peeled off or discolored, or 3) grooves or printed numbers have Before assembling new discs, soak them in ATF for at least 2 hours. 25. INSPECT REAR PLANETARY GEAR ASSEMBLY (a) Using a feeler gauge, measure the rear planetary gear pinion thrust clearance. Standard clearance: 0.2 to 0.6 mm (0.00787 to 0.0236 in.) If the clearance is greater than the standard, replace the planetary gear assembly. Standard inside diameter: 20.0 to 20.025 mm (0.787 to 0.788 in.) If the inside diameter is greater than the standard, replace the rear planetary gear assembly. 26. INSPECT 1ST AND REVERSE BRAKE RETURN SPRING SUB-ASSEMBLY Standard free length: 23.54 to 23.94 mm (0.927 to 0.943 in.) AB60F AUTOMATIC TRANSMISSION: AUTOMATIC TRANSMIS... |
