MARK THICKNESS Z 4.325 to 4.374 mm (0.17028 to 0.17220 in.) 6. INSTALL BRAKE PLATE STOPPER SPRING 7. INSTALL REAR PLANETARY RING GEAR (a) Install the rear planetary ring gear flange on the rear planetary ring gear. (b) Using a screwdriver, install the snap ring. (c) Install the 3 thrust bearing races, thrust needle roller bearing and planetary ring gear with the rear planetary ring gear flange to the intermediate shaft. HINT: Bearing and race diameter: ITEM INSIDE OUTSIDE Front race H 39.5 to 39.8 mm (1.56 to 1.57 in.) 56.9 to 57.2 mm (2.24 to 2.25 in.) AB60E AUTOMATIC TRANSMISSION: AUTOMATIC TRANSMIS... |
