Toyota Tundra (2015 year). Manual - part 996
Last Modified: 9-16-2014
6.6 A
Doc ID: RM000002ZY1015X
Model Year: 2015
Model: Tundra
Prod Date Range: [08/2014 - ]
Title: AUDIO / VISUAL: INSTRUMENT PANEL SPEAKER (for Regular Cab): INSTALLATION; 2015 MY Tundra
[08/2014 - ]
INSTALLATION
1. INSTALL FRONT NO. 2 SPEAKER ASSEMBLY RH
(a) Connect the connector.
(c) Install the front No. 2 speaker assembly RH with the 2 bolts.
Torque:
3.5 N·m {36 kgf·cm, 31in·lbf}
NOTICE:
(a) Connect the connector.
(c) Install the front No. 2 speaker assembly LH with the 2 bolts.
Torque:
3.5 N·m {36 kgf·cm, 31in·lbf}
NOTICE:
(a) Attach the 2 guides, 3 clips and 3 claws to install the No. 2 instrument panel speaker panel sub-assembly.
4. INSTALL NO. 1 INSTRUMENT PANEL SPEAKER PANEL SUB-ASSEMBLY
(a) Attach the 2 guides, 3 clips and 3 claws to install the No. 1 instrument panel speaker panel sub-assembly.
5. INSTALL FRONT PILLAR GARNISH RH
6. INSTALL FRONT PILLAR GARNISH LH
