OK NEXT Check / Manual Mode / AIR PUMP 1: ON, ASV 1: OPEN, AIR PUMP 2: ON, ASV 2: OPEN. HINT: When Manual Mode is selected, the Techstream initialization (atmospheric pressure measurement) is performed automatically. The initialization takes 10 seconds. After the initialization, AIR PUMP and ASV (n) Start the engine. (o) Perform the AIR system forced operation while the engine is idling. (q) Turn the ignition switch off. NOTICE: TESTER CONNECTION CONDITION SPECIFIED CONDITION D50-4 (SIP) - D50-1 (E) AIR PUMP: ON, ASV: OPEN 0.5 to 2 V D54-4 (SIP2) - D54-1 (E2) AIR PUMP: ON, ASV: OPEN 0.5 to 2 V D50-4 (SIP) - D50-1 (E) AIR PUMP: OFF, ASV: CLOSE 11 to 14 V D54-4 (SIP2) - D54-1 (E2) AIR PUMP: OFF, ASV: CLOSE 11 to 14 V NG REPLACE ECM 6. REPLACE AIR INJECTION CONTROL DRIVER (FOR BANK 1 OR BANK 2) (a) Replace the air injection control driver (for bank 1 or bank 2)
. 7. CONFIRM WHETHER DTC OUTPUT RECURS (a) Start the engine and warm it up. (b) Turn the ignition switch off. 3UR-FBE ENGINE CONTROL SYSTEM: SFI SYSTEM: P1613,P1614... |
