Toyota Tundra (2015 year). Manual - part 2477
15. INSTALL SEAT CUSHION CLIMATE CONTROL DUCT LH (w/ Climate Control Seat
System)
16. INSTALL SEAT HEATER CONTROL SUB-ASSEMBLY LH (w/ Seat Heater System)
17. INSTALL OCCUPANT CLASSIFICATION ECU (for Front Passenger Side)
18. INSTALL SEPARATE TYPE FRONT SEAT CUSHION COVER WITH PAD
19. INSTALL FRONT SEATBACK FRAME SUB-ASSEMBLY LH
(a) Attach the 2 guides and 2 clips to install the lumbar support adjuster assembly LH to the front seatback
frame sub-assembly LH.
20. INSTALL SEATBACK CLIMATE CONTROL BLOWER LH (w/ Climate Control Seat System)
21. INSTALL FRONT SEATBACK WIRE LH (for Driver Side)
22. INSTALL FRONT SEATBACK WIRE RH (for Front Passenger Side)
23. INSTALL FRONT SEAT AIRBAG ASSEMBLY LH
24. INSTALL SEPARATE TYPE FRONT SEATBACK PAD
25. INSTALL SEPARATE TYPE FRONT SEATBACK COVER
26. INSTALL SEPARATE TYPE FRONT SEATBACK ASSEMBLY
27. INSTALL FRONT INNER NO. 1 SEAT CUSHION SHIELD LH
28. INSTALL FRONT SEAT CUSHION SHIELD LH
29. INSTALL SEAT POSITION AIRBAG SENSOR
30. INSTALL FRONT SEAT INNER BELT ASSEMBLY LH (for Driver Side)
31. INSTALL FRONT SEAT INNER BELT ASSEMBLY RH (for Front Passenger Side)
32. INSTALL FRONT SEAT ASSEMBLY
33. CHECK SRS WARNING LIGHT
34. INSPECT FRONT SEAT ASSEMBLY
(a) w/o Seat Position Memory System:
(b) w/ Seat Position Memory System:
35. INSPECT SEAT HEATER SYSTEM (w/ Seat Heater System)
SEAT: FRONT POWER SEAT MOTOR ASSEMBLY: INSTALLATION; ...
