262

5-1. Basic function

adjust the volume. Press and hold to restart the system.
(P.267,  303)
When an Apple CarPlay connection is established, press to dis-
play the Maps app screen.

*1, 2

Press to display the audio/visual system screen. (P.302, 303)
Press to display the “Menu” screen. (P.263)
Press to display the home screen. (P.270)

*1

:For details about Apple CarPlay: P.292

*2

:This function is not made available in some countries or areas.

*3

:The Toyota Entune App Suite Connect screen may not be displayed

when an Apple CarPlay connection is established.

The screen shots in this document and the actual screens of the system dif-

fer depending on whether the functions and/or a contract existed.

WARNING

For safety, the driver should not

operate the system while he/she

is driving. Insufficient attention to

the road and traffic may cause an

accident.

263

5-1. Basic function

5

Entune au

dio

Press the “MENU” button to dis-
play the “Menu” screen.

Displays the clock. Select to
display the clock settings
screen. (P.297)
Select to display the audio
control screen. (P.302)
Select to display the
hands-free operation screen.
(P.345)
When an Apple CarPlay con-
nection is established, select
to display the Phone app
screen.

*

Select to display the applica-
tion screen.

*

 (P.373)

When an Apple CarPlay con-
nection is established and
this button displays “Apple
CarPlay”, select to display
the home screen of Apple
CarPlay.

*

 (P.292)

Vehicles without DCM: Select
to display the fuel consump-
tion screen. (P.92)
Vehicles with DCM: Select to

display the information
screen.
Select “ECO” to display the
fuel consumption screen.
(P.92)
The “Vehicle Alert History”
shown on the information
screen.

*

Select to display the “Setup”
screen. (P.266)
Select to adjust the contrast,
brightness, etc. of the dis-
play. (P.274)

*

: This function is not made avail-

able in some countries or areas.

Menu screen

Menu screen operation

264

5-1. Basic function

Indicate during data commu-
nication performed via Data
Communication Module
(DCM)

*1

The reception level of Data
Communication Module
(DCM) display

*1

 (P.264)

The reception level of the
connected phone display
(P.264)
Remaining battery charge
display (P.265)
Bluetooth

®

 phone connection

condition display (P.265)
Wi-Fi

®

 connection condition

display

*1, 2

 (P.287)

*1

:Vehicles with DCM

*2

:This function is not made avail-

able in some countries or areas.

The number of status icons that can

be displayed differs depending on

the displayed screen.

The level of reception does not
always correspond with the level
displayed on the cellular phone.
The level of reception may not
be displayed depending on the
phone you have.
When the cellular phone is out
of the service area or in a place
inaccessible by radio waves,

/

 is displayed.

“Rm” is displayed when receiv-
ing in a roaming area. While
roaming, display “Rm” top-left
on the icon.
The receiving area may not be
displayed depending on the type
of Bluetooth

®

 phone you have.



While connected with cellular
phone

Status icon

Status icons are displayed
at the top of the screen.

Status icon explanation

Reception level display

Reception Level

Indicators

Poor

Excellent

265

5-1. Basic function

5

Entune au

dio



While using Data Communi-
cation Module (DCM)



While using Wi-Fi

®

Hotspot

When Wi-Fi

®

 Hotspot is off, no item

is displayed.

The amount displayed does not
always correspond with the
amount displayed on the Blue-
tooth

®

 device.

The amount of battery charge
left may not be displayed
depending on the type of the
Bluetooth

®

 device connected.

This system does not have a
charging function.

An antenna for the Bluetooth

®



connection is built into the
instrument panel.

The condition of the Bluetooth

®



connection may deteriorate and
the system may not function
when a Bluetooth

®

 phone is

used in the following conditions
and/or places:
The cellular phone is obstructed
by certain objects (such as
when it is behind the seat or in
the glove box or console box).
The cellular phone is touching or
is covered with metal materials.

Leave the Bluetooth

®

 phone in a

place where the condition of the
Bluetooth

®

 connection is good.

Reception Level

Indicators

Poor

Excellent

Reception Level

Indicators

No connection

Connected

Remaining battery charge
display

Remaining

charge

Indicators

Empty

Full

Bluetooth

®

 connection

condition display

Indicators

Conditions

(Blue)

Indicates that the con-
dition of the Blue-
tooth

®

 connection is

good.

(Gray)

While in this condition,
sound quality during
phone calls may dete-
riorate.

Indicates that the cel-
lular phone is not con-
nected via Bluetooth

®

.

266

5-1. Basic function

Press the “MENU” button, then
select “Setup” to display the
“Setup” screen. The items
shown on the “Setup” screen
can be set.

Select to change the selected
language, operation sound
settings, etc. (P.296)
Select to set Bluetooth

®



device and Bluetooth

®

 sys-

tem settings. (P.280)
Select to set audio settings.
(P.323)
Select to set the phone
sound, contacts, message
settings, etc. (P.360)
Select to set the voice set-
tings. (P.299)

Select to set vehicle informa-
tion. (P.300)
Select to set Wi-Fi

®

 connec-

tion settings.

*1, 2

 (P.288)

Select to set Toyota Entune
App Suite Connect settings.

*2



(P.383)

*1

:Vehicles with DCM

*2

:This function is not made avail-

able in some countries or areas.

“Setup” screen

“Setup” screen

267

5-2. Basic information before operation

5

Entune au

dio

5-2.Basic information before operation

After a few seconds, the caution
screen will be displayed.
After about 5 seconds or select-
ing “Continue”, the caution
screen automatically switches to
the next screen.

When system response is
extremely slow, the system can
be restarted.
Press and hold the “POWER
VOLUME” knob for 3 seconds or
more.

Initial screen

When the engine switch is
turned to ACC or ON, the
initial screen will be dis-
played and the system will
begin operating.

Caution screen

WARNING

When the vehicle is stopped with

the engine running, always apply

the parking brake for safety.

Restarting the system

268

5-2. Basic information before operation

Operations are performed by touching the touch screen directly with
your finger.

*

: The above operations may not be performed on all screens.

Flick operations may not be performed smoothly at high altitudes.

This system is operated mainly
by the buttons on the screen.
(Referred to as screen buttons
in this manual.)
When a screen button is

touched, a beep sounds. (To set
the beep sound: P.296)

●

If the system does not respond to

touching a screen button, move

your finger away from the screen

and then touch it again.

●

Dimmed screen buttons cannot be

Touch screen

Touch screen gestures

Operation method

Outline

Main use

 Touch
Quickly touch and
release once.

 Selecting an item

on the screen

 Drag

*

Touch the screen
with your finger,
and move the
screen to the
desired position.

 Scrolling the lists

 Flick

*

Quickly move the
screen by flicking
with your finger.

 Scrolling the main

screen page

Touch screen operation

269

5-2. Basic information before operation

5

Entune au

dio

operated.

●

The displayed image may become

darker and moving images may

be slightly distorted when the

screen is cold.

●

In extremely cold conditions, the

screen may not be displayed and

the data input by a user may be

deleted. Also, the screen buttons

may be harder than usual to

depress.

●

When you look at the screen

through polarized material such as

polarized sunglasses, the screen

may be dark and hard to see. If

so, look at the screen from differ-

ent angles, adjust the screen set-

tings on the display settings

screen or take off your sun-

glasses.

●

When

 is displayed on the

screen, select

 to return to the

previous screen.

The operable areas of the
capacitive touch screen buttons
use capacitive touch sensors
and may not operate properly in
the following situations:


If the screen is dirty or wet



If a source of strong electro-
magnetic waves is brought
near the screen



If a glove is worn during oper-
ation



If the screen is touched by a
fingernail



If a stylus is used to operate
the buttons



If your palm touches the oper-
able area of another button
during operation



If a button is touched quickly



If the operable part of a
capacitive touch screen but-
ton is touched by or covered
with a metal object, such as
the following, it may not oper-
ate properly:

• Magnetic isolation cards
• Metallic foil, such as the inner

packaging of a cigarette box

• Metallic wallets or bags
• Coins
• Discs, such as a CD or DVD



If the operable part of a
capacitive touch screen but-
ton is wiped, it may operate
unintentionally.



If the capacitive touch screen
button is being touched when
the engine switch is changed
to ACC or ON, the button may
not operate properly. In this
case, remove anything touch-
ing the button, turn the engine
switch off and then turn it to

NOTICE

●

To prevent damaging the

screen, lightly touch the screen

buttons with your finger.

●

Do not use objects other than

your finger to touch the screen.

●

Wipe off fingerprints using a

glass cleaning cloth. Do not use

chemical cleaners to clean the

screen, as they may damage

the touch screen.

Capacitive touch screen
buttons

270

5-2. Basic information before operation

ACC or ON, or restart the sys-
tem by press and hold the
“POWER VOLUME” knob for
3 seconds or more.

Capacitive touch screen button sen-

sor sensitivity can be adjusted.

(P.296)

1

Press the “HOME” button.

2

Check that the home screen
is displayed.

Selecting a screen will display it full

screen.

●

The display information and area

on the home screen can be cus-

tomized.

●

The home screen can be set to

several types of split layouts

Home screen

On the home screen, multi-
ple screens, such as the
audio/visual system screen,
hands-free screen and clock
screen, can be displayed
simultaneously.

Home screen operation

271

5-2. Basic information before operation

5

Entune au

dio

The display information/area on
the home screen and the home
screen layout can be changed.

1

Press the “MENU” button.

2

Select “Setup”.

If the general settings screen is not

displayed, select “General”.

3

Select “Customize Home
Screen”.

4

Select the items to be set.

Select to change the display
information and area on the
home screen.
Select to change the home
screen layout.

When searching by a name or
entering data, letters and num-
bers can be entered via the
screen.

Text field. Entered charac-
ter(s) will be displayed.
Select to erase one charac-
ter.
Select and hold to continue
erasing characters.
Select to move the cursor.
Select to choose predictive
text candidate for entered
text. (P.272)
Select to display a list of pre-
dictive text candidates when
there is more than one.
(P.272)
Select to enter desired char-
acters.
Select to enter characters in
lower case or in upper case.

Customizing the home
screen

Entering letters and

numbers/list screen

operation

Entering letters and num-
bers

272

5-2. Basic information before operation

Select to change character
types. (P.272)
Select to make a space on
cursor.

Keyboard layout can be changed.

(P.296)

1

Select “Change Type”.

2

Select the desired character.

Depending on the screen being dis-

played, it may not be possible to

change keyboard characters.

When text is input, the system
predicts the text that may com-
plete the currently unconfirmed
text and displays predictive
replacement candidates that
match the beginning of the text.

1

Input text.

2

Select the desired candidate.

To select a candidate that is not
displayed, select

, and

then select the desired predic-
tive replacement candidate.

The list screen may be dis-
played after entering characters.
When a list is displayed, use the
appropriate screen button to
scroll through the list.

Changing character type

Displaying predictive text
candidates

List screen

Scrolling list screen

273

5-2. Basic information before operation

5

Entune au

dio

To scroll up/down the list,
flick the list up/down.
Select to skip to the next or
previous page. Select and
hold

 or

 to scroll

through the displayed list.
Indicates the position of the
displayed entries in the entire
list.
To scroll up/down pages,
drag the bar.

If

 appears to the right of an item

name, the complete name is too

long to display.

●

Select to

 scroll to the end of

the name.

●

Select

 to move to the begin-

ning of the name.

Items are displayed in the list
with the most similar results of
the search at the top.

1

Select

.

2

Input text.

3

Select “Search”.

4

The list is displayed.

Searching a list

274

5-2. Basic information before operation

1

Press the “MENU” button.

2

Select “Display”.

3

Select the desired items to
be set.

Select to turn the screen off.
To turn it on, press any but-

ton.
Select to turn day mode
on/off. (P.274)
Select to adjust the screen
display. (P.274)
Select to adjust the camera
display.

When the screen is viewed through

polarized sunglasses, a rainbow

pattern may appear on the screen

due to optical characteristics of the

screen. If this is disturbing, please

operate the screen without polarized

sunglasses.

Depending on the position of the
headlight switch, the screen
changes to day or night mode.
This feature is available when
the headlight is switched on.
Select “Day Mode”.

If the screen is set to day mode with

the headlight switch turned on, this

condition is memorized even with

the engine turned off.

The contrast and brightness of
the screen can be adjusted
according to the brightness of
your surroundings.

1

Select “General” or “Cam-
era”.

2

Select the desired item.

“Display (General)” screen only:

Screen adjustment

The contrast and brightness
of the screen display and
the image of the camera dis-
play can be adjusted. The
screen can also be turned
off, and/or changed to either
day or night mode.

(For information regarding
audio/visual screen adjust-
ment: P.305)

Displaying the screen
adjustment screen

Changing between day
and night mode

Adjusting the con-
trast/brightness

275

5-2. Basic information before operation

5

Entune au

dio

Select “<” or “>” to select the

desired display.



“Contrast”

“+”: Select to strengthen the con-
trast of the screen.
“-”: Select to weaken the contrast of
the screen.



“Brightness”

“+”: Select to brighten the screen.
“-”: Select to darken the screen.

Linking multi-informa-

tion display and the

system

The following functions of
the system are linked with
the multi-information dis-
play in the instrument clus-
ter:



Audio



Phone

*

etc.

These functions can be
operated using multi-infor-
mation display control
switches on the steering
wheel. (P.87)

*

: When an Apple CarPlay con-

nection is established, this
function will be unavailable.

276

5-3. Connectivity settings

5-3.Connectivity settings

●

This system is not guaranteed to
operate with all Bluetooth

®



devices.

●

If your cellular phone does not

support HFP, registering the Blue-
tooth

®

 phone or using OPP,

PBAP, MAP or SPP profiles indi-

vidually will not be possible.

●

If the connected Bluetooth

®



device version is older than rec-

ommended or incompatible, the
Bluetooth

®

 device function may

not work properly.

●

Refer to

http://www.toyota.com/Entune/

in the United States,

http://www.toyota.ca/entune in

Canada, and

http://www.toyotapr.com/entune in

Puerto Rico, to find approved

Bluetooth

®

 phones for this sys-

tem.

●

Certification

Bluetooth is a registered trademark

of Bluetooth SIG, Inc.

■

Registering from the sys-
tem

1

Turn the Bluetooth

®

 connec-

tion setting of your cellular
phone on.

This function is not available when
Bluetooth

®

 connection setting of

your cellular phone is set to off.

2

Press the “MENU” button.

3

Select “Phone”.

Operations up to this point can also

be performed by pressing the

“PHONE” button on the instrument

panel.

Registering/Connect-

ing a Bluetooth

®



device

To use the hands-free sys-
tem, it is necessary to regis-
ter a Bluetooth

®

 phone with

the system.

Once the phone has been
registered, it is possible to
use the hands-free system.

This operation cannot be
performed while driving.

When an Apple CarPlay
connection is established,
Bluetooth

®

 functions of the

system will become unavail-
able and any connected
Bluetooth

®

 devices will be

disconnected.

Registering a Bluetooth

®



phone for the first time

277

5-3. Connectivity settings

5

Entune au

dio

4

Select “Yes” to register a
phone.

5

Select the desired Bluetooth

®



device.

If the desired Bluetooth

®

 phone is

not on the list, select “If you cannot

find...” and follow the guidance on

the screen. (P.278)

6

Register the Bluetooth

®



device using your Blue-
tooth

®

 device.



For details about operating
the Bluetooth

®

 device, see

the manual that comes with it.



A PIN code is not required for
SSP (Secure Simple Pairing)

compatible Bluetooth

®



devices. Depending on the
type of Bluetooth

®

 device

being connected, a message
confirming registration may
be displayed on the Blue-
tooth

®

 device’s screen.

Respond and operate the
Bluetooth

®

 device according

to the confirmation message.

7

Check that the following
screen is displayed, indicat-
ing pairing was successful (a
Bluetooth

®

 link has been

established but registration is
not yet complete).



The system is connecting to
the registered device.



At this stage, the Bluetooth

®



functions are not yet avail-
able.
