Toyota Tundra (2015 year). Manual - part 2906
Last Modified: 9-16-2014
6.6 A
Doc ID: RM00000308P009X
Model Year: 2015
Model: Tundra
Prod Date Range: [08/2014 - ]
Title: EXTERIOR: FRONT DOOR BELT MOULDING (for Regular Cab): INSTALLATION; 2015 MY Tundra [08/2014
- ]
INSTALLATION
HINT:
Use the same procedures for the RH side and LH side.
The procedures listed below are for the LH side.
1. INSTALL FRONT OUTER DOOR GLASS WEATHERSTRIP
ASSEMBLY LH
(a) Attach the claw to install the weatherstrip.
2. INSTALL FRONT REAR DOOR GUIDE BRACKET GARNISH LH
(a) Clean the radiator front door surface.
(1) Using a heat light, heat the front door surface.
(2) Remove the double-sided tape from the front door.
(3) Wipe off any tape adhesive residue with cleaner.
(b) If reusing the garnish:
Clean the garnish.
(1) Remove the double-sided tape from the garnish.
(2) Wipe off any tape adhesive residue with cleaner.
(3) Apply new double-sided tape to the garnish, as shown in the
illustration.
(c) Install the garnish.
