342

5-11. Voice command system operation

only be performed when the

audio/visual system is turned on.

343

5-12. Mobile Assistant operation

5

Entune au

dio

5-12.Mobile Assistant operation

●

While a phone call is active, the

Mobile Assistant cannot be used.

●

If using the navigation feature of

the cellular phone, ensure the
active audio source is Bluetooth

®



audio or iPod in order to hear turn

by turn direction prompts.

●

Wait for the listening beeps before

using the Mobile Assistant.

●

The Mobile Assistant may not rec-

ognize commands in the following

situations:

• Spoken too quickly.

• Spoken at a low or high volume.

• The windows are open.

• Passengers are talking while the

Mobile Assistant is being used.

• The fan speed of the air condition-

ing system is set at high.

• The air conditioning vents are

turned toward the microphone.

Mobile Assist supports the Siri
Eyes Free Mode and Google
App. The available features and
functions may vary based on the
iOS/Android version installed on
the connected device.



Type A

1

Press and hold the talk
switch on the steering wheel
until Mobile Assistant screen
is displayed.



Type B

1

Press and hold the

 switch

on the steering wheel until

Mobile Assistant

The Mobile Assistant func-
tion is a voice input assist
function. Mobile Assist sup-
ports the Siri Eyes Free
Mode and Google App.
(Google App can be used
only with the corresponding
device.) Instructions can be
spoken into the vehicle
microphone as if speaking a
command to the phone. The
content of the request is
then interpreted by the
phone and the result is out-
put from the vehicle speak-
ers. To operate the Mobile
Assistant, a compatible
device must be registered
and connected to this sys-
tem via Bluetooth

®

.

(P.276)
When an Apple CarPlay
connection is established,
this function will be unavail-
able.

Connectable devices and
available functions

Mobile Assistant opera-
tion

344

5-12. Mobile Assistant operation

Mobile Assistant screen is
displayed.

2

The Mobile Assistant can be
used only when the following
screen is displayed.



Type A: To cancel the Mobile
Assistant, select “Cancel” or
press and hold the talk switch
on the steering wheel.
Type B: To cancel the Mobile
Assistant, select “Cancel” or
press and hold the

 switch

on the steering wheel.



Type A: To restart the Mobile
Assistant for additional com-
mands, press the talk switch
on the steering wheel.
Type B: To restart the Mobile
Assistant for additional com-
mands, press the

 switch

on the steering wheel.

• Mobile Assistant can only be

restarted after the system
responds to a voice command.

• After some phone and music

commands, the Mobile Assistant
feature will automatically end to
complete the requested action.



The volume of the Mobile
Assistant can be adjusted
using the “POWER VOLUME”
knob or steering wheel vol-
ume control switches. The
Mobile Assistant and phone
call volumes are synchro-
nized.

345

5-13. Phone operation (Hands-free system for cellular phones)

5

Entune au

dio

5-13.Phone operation (Hands-free system for cellular phones)

The phone screen can be
reached by the following meth-
ods:



From the “PHONE” button

Press the “PHONE” button.



From the “MENU” button

Press the “MENU” button, then
select “Phone”.

The following functions can be
used on phone operation:


Registering/connecting a
Bluetooth

®

 device (P.276)



Placing a call using the Blue-
tooth

®

 hands-free system

(P.350)



Receiving a call using the
Bluetooth

®

 hands-free system

(P.353)



Talking on the Bluetooth

®



hands-free system (P.354)

The following function can be
used on message function:

Using the Bluetooth

®

 phone

message function (P.356)

The following functions can be
made in the system:


Phone settings (P.360)



Bluetooth

®

 settings (P.280)

Quick reference

Phone screen operation

Bluetooth

®

 hands-free

system operation

Message function

Setting up a phone

346

5-13. Phone operation (Hands-free system for cellular phones)

●

This system is not guaranteed to
operate with all Bluetooth

®



devices.

●

If your cellular phone does not
support Bluetooth

®

, this system

cannot function.

●

In the following conditions, the

system may not function:

• The cellular phone is turned off.

• The current position is outside the

communication area.

• The cellular phone is not con-

nected.

• The cellular phone has a low bat-

tery.

●

Depending on the type of Blue-
tooth

®

 phone, some function is

not available.

●

When using the hands-free sys-
tem or Bluetooth

®

 audio and

Wi-Fi

®

 Hotspot functions at the

same time, the following problems

may occur:

• The Bluetooth

®

 connection may

be cut.

• Noise may be heard on the Blue-

tooth

®

 audio playback.

• A noise may be heard during

phone calls.

●

Bluetooth

®

 uses the 2.4 GHz fre-

quency band. If both a Wi-Fi

®

 con-

nection and Bluetooth

®



connection are being used simul-

taneously, each connection may

be affected.

●

If a Bluetooth

®

 device is attempt-

ing to connect to the vehicle while

another device is connected as a
Bluetooth

®

 audio device or con-

nected using the hands-free sys-
tem or Wi-Fi

®

 Hotspot function,

the communication speed may

decrease or malfunctions may

occur, such as image distortion or
audio skipping. If a Bluetooth

®



device is connected to the system,

the interference it may cause will

be reduced. When carrying a
device with its Bluetooth

®

 connec-

tion enabled, make sure to regis-

ter it to the system and connect it
or disable its Bluetooth

®

 function.

●

When a device is connected via
Bluetooth

®

, the Bluetooth

®

 icon

on the status bar will be displayed

in blue. (P.264)

Some basics

The hands-free system
enables calls to be made
and received without having
to take your hands off the
steering wheel.

This system supports Blue-
tooth

®

. Bluetooth

®

 is a wire-

less data system that
enables cellular phones to
be used without being con-
nected by a cable or placed
in a cradle.

The operating procedure of
the phone is explained here.

When an Apple CarPlay
connection is established,
phone functions will be per-
formed by Apple CarPlay
instead of the hands-free
system.

WARNING

●

While driving, do not operate a

cellular phone.

347

5-13. Phone operation (Hands-free system for cellular phones)

5

Entune au

dio

To use the hands-free system
for cellular phones, it is neces-
sary to register a cellular phone
with the system. (P.276)

■

Connecting a Bluetooth

®



device



Registering an additional
device

1

Display the phone top
screen. (P.345)

2

Select “Select Device”.

3

Select “Add Device”.

When another Bluetooth

®

 device is

connected, a confirmation screen

will be displayed. To disconnect the
Bluetooth

®

 device, select “Yes”.

4

Follow the steps in “Register-
ing a Bluetooth

®

 phone for

the first time” from step

5

.

(P.276)



Selecting a registered device

1

Display the phone top
screen. (P.345)

2

Select “Select Device”.

3

Select the desired device to
be connected.

4

Check that a confirmation
screen is displayed when the
connection is complete.

If an error message is displayed,

follow the guidance on the screen

to try again.

■

Bluetooth

®

 phone condition

display

The condition of the Bluetooth

®



phone appears on the upper
right side of the screen.
(P.265)

WARNING

●

Your audio unit is fitted with
Bluetooth

®

 antennas. People

with implantable cardiac pace-

makers, cardiac resynchroniza-

tion therapy-pacemakers or

implantable cardioverter defibril-

lators should maintain a reason-

able distance between
themselves and the Bluetooth

®



antennas. The radio waves may

affect the operation of such

devices.

●

Before using Bluetooth

®



devices, users of any electrical

medical device other than

implantable cardiac pacemak-

ers, cardiac resynchronization

therapy-pacemakers or implant-

able cardioverter defibrillators

should consult the manufacturer

of the device for information

about its operation under the

influence of radio waves. Radio

waves could have unexpected

effects on the operation of such

medical devices.

NOTICE

Do not leave your cellular phone

in the vehicle. The temperature

inside may rise to a level that

could damage the phone.

Registering/Connecting a
Bluetooth

®

 phone

348

5-13. Phone operation (Hands-free system for cellular phones)

■

Steering switch

By pressing the phone switch, a
call can be received or ended
without taking your hands off the
steering wheel.

Phone switch

• If the switch is pressed during a

call, the call will end.

• If the switch is pressed when an

incoming call is received, the call
will be answered.

• If the switch is pressed during a

call when a separate incoming
call is waiting, the waiting call will
be answered.

• If the switch is pressed when an

Apple CarPlay connection is
established, the Apple CarPlay
phone application will be dis-
played on the system screen.

Volume control switch

• Press the “+” side to increase the

volume.

• Press the “-” side to decrease the

volume.

■

Microphone

The microphone is used when
talking on the phone.

●

The other party’s voice will be

heard from the front speakers.

The audio/visual system will be

muted during phone calls or when

hands-free voice commands are

used.

●

Talk alternately with the other

party on the phone. If both parties

speak at the same time, the other

party may not hear what has been

said. (This is not a malfunction.)

●

Keep call volume down. Other-

wise, the other party’s voice may

be audible outside the vehicle and

voice echo may increase. When

talking on the phone, speak

clearly towards the microphone.

●

The other party may not hear you

clearly when:

• Driving on an unpaved road.

(Making excessive traffic noise.)

• Driving at high speeds.

• The windows are open.

• The air conditioning vents are

pointed towards the microphone.

• The sound of the air conditioning

fan is loud.

• There is a negative effect on

sound quality due to the phone

and/or network being used.

Using the phone
switch/microphone

NOTICE

Do not touch and put a sharp

object to the microphone. It may

cause failure.

349

5-13. Phone operation (Hands-free system for cellular phones)

5

Entune au

dio

Press this switch to operate the
voice command system.

The voice command system and
its list of commands can be
operated. (P.336)

The following data is stored for
every registered phone. When
another phone is connected, the
following registered data cannot
be read:


Contact data



Call history data



Favorites data



Image data



All phone settings



Message settings

When a phone’s registration is

deleted, the above-mentioned data

is also deleted.

A lot of personal data is regis-
tered when the hands-free sys-
tem is used. When selling or
disposing of the vehicle, initial-
ize the data. (P.298)
The following data in the system
can be initialized:


Contact data



Call history data



Favorites data



Image data



All phone settings



Message settings

Once initialized, the data and set-

tings will be erased. Pay additional

attention when initializing the data.

Voice command system

About the contacts in the
contact list

When selling or disposing
of the vehicle

350

5-13. Phone operation (Hands-free system for cellular phones)

1

Display the phone top
screen. (P.345)

2

Select the desired method to
call from.

■

Calling methods from
phone screen



By call history (P.350)



By favorites (P.350)



By contacts (P.351)



By keypad (P.352)



By message (P.359)

■

Also the following lists are
available from each func-
tion’s screen



By voice command system
(P.337)



By home screen (P.352)

Up to 30 of the latest call history

items (missed, incoming and
outgoing) can be selected.

1

Display the phone top
screen. (P.345)

2

Select “History” and select
the desired contact.

If the contact which is not regis-

tered on the contact list is selected,

the name is displayed as “Unknown

Contact”. In this case, select the

number to make a call properly.

3

Check that the dialing screen
is displayed.

●

The icons of call type are dis-

played.

: Missed call

: Incoming call

: Outgoing call

●

When making a call to the same

number continuously, only the

most recent call is listed in call his-

tory.

●

When a phone number registered

in the contact list is received, the

name is displayed.

●

Number-withheld calls are also

memorized in the system.

●

International phone calls may not

be made depending on the type of
Bluetooth

®

 phone you have.

●

The list should group together

consecutive entries with the same

phone number and same call

type. For example, two calls from

John’s mobile would be displayed

as follows: John (2)

Calls can be made using regis-
tered contacts which can be

Placing a call using

the Bluetooth

®



hands-free system

After a Bluetooth

®

 phone

has been registered, a call
can be made using the
hands-free system. There
are several methods by
which a call can be made, as
described below.

Calling methods on the
Bluetooth

®

 phone

By call history

By favorites list

351

5-13. Phone operation (Hands-free system for cellular phones)

5

Entune au

dio

selected from a contact list.
(P.351)

1

Display the phone top
screen. (P.345)

2

Select “Favorites” and select
the desired contact.

3

Select the desired number.

4

Check that the dialing screen
is displayed.

Calls can be made by using
contact data which is transferred
from a registered cellular phone.
(P.362)
Up to 5000 contacts (maximum
of 4 phone numbers, e-mail
addresses and addresses per
contact) can be registered in the
contact list.

1

Display the phone top
screen. (P.345)

2

Select “Contacts” and select
the desired contact.

3

Select the desired number.

“Add Favorite”/“Remove Favorite”:

Select to register/remove the con-

tact in the favorites list. (P.366,

367)
“E-mail Addresses”: Select to dis-

play all registered e-mail addresses

for the contact.
“Addresses”: Select to display all

registered addresses for the con-

tact.

4

Check that the dialing screen
is displayed.

■

For PBAP compatible Blue-
tooth

®

 phones when “Auto-

matic Transfer” is set to on
(P.362)

Contacts are transferred auto-
matically.

■

For PBAP compatible Blue-
tooth

®

 phones when “Auto-

matic Transfer” is set to off
(P.362)

1

Select the desired item.

Select to always transfer all
the contacts from a con-
nected cellular phone auto-
matically.
Select to transfer all the con-
tacts from a connected cellu-
lar phone only once.
Select to cancel transferring.

By contacts list

When the contact list is
empty

352

5-13. Phone operation (Hands-free system for cellular phones)

2

Check that a confirmation
screen is displayed when the
operation is complete.

■

For PBAP incompatible but
OPP compatible Blue-
tooth

®

 phones

1

Select the desired item.

Select to transfer the con-
tacts from the connected cel-
lular phone.
Transfer the contact data to
the system using a Blue-
tooth

®

 phone.

Select to add a new contact
manually.
Follow the steps in “Register-
ing a new contact to the con-
tacts list” from step

2

.

(P.365)
Select to cancel transferring.

●

If your cellular phone is neither

PBAP nor OPP compatible, the

contacts cannot be transferred
using Bluetooth

®

. But the contacts

can be transferred from USB

device. (P.364)

●

Depending on the type of Blue-
tooth

®

 phone:

• It may be necessary to perform

additional steps on the phone

when transferring contact data.

• The registered image in the con-

tact list may not transfer depend-
ing on the type of Bluetooth

®



phone connected.

1

Display the phone top
screen. (P.345)

2

Select “Keypad” and enter
the phone number.

3

Select

 or press the



switch on the steering wheel.

4

Check that the dialing screen
is displayed.

Depending on the type of Blue-
tooth

®

 phone being connected, it

may be necessary to perform addi-

tional steps on the phone.

1

Display the home screen.
(P.270)

2

Select the desired contact.

3

Check that the dialing screen
is displayed.

■

Registering a new contact

1

Select and hold the screen
button to add a contact.

2

Select the desired contact.

3

Select the desired number.

●

If there is no contact in the con-

tacts list, the contacts cannot be

registered at the home screen.

●

The contact cannot be registered

at the home screen while driving.

By keypad

By home screen

353

5-13. Phone operation (Hands-free system for cellular phones)

5

Entune au

dio

1

Select “Answer” or press the

 switch on the steering

wheel to talk on the phone.

“Decline”: Select to refuse to
receive the call.
To adjust the volume of a received
call: Turn the “POWER VOLUME”
knob, or use the volume control
switch on the steering wheel.

●

The contact image picture can be

displayed only when the vehicle is

not moving.

●

During international phone calls,

the other party’s name or number

may not be displayed correctly

depending on the type of Blue-
tooth

®

 phone you have.

●

The incoming call display mode

can be set. (P.361)

●

The ringtone that has been set in

the sound settings screen can be

heard when there is an incoming

call. Depending on the type of

Bluetooth

®

 phone, both the sys-

tem and Bluetooth

®

 phone may

ring simultaneously when there is

an incoming call. (P.360)

Receiving a call using

the Bluetooth

®



hands-free system

When a call is received, the
following screen is dis-
played with a sound.

Incoming calls

354

5-13. Phone operation (Hands-free system for cellular phones)

Select to display the keypad
to send tones. (P.354)
Select to send tones. This
button only appears when a
number that contains a (w) is
dialed in hands-free mode.
(P.354)
Select to adjust your voice
volume that the other party
hears from their speaker.
(P.355)
Select to mute your voice to
the other party.
Select to change handset
modes between hands-free
and cellular phone.
Select to put a call on hold.
To cancel this function, select

“Activate”.
Select to hang up the phone.

●

Changing from hands-free call to

cellular phone call is not possible

while driving.

●

Only when the vehicle is not mov-

ing, the contact image can be dis-

played.

●

When cellular phone call is

changed to hands-free call, the

hands-free screen will be dis-

played and its functions can be

operated on the screen.

●

Changing between cellular phone

call and hands-free call can be

performed by operating the cellu-

lar phone directly.

●

Transferring methods and opera-

tions will be different depending

on the type of cellular phone you

have.

●

For the operation of the cellular

phone, see the manual that

comes with it.

■

By keypad

This operation cannot be per-
formed while driving.

1

Select “0-9”.

2

Enter the desired number.

■

By selecting “Release
Tones”

“Release Tones” appear when a
continuous tone signal (s) con-
taining a (w) is registered in the
contact list.
This operation can be per-
formed while driving.
Select “Release Tones”.

Talking on the Blue-

tooth

®

 hands-free sys-

tem

While talking on the phone,
the following screen is dis-
played. The operations out-
lined below can be
performed on this screen.

Call screen operation

Sending tones

355

5-13. Phone operation (Hands-free system for cellular phones)

5

Entune au

dio

●

A continuous tone signal is a char-

acter string that consists of num-

bers and the characters “p” or “w”.

(e.g. 056133w0123p#1)

●

When the “p” pause tone is used,

the tone data up until the next

pause tone will be automatically

sent after 2 seconds have

elapsed. When the “w” pause tone

is used, the tone data up until the

next pause tone will be automati-

cally sent after a user operation is

performed.

●

Release tones can be used when

automated operation of a phone

based service such as an answer-

ing machine or bank phone ser-

vice is desired. A phone number

with continuous tone signals can

be registered in the contact list.

●

Tone data after a “w” pause tone

can be operated by voice com-

mand during a call.

1

Select “Transmit Volume”.

2

Select the desired level for
the transmit volume.

3

Select

 to display previ-

ous screen.

●

The sound quality of the voice

heard from the other party’s

speaker may be negatively

impacted.

●

“Transmit Volume” is dimmed

when mute is on.



When there are no calls on
hold during a call: “Hold” is
displayed. When selected, the

current call is placed on hold.



When there is no current call,
but there is a call on hold:
“Activate” is displayed. When
selected, the system switches
to the call that was on hold.



When there is another call on
hold during a call: “Swap
Calls” is displayed. When
selected, the current call is
placed on hold, and the sys-
tem switches to the call that
was on hold.

This function may not be available

depending on the type of cellular

phone.

When a call is interrupted by a
third party while talking, the
incoming screen is displayed.

Select “Answer” or press the



switch on the steering wheel to
start talking with the other party.


To refuse to receive the call:
Select “Decline”.



Each time “Swap Calls” is
selected, the party who is on
hold will be switched.

This function may not be available
depending on the type of Bluetooth

®



phone.

Transmit volume setting

Switching calls while a
call is in progress

Incoming call waiting

356

5-13. Phone operation (Hands-free system for cellular phones)

1

Display the phone top
screen. (P.345)

2

Select “Message”.

A confirmation message appears

when the “Automatic Message

Transfer” function is set to off

(P.368), select “Yes”.

3

Check that the message
screen is displayed.

“Phone”: Select to change to phone

mode.



The account name is dis-
played on the left side of
screen.



Account names are the

names of the accounts that
exist on the currently con-
nected phone.



The following functions can
be used on message function:

• Receiving a message

(P.356)

• Checking messages

(P.357)

• Replying to a message (dicta-

tion reply) (P.358)

• Replying to a message (quick

reply) (P.358)

• Calling the message sender

(P.359)

• Message settings (P.368)

When an e-mail/SMS/MMS is
received, the incoming message
screen pops up with sound and
is ready to be operated on the
screen.

Select to check the message.
Select to not open the mes-
sage.
Select to call the message
sender.

●

Depending on the type of Blue-

Bluetooth

®

 phone

message function

Received messages can be
forwarded from the con-
nected Bluetooth

®

 phone,

enabling checking and
replying using the system.

Depending on the type of
Bluetooth

®

 phone con-

nected, received messages
may not be transferred to
the system.

If the phone does not sup-
port the message function,
this function cannot be
used. Even when the sup-
ported phone is used, reply
function may not be used.

Displaying the message
screen

Receiving a message

357

5-13. Phone operation (Hands-free system for cellular phones)

5

Entune au

dio

tooth

®

 phone used for receiving

messages, or its registration sta-

tus with the system, some infor-

mation may not be displayed.

●

The pop-up screen is separately

available for incoming e-mail and

SMS/MMS messages under the

following conditions:

E-mail:
• “Incoming E-mail Display” is set to

“Full Screen”. (P.361)

• “E-mail Notification Pop-up” is set

to on. (P.361)

SMS/MMS:
• “Incoming SMS/MMS Display” is

set to “Full Screen”. (P.361)

• “SMS/MMS Notification Pop-up” is

set to on. (P.361)

●

Depending on the type of Blue-
tooth

®

 phone being connected,

E-Mail function cannot be used via
Bluetooth

®

.

1

Display the message screen.
(P.356)

2

Select a desired account
name.

3

Select the desired message
from the list.

4

Check that the message is
displayed.

Select to call the message

sender.
Select to have messages
read out.
To cancel this function, select
“Stop”.
When “Automatic Message
Readout” is set to on, mes-
sages will be automatically
read out. (P.368)
Select to display the previous
or next message.
This function can be chosen
the method to reply mes-
sage with “Dictation” or
“Quick Message”.

●

Reading a text message is not

available while driving.

●

Depending on the type of Blue-
tooth

®

 phone being connected,

this function cannot be used.

●

Depending on the type of Blue-
tooth

®

 phone being connected, it

may be necessary to perform

additional steps on the phone.

●

Messages are displayed in the

appropriate connected Blue-
tooth

®

 phone’s registered mail

address folder. Select the desired

folder to be displayed.

●

Only received messages on the
connected Bluetooth

®

 phone can

be displayed.

●

The text of the message is not dis-

played while driving.

●

Turn the “POWER VOLUME”

knob, or use the volume control

switch on the steering wheel to

adjust the message read out vol-

ume.

●

“Subject:” field is not shown on

SMS case.

●

E-mail only: Select “Mark Unread”

Checking received mes-
sages
