374

5-16. Toyota Entune overview

*

: If equipped

Type A: Function achieved by using a smart
phone or DCM

*

Of the functions included with Toyota Entune, the Toyota
Entune App Suite Connect relies on the use of a smart phone
or DCM.



Using a smart phone

• Toyota Entune App Suite Connect enables applicable apps

installed on a smart phone to be displayed on and operated from
the screen via a Bluetooth

®

.



Via DCM

• Toyota Entune App Suite Connect enables applicable apps

installed on the system to be displayed on and operated from the
screen.

A few settings must be performed before Toyota Entune App
Suite Connect can be used. (P.379)

By using a smart phone or DCM

375

5-16. Toyota Entune overview

5

Entune au

dio

Content provider
Provides contents to the application server.
Application server
Provides applications to the system or a smart phone.

Smart phone

*

Using the Toyota Entune App Suite Connect, communication is
relayed between the system, application server and contents pro-
vider. The smart phone cannot be operated while communicating.
Applications
Display usable content from the content providers on the screen
using the data connection of the connected smart phone or DCM.
System
Content received, via a smart phone or DCM, from content pro-
vider servers is displayed on the screen. The system is equipped
with an application player to run applications.
Via DCM

*

: For known compatible phones, refer to

http://www.toyota.com/Entune/
in the United States,
http://www.toyota.ca/entune
in Canada, and
http://www.toyotapr.com/entune
in Puerto Rico.

The required operations to acti-
vate applications and connect a
smart phone to the system, and
the registration steps for the
Toyota Entune App Suite Con-
nect are explained in this sec-
tion.


Toyota Entune App Suite
Connect does not require an
activation fee or monthly
recurring fees.



Services requiring a separate

contract can also be used.

*

*

: For details, refer to

http://www.toyota.com/Entune/
or call 1-800-331-4331 in the
United States,
http://www.toyota.ca/entune
or call 1-888-869-6828 in Can-
ada, and
http://www.toyotapr.com/entune
or call 1-877-855-8377 in Puerto
Rico.

■

Availability of function



Toyota Entune App Suite
Connect is available in the
contiguous United States,

Before using the function

376

5-16. Toyota Entune overview

Washington D.C., Alaska,
Hawaii, Puerto Rico and Can-
ada.



Toyota Entune App Suite
Connect is not available in the
United States Virgin Islands.

●

Data usage fees may apply while

using Toyota Entune App Suite

Connect function. Confirm data

usage fees before using this func-

tion.

●

For details regarding operation of

the Toyota Entune App Suite Con-

nect and the applications, refer to

http://www.toyota.com/Entune/

in the United States,

http://www.toyota.ca/entune

in Canada, and

http://www.toyotapr.com/entune

in Puerto Rico.

●

These functions are not made

available in some countries or

areas. Availability of functions of

the Toyota Entune App Suite Con-

nect service is dependent on net-

work reception level.

■

Initializing personal data

The personal data used in appli-
cations can be reset. (P.298)
The following personal data can
be deleted and returned to their
default settings:


Downloaded contents



Radio stations that were lis-
tened to

Once initialized, the data and set-

tings will be erased. Pay much

attention when initializing the data.

■

Settings required to use
Toyota Entune App Suite
Connect

Perform the settings in the fol-
lowing order.

1

Download the Toyota Entune
App Suite Connect applica-
tion to your smart phone or
the system.

2

Register a Bluetooth

®

 phone

with the hands-free system.
(P.276)

●

Applications can only be used

when the Toyota Entune App

Suite Connect application has

been downloaded to your smart

phone or the system, and the

application is running.

●

Toyota Entune App Suite Connect

operational procedures can also

be confirmed by visiting

http://www.toyota.com/Entune/

in the United States,

http://www.toyota.ca/entune

in Canada, and

http://www.toyotapr.com/entune

in Puerto Rico.

●

If a Toyota Entune App Suite Con-

nect application is used while iPod

audio/video is being played back,

system operation may become

unstable.

Preparation before using
Toyota Entune App Suite
Connect

377

5-16. Toyota Entune overview

5

Entune au

dio

*

: If equipped

■

Subscription

After you have signed the
Telematics Subscription Service
Agreement and are enrolled,
you can begin receiving ser-
vices. A variety of subscription
terms are available. Contact
your Toyota dealer, or call
1-800-331-4331 in the United
States, 1-888-869-6828 in Can-
ada, and 1-877-855-8377 in
Puerto Rico, for further sub-
scription details. (P.375)

■

Availability of functions



Wi-Fi

®

 Hotspot is available in

the contiguous United States,
Washington D.C., Alaska and
Hawaii.



Wi-Fi

®

 Hotspot is not avail-

able in Puerto Rico, Canada,
and in the United States Vir-
gin Islands.

Type B: Function

achieved by using

DCM and the system

*

The functionality of Wi-Fi

®



Hotspot is made possible
through the shared work of
the DCM and the system.

This service is available by
subscription and supported
by the Toyota Entune center,
which operates 24 hours a
day, 7 days a week.

For details about Wi-Fi

®



Hotspot:P.287

Before using the function

378

5-16. Toyota Entune overview

*

: If equipped

Type C: Function

achieved by using

DCM

*

The functionality of Safety
Connect is made possible
by the use of a DCM.

For details, (P.61)

379

5-17. Toyota Entune operation

5

Entune au

dio

5-17.Toyota Entune operation



From the “MENU” button

1

Press the “MENU” button.

2

Select “Apps”.

3

Follow the steps in “From the
“APPS” button” from step

3

.

(P.379)



From the “APPS” button

1

Press the “APPS” button.

2

Select “Apps”.

If a specific application screen is

displayed, select “Apps” again.

3

Select the desired application
screen button.

: Select to activate an applica-

tion.
“Update”: Select to update the

applications. (P.379)
“App Catalog”: Select to change the

order of the applications. (P.380)

: Displays the number of new

notifications for the application

When the App Suite is activated,
an application may need to be
updated. To update an applica-
tion, it is necessary to download
update data and install it.

■

Downloading update

If an update is available,
“Update” can be selected.

Toyota Entune App

Suite Connect

App Suite is a function that
enables certain apps
installed on a smart phone
or the system to be dis-
played on and operated
from the system screen.
Before the Toyota Entune
App Suite Connect can be
used, some setup needs to
be performed. (P.376)
For details about the func-
tions and services provided
by each application, refer to
http://www.toyota.com/
Entune/
in the United States,
http://www.toyota.ca/entune
in Canada, and
http://www.toyotapr.com/
entune
in Puerto Rico.

Using Toyota Entune App
Suite Connect

Updating an application

380

5-17. Toyota Entune operation

1

Select “Update” on the appli-
cation screen. (P.379)

2

Check that downloading
starts.

“Download in Background”: Select

to operate other functions while

downloading.
“Cancel”: Select to cancel updating.

3

Check that downloading is
complete.

“Later”: Select to install later. When

this screen button is selected, the

screen will return to the last dis-

played screen. To install the update

data: (P.380)
“See Detail”: Select to display

detailed information on the update

data.
“Install”: Select to install the update

data. Follow the steps “Installing

the update data” from step

2

.

(P.380)

■

Installing the update data

After the downloading is com-
plete, “Update” will be changed
to “Install”.

1

Select “Install” on the appli-
cation screen. (P.379)

2

Select “Continue”.

“Later”: Select to postpone the

installation of the update data and

go back to the previous screen.

3

Check that installing is
started.

“Install in Background”: Select to

operate other functions while

installing.

4

Select “OK” after the install-
ing is complete.

The Toyota Entune App Suite Con-

nect function cannot be operated

while installing.

Order of the applications can be
changed.

1

Display the application
screen. (P.379)

2

Select “App Catalog”.

3

Select the desired application
to be moved.

4

Select “<<” or “>>” to move
the application, and then
select the done button.

When problems occur with start-
ing the application player, a
message will appear on the
screen. Referring to the follow-
ing items, identify the problem
and take the suggested correc-
tive action.


“When it is safe and legal to
do so, please ensure your
Entune App Suite application
is running and logged in on
your phone.”

The Toyota Entune App Suite Con-
nect application cannot be con-
nected to Bluetooth

®

 SPP.

Refer to
http://www.toyota.com/Entune/
in the United States,
http://www.toyota.ca/entune
in Canada, and
http://www.toyotapr.com/entune

Reordering the applica-
tions

If a message appears on
the screen

381

5-17. Toyota Entune operation

5

Entune au

dio

in Puerto Rico, to confirm if the
phone is Bluetooth

®

 SPP compati-

ble or not, and then activate the
Toyota Entune App Suite Connect
application.



“Installation failed, please try
again”

Installation can be attempted again
by changing to the application
screen and pressing the “Install”
switch.



“Application download error.
Please try again later.”

Downloading can be attempted
again by checking the communica-
tion status, changing to the applica-
tion screen and pressing the
“Download” switch again.



“Download error, some
Entune App Suite functions
may not work as expected.
Please reinitiate the download
process.”

The Toyota Entune App Suite Con-
nect application cannot be con-
nected to Bluetooth

®

 SPP.

Refer to
http://www.toyota.com/Entune/
in the United States,
http://www.toyota.ca/entune
in Canada, and
http://www.toyotapr.com/entune
in Puerto Rico, to confirm if the
phone is Bluetooth

®

 SPP compati-

ble or not, and then activate the
Toyota Entune App Suite Connect
application.
Please ensure your Toyota Entune
App Suite Connect application is
running and logged in on your
phone while vehicle is not moving.



“To use the services, Entune
APP Suite Connect applica-
tion needs to be running on
your phone. For more infor-
mation, please visit toy-
ota.com or call
1-800-331-4331 in the United
States, 1-888-869-6828 in
Canada, and 1-877-855-8377
in Puerto Rico.”

The Toyota Entune App Suite Con-
nect application cannot be con-
nected to Bluetooth

®

 SPP.

Refer to
http://www.toyota.com/Entune/
in the United States,
http://www.toyota.ca/entune
in Canada, and
http://www.toyotapr.com/entune
in Puerto Rico, to confirm if the
phone is Bluetooth

®

 SPP compati-

ble or not, and then activate the
Toyota Entune App Suite Connect
application.



“Communication unsuccess-
ful. Please try again.”

Communication was disconnected.
After a few moments, retry the
operation.

A keyword can be entered to an
application by the software key-
board or voice recognition func-
tion. For details about the
functions and services provided
by each application, refer to
http://www.toyota.com/Entune/

Entering keyword opera-
tion

382

5-17. Toyota Entune operation

in the United States,
http://www.toyota.ca/entune
in Canada, and
http://www.toyotapr.com/entune
in Puerto Rico.
The keyboard layout can be
changed. (P.296)

1

Display the application
screen. (P.379)

2

Select the desired application
screen button.

3

Select the character entering
space.

4

Enter a search term, and
then select “OK”.

5

Entering characters will be
reflected on the character
entering space.

For details on operating the key-

board: P.271

1

Display the application
screen. (P.379)

2

Select the desired application
screen button.

3

Press the talk switch.
(P.336)

4

Say the desired keyword.

Completion of the keyword will be

detected automatically.

5

Search results will be dis-
played on the screen.

Entering a keyword using
the software keyboard

Entering a keyword using
the voice recognition func-
tion

383

5-18. Toyota Entune App Suite Connect settings

5

Entune au

dio

5-18.Toyota Entune App Suite Connect settings

1

Press the “MENU” button.

2

Select “Setup”.

3

Select “Entune App Suite”.

4

Select the desired items to
be set.

Select to set the pop up
reminder for smart phone
data usage. (P.381)

Select to detect iPhone app
automatically on/off.
Select to set the enhanced
mode with connecting USB
device on/off.

When an iPhone is connected while
this setting is set to “On”, communi-
cation with devices connected to
other USB ports may not be possi-
ble. Also, depending on the device,
charging may not be possible.

Select to configure the Apps
menu layout (e.g. app order,
which applications are acti-
vated, etc.). This updates a
setting file stored on the Toy-
ota Entune center, this set-
tings file can also be updated
from the navigation system,
smart phone app and by web
portal.
Select to install the Apps via
a USB memory device. For
details, contact your Toyota
dealer.
Select to reset all setup
items.

The data use notification
pop-up, which indicates that the
system will use an internet con-
nection, can be enabled/dis-
abled.

1

Display the Toyota Entune
App Suite Connect settings
screen. (P.383)

Setup

The settings of Toyota
Entune App Suite Connect
can be changed.

Displaying the Toyota
Entune App Suite Con-
nect settings screen

Toyota Entune App Suite
Connect settings screen

Data use notification
pop-up settings

384

5-18. Toyota Entune App Suite Connect settings

2

Select “Data Usage Mes-
sage”.

3

Change the setting as
desired.

385

6

6

Interior

 featur

es

Interior features

.

6-1. Using the air conditioning

system and defogger

Manual air conditioning sys-

tem ............................

386

Automatic air conditioning

system.......................

391

Heated steering wheel/seat

heaters ......................

396

6-2. Using the interior lights

Interior lights list ..........

398

6-3. Using the storage features

List of storage features

..................................

400

Trunk features .............

403

6-4. Other interior features

Other interior features .

404

Garage door opener....

414

386

6-1. Using the air conditioning system and defogger

6-1.Using the air conditioning system and defogger

*

: If equipped

The display and button positions will differ depending on the type of
the system.

Fan speed control switch
Temperature control switch
“MAX A/C” switch
“A/C” switch
Outside air mode switch
Recirculated air mode switch
Airflow mode control switch
Rear window defogger and outside rear view mirror defoggers
switch

*

Windshield defogger switch
On/off switch

Rear window defogger switch

*

*

: If equipped

■

Adjusting the temperature
setting

To adjust the temperature set-
ting, turn the temperature con-
trol switch clockwise (warm) or
counterclockwise (cool).

If “A/C” switch is not pressed, the
system will blow ambient tempera-
ture air or heated air.
For quick cooling, press the “MAX
A/C” switch. The air conditioning
will automatically turn on and, if an

Manual air conditioning system

*

Air conditioning controls

387

6-1. Using the air conditioning system and defogger

6

Interior

 featur

es

air outlet position

 or

 is

selected, the system will be set to
recirculated air mode. While “MAX
A/C” is selected, it is not possible to
turn off the air conditioning.

■

Fan speed setting

To adjust the fan speed, turn the
fan speed control switch clock-
wise (increase) or counterclock-
wise (decrease).

Pressing the on/off switch to turns
off the fan.
When the fan is off, pressing the
on/off switch or turning the fan
speed control switch clockwise will
turn on the fan.

■

Change the airflow mode

Press the airflow mode control
switch.

The airflow mode changes as fol-
lows each time the switch is
pressed.

1

Upper body

2

Upper body and feet

3

Feet

4

Feet and the windshield

defogger operates

■

Switching between outside
air and recirculated air
modes



To change to recirculated air
mode, press the recirculated
air mode switch.

The indicator illuminates on the
recirculated air mode switch.



To change to outside air
mode, press the outside air
mode switch.

The indicator illuminates on the out-
side air mode switch.

■

Set cooling and dehumidifi-
cation function

Press the “A/C” switch.

When the function is on, the indica-
tor illuminates on the “A/C” switch.

■

Defogging the windshield

Defoggers are used to defog the
windshield and front side win-
dows.
Press the windshield defogger
switch.

Set the outside/recirculated air
mode switch to outside air mode if
the recirculated air mode is used.
To defog the windshield and the
side windows quickly, turn the air
flow and temperature up.
To return to the previous mode,
press the windshield defogger
switch again when the windshield is
defogged.
When the windshield defogger
switch is on, the indicator illumi-
nates on the windshield defogger

388

6-1. Using the air conditioning system and defogger

switch.

■

Defogging the rear window
and outside rear view mir-
rors



Vehicles without outside rear
view mirror defoggers

A defogger is used to defog the
rear window.
Press the rear window defogger
switch.

The defogger will automatically turn
off after a while.
When the rear window defogger
switch is on, the indicator illumi-
nates on the rear window defogger
switch.



Vehicles with outside rear
view mirror defoggers

Defoggers are used to defog the
rear window, and to remove
raindrops, dew and frost from
the outside rear view mirrors.
Press the rear window and out-
side rear view mirror defoggers
switch.

The defoggers will automatically
turn off after a while.
When the rear window and outside
rear view mirror defoggers switch is
on, the indicator illuminates on the
rear window and outside rear view
mirror defoggers switch.

■

Fogging up of the windows

●

The windows will easily fog up

when the humidity in the vehicle is

high. Turning “A/C” switch is on

will dehumidify the air from the

outlets and defog the windshield

effectively.

●

If you turn “A/C” switch is off, the

windows may fog up more easily.

●

The windows may fog up if the

recirculated air mode is used.

■

Outside/recirculated air mode

When driving on dusty roads such

as tunnels or in heavy traffic, set the

outside/recirculated air mode switch

to the recirculated air mode. This is

effective in preventing outside air

from entering the vehicle interior.

During cooling operation, setting the

recirculated air mode will also cool

the vehicle interior effectively.

■

When the outside temperature

falls to nearly 32°F (0°C)

The dehumidification function may

not operate even when “A/C” switch

is pressed.

■

Ventilation and air conditioning

odors

●

To let fresh air in, set the air condi-

tioning system to the outside air

mode.

●

During use, various odors from

inside and outside the vehicle may

enter into and accumulate in the

air conditioning system. This may

then cause odor to be emitted

from the vents.

●

It is recommended that the air

conditioning system be set to out-

side air mode prior to turning the

vehicle off.

●

When parking, the system auto-

matically switches to outside air

mode to encourage better air cir-

culation throughout the vehicle,

helping to reduce odors that occur

when starting the vehicle.

■

Air conditioning filter

P.457

■

Air conditioning system refrig-

erant

●

A label regarding the refrigerant of

the air conditioning system is

attached to the hood at the loca-

tion shown in the following illustra-

389

6-1. Using the air conditioning system and defogger

6

Interior

 featur

es

tion.

●

The meaning of each symbol on

the label are as follows:

■

Location of air outlets

The air outlets and air volume
changes according to the
selected air flow mode.

: If equipped

Caution

Air conditioning sys-
tem

Air conditioning sys-
tem lubricant type

Requires registered
technician to service
air conditioning sys-
tem

Flammable refrigerant

WARNING

■

To prevent the windshield

from fogging up

Do not use the windshield defog-

ger switch during cool air opera-

tion in extremely humid weather.

The difference between the tem-

perature of the outside air and

that of the windshield can cause

the outer surface of the wind-

shield to fog up, blocking your

vision.

■

When the outside rear view

mirror defoggers are operat-

ing (vehicles with outside rear

view mirror defoggers)

Do not touch the outside rear view

mirror surfaces, as they can

become very hot and burn you.

NOTICE

■

To prevent battery discharge

Do not leave the air conditioning

system on longer than necessary

when the engine is off.

■

When repairing/replacing

parts of the air conditioning

system

Have repair/replacement per-

formed by your Toyota dealer.

When a part of the air conditioning

system, such as the evaporator, is

to be replaced, it must be

replaced with a new one.

Air outlet layout and oper-
ations
