DTC NO. DTC DETECTION CONDITION TROUBLE AREA P0010 Open or short in OCV (for intake side of bank 1) circuit (1 trip detection logic) Open or short in OCV (for intake side of bank 1) circuit P0020 Open or short in OCV (for intake side of bank 2) circuit (1 trip detection logic) Open or short in OCV (for intake side of bank 2) circuit HINT: This DTC relates to the Camshaft Timing Oil Control Valve (OCV). MONITOR DESCRIPTION This DTC is designed to detect opens or shorts in the camshaft timing oil control valve assembly (OCV) circuit. If the OCV's duty-cycle is excessively high or low while the engine is running, the ECM will illuminate the MIL and set the DTC. MONITOR STRATEGY Related DTCs P0010: VVT OCV range check (Bank 1) P0020: VVT OCV range check (Bank 2) Required Sensors/Components (Main) Camshaft timing oil control valve assembly (for intake side) Required Sensors/Components (Related) - Duration 1 second MIL Operation Immediate TYPICAL ENABLING CONDITIONS All Monitor runs whenever following DTCs not stored None Starter OFF Ignition switch ON Time after ignition switch off to ON 0.5 seconds or more Case 1 Battery voltage 11 to 13 V 3UR-FBE ENGINE CONTROL SYSTEM: SFI SYSTEM: P0010,P002... |
