emitted from electric appliances

within 10 cm (3.9 in.) of the electronic key may interfere with the key, caus-

ing the key to not function properly.

■ In case of a smart entry & start system malfunction or other key-related

problems

Take your vehicle with all the electronic keys provided with your vehicle to

any authorized Toyota dealer or repairer, or another duly qualified and

equipped professional.

■ When an electronic key is lost

If the electronic key remains lost, the risk of vehicle theft increases signifi-

cantly. Visit any authorized Toyota dealer or repairer, or another duly quali-

fied and equipped professional immediately with all remaining electronic

keys that were provided with your vehicle.

PRIUS +_OM_OM47B24E_(EE)

144

3-2. Opening, closing and locking the doors

Side doors

The vehicle can be locked and unlocked using the entry func-

tion, wireless remote control or door lock switch.

Unlocking and locking the doors from the outside

◆ Smart entry & start system

Carry the electronic key to enable this function.

Grip the driver’s door handle

1

or front passenger door han-

dle with the sensor

(if

equipped) to unlock the door.

Make sure to touch the sensor

on the back of the handle.

The doors cannot be unlocked

for 3 seconds after the doors are

locked.

2

Touch the lock sensor (indentation on the upper part of the front

door handle) to lock the doors.

Check that the door is securely locked.

◆ Wireless remote control

Locks all the doors

1

Check that the door is securely

locked.

Unlocks all the doors

2

PRIUS +_OM_OM47B24E_(EE)

3-2. Opening, closing and locking the doors

145

■ Operation signals

The emergency flashers flash to indicate that the doors have been locked/

unlocked. (Locked: Once; Unlocked: Twice)

■ Security feature

If a door is not opened within approximately 30 seconds after the vehicle is

unlocked, the security feature automatically locks the vehicle again.

■ When the door cannot be locked by the lock sensor on the upper part of

the door handle

If the door will not lock even when the top-

side sensor area is touched, try touching

both the topside and underside sensor

areas at the same time.

3

■ Door lock buzzer

If an attempt to lock the doors is made when a door is not fully closed, a

buzzer sounds continuously for 5 seconds. Fully close the door to stop the

buzzer, and lock the vehicle once more.

■ Setting the alarm (if equipped)

Locking the doors will set the alarm system. (→P. 98)

■ If the smart entry & start system or the wireless remote control does not

operate properly

● Use the mechanical key to lock and unlock the doors. (→P. 450)

● Replace the key battery with a new one if it is depleted. (→P. 361)

PRIUS +_OM_OM47B24E_(EE)

146

3-2. Opening, closing and locking the doors

Locking and unlocking the doors from the inside

◆ Door lock switch

1

Locks all the doors

2

Unlocks all the doors

◆ Inside lock buttons

1

Locks the door

2

Unlocks the door

The front doors can be opened

by pulling the inside handle

even if the lock buttons are in

the lock position.

Locking the front doors from the outside without a key

1

Move the inside lock button to the lock position.

2

Close the door while pulling the door handle.

The door cannot be locked if the power switch is in ACCESSORY or

ON mode, or the electronic key is left inside the vehicle.

The key may not be detected correctly and the door may be locked.

PRIUS +_OM_OM47B24E_(EE)

3-2. Opening, closing and locking the doors

147

Rear door child-protector lock

The door cannot be opened from

inside the vehicle when the lock is

set.

1

Unlock

2

Lock

These locks can be set to prevent

children from opening the rear

doors. Push down on each rear

door switch to lock both rear doors.

3

■ Customization

Settings (e.g. unlocking function using a key) can be changed.

(Customizable features: →P. 477)

WARNING

■ To prevent an accident

Observe the following precautions while driving the vehicle.

Failure to do so may result in a door opening and an occupant throwing out

of the vehicle, resulting in death or serious injury.

● Ensure that all doors are properly closed.

●Do not pull the inside handle of the doors while driving.

Be especially careful for the front doors, as the door may be opened even

if the inside lock buttons are in locked position.

● Set the rear door child-protector locks when children are seated in the rear

seats.

■ When opening or closing a door

Check the surroundings of the vehicle such as whether the vehicle is on an

incline, whether there is enough space for a door to open and whether a

strong wind is blowing. When opening or closing the door, hold the door

handle tightly to prepare for any unpredictable movement.

PRIUS +_OM_OM47B24E_(EE)

148

3-2. Opening, closing and locking the doors

Back door

The back door can be unlocked/locked and opened by the fol-

lowing procedures.

◆ Smart entry & start system (if equipped)

Carry the electronic key to enable this function.

Locks all the doors

1

Check that the door is securely

locked.

Unlocks all the doors

2

The doors cannot be unlocked

for 3 seconds after the doors are

locked.

◆ Wireless remote control

→P. 140

◆ Door lock switch

→P. 146

Opening the back door from outside the vehicle

Raise the back door while pushing

up the back door opener switch.

PRIUS +_OM_OM47B24E_(EE)

3-2. Opening, closing and locking the doors

149

When closing the back door

Lower the back door using the

back door handle, and make sure

to push the back door down from

the outside to close it.

Be careful not to pull the back door

sideways when closing the back

door with the handle.

■ Luggage compartment light

The luggage compartment light turns on when the back door is opened with

3

the luggage compartment light switch on.

1

Off

2

On

When the power switch is turned off, the

light will go off automatically after

20

minutes.

■ If the back door opener is inoperative

The back door can be unlocked from the inside.

Remove the cover.

1

To prevent damage, cover the tip of the

screwdriver with a rag.

2

Move the lever.

PRIUS +_OM_OM47B24E_(EE)

150

3-2. Opening, closing and locking the doors

WARNING

Observe the following precautions.

Failure to do so may result in death or serious injury.

■ Before driving

● Make sure that the back door is fully closed. If the back door is not fully

closed, it may open unexpectedly while driving and hit near-by objects or

luggage in the luggage compartment may be thrown out, causing an acci-

dent.

●Do not allow children to play in the luggage compartment.

If a child is accidentally locked in the luggage compartment, they could

have heat exhaustion or other injuries.

●Do not allow a child to open or close the back door.

Doing so may cause the back door to open unexpectedly, or cause the

child’s hands, head, or neck to be caught by the closing back door.

■ Important points while driving

●Keep the back door closed while driving.

If the back door is left open, it may hit near-by objects or luggage in the

luggage compartment may be thrown out, causing an accident.

●Never let anyone sit in the luggage compartment. In the event of sudden

braking, sudden swerving or a collision, they are susceptible to death or

serious injury.

PRIUS +_OM_OM47B24E_(EE)

3-2. Opening, closing and locking the doors

151

WARNING

■ Operating the back door

Observe the following precautions.

Failure to do so may cause parts of the body to be caught, resulting in death

or serious injury.

●Remove any heavy loads, such as snow and ice, from the back door

before opening it. Failure to do so may cause the back door to suddenly

shut again after it is opened.

● When opening or closing the back door, thoroughly check to make sure

the surrounding area is safe.

● If anyone is in the vicinity, make sure they are safe and let them know that

the back door is about to open or close.

●Use caution when opening or closing the back door in windy weather as it

3

may move abruptly in strong wind.

●The back door may suddenly shut if it is

not opened fully. It is more difficult to

open or close the back door on an

incline than on a level surface, so

beware of the back door unexpectedly

opening or closing by itself. Make sure

that the back door is fully open and

secure before using the luggage com-

partment.

● When closing the back door, take extra

care to prevent your fingers etc. from

being caught.

● When closing the back door, make sure

to press it lightly on its outer surface. If

the back door handle is used to fully

close the back door, it may result in

hands or arms being caught.

●Do not pull on the back door damper stay to close the back door, and do

not hang on the back door damper stay.

Doing so may cause hands to be caught or the back door damper stay to

break, causing an accident.

● If a bicycle carrier or similar heavy object is attached to the back door, it

may suddenly shut again after being opened, causing someone’s hands,

head or neck to be caught and injured. When installing an accessory part

to the back door, using a genuine Toyota part is recommended.

PRIUS +_OM_OM47B24E_(EE)

152

3-2. Opening, closing and locking the doors

NOTICE

■ Back door damper stays

The back door is equipped with damper stays that hold the back door in

place.

Observe the following precautions.

Failure to do so may cause damage to the back door damper stay, resulting

in malfunction.

●Do not attach any foreign objects, such

as stickers, plastic sheets, or adhesives

to the damper stay rod.

●Do not touch the damper stay rod with

gloves or other fabric items.

●Do not attach any accessories other

than genuine Toyota parts to the back

Damper stays

door.

●Do not place your hand on the damper stay or apply lateral forces to it.

PRIUS +_OM_OM47B24E_(EE)

Content   ..  7  8  9  10   ..
