Toyota Tundra (2015 year). Manual - part 1583





OK

OK

OK

(a) Repair or replace the throttle body assembly



.

NEXT

GO TO STEP 14

5.

CHECK PCV SYSTEM

(a) Start the engine.

(b) Pinch the positive crankcase ventilation hose.

(c) Check the engine rpm.

OK:

The engine rpm rises when the PCV hose is pinched.

NG

GO TO STEP 10

6.

CHECK AIR INDUCTION SYSTEM

(a) Check the air induction system for vacuum leaks



.

OK:

No leakage from the air induction system.

NG

GO TO STEP 11

7.

CHECK AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY

(a) Visually check that the air cleaner filter element sub-assembly is not excessively contaminated

with dirt or oil.

OK:

The air cleaner filter element sub-assembly is not excessively contaminated with dirt or oil.

NG

GO TO STEP 12

3UR-FBE ENGINE CONTROL SYSTEM: SFI SYSTEM: P050B; Cold...

OK

OK

8.

PERFORM ACTIVE TEST USING TECHSTREAM (OPERATE CAMSHAFT TIMING OIL
CONTROL VALVE)

(a) Operate the VVT system through the Active test, and check if the VVT system is operating

normally.

(1) (1) Perform the Active Test, referring to DTC P0011 inspection procedure (VVT system for

intake camshaft)



.

(2) Perform the Active Test, referring to DTC P0014 inspection procedure (VVT system for

exhaust camshaft)



.

NG

GO TO STEP 13

9.

READ VALUE USING TECHSTREAM (MAF)

NG

GO TO STEP 15

10.

REPAIR OR REPLACE PCV SYSTEM

(a) Repair or replace the PCV system.

NEXT

GO TO STEP 14

11.

REPAIR OR REPLACE AIR INDUCTION SYSTEM

(a) Repair or replace the air induction system.

NEXT

GO TO STEP 14

12.

REPLACE AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY

(a) Replace the air cleaner filter element sub-assembly.

NEXT

GO TO STEP 14

3UR-FBE ENGINE CONTROL SYSTEM: SFI SYSTEM: P050B; Cold...

NEXT

13.

CHECK AND REPAIR VVT SYSTEM

(a) Check and repair the VVT system.

HINT:

Refer to DTC P0011 Inspection Procedure (VVT system for intake side)



.

Refer to DTC P0014 Inspection Procedure (VVT system for exhaust side)



.

14.

CHECK WHETHER DTC OUTPUT RECURS (DTC P050B)

NOTICE:

For this operation, the engine must be cold (the same level as the engine coolant temperature recorded

in the freeze frame data).

(a) Connect the Techstream to the DLC3.

(b) Turn the ignition switch to ON.

(c) Turn the Techstream ON.

(d) Clear the DTCs



.

(e) Turn the ignition switch off and wait for at least 30 seconds.

(f) Turn the ignition switch to ON and turn the Techstream on.

(g) Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Coolant Temp.

(h) Check that the engine coolant temperature is between - 10°C and 50°C (14 and 122°F).

(i) Start the engine and warm it up.

(j) Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving

Pattern

(k) Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.

(l) Input the DTC: P050B.

(m) Check the DTC judgment result.

Result

RESULT

PROCEED TO

NORMAL (DTC is not output)

A

ABNORMAL (DTC P050B is output)

B

B

GO TO STEP 15

A

CHECK FOR INTERMITTENT PROBLEMS

3UR-FBE ENGINE CONTROL SYSTEM: SFI SYSTEM: P050B; Cold...

NEXT

15.

CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER CONNECTOR
CONNECTION)



.

HINT:

Repair any problems.

16.

CHECK WHETHER DTC OUTPUT RECURS (DTC P050B)

NOTICE:

For this operation, the engine must be cold (the same level as the engine coolant temperature recorded

in the freeze frame data).

(a) Connect the Techstream to the DLC3.

(b) Turn the ignition switch to ON.

(c) Turn the Techstream ON.

(d) Clear the DTCs



.

(e) Turn the ignition switch off and wait for at least 30 seconds.

(f) Turn the ignition switch to ON and turn the Techstream on.

(g) Enter the following menus: Powertrain / Engine and ECT / Data List / All Data / Coolant Temp.

(h) Check that the engine coolant temperature is between - 10°C and 50°C (14 and 122°F).

(i) Start the engine and warm it up.

(j) Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving

Pattern

(k) Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.

(l) Input the DTC: P050B.

(m) Check the DTC judgment result.

Result

RESULT

PROCEED TO

ABNORMAL (DTC P050B is output)

A

NORMAL (DTC is not output)

B

B

END

3UR-FBE ENGINE CONTROL SYSTEM: SFI SYSTEM: P050B; Cold...
