6.6 U
Doc ID: RM000004MNK0ANX
Model Year: 2015
Model: Tundra
Prod Date Range: [08/2014 - ]
Title: NAVIGATION: NAVIGATION SYSTEM: DATA LIST / ACTIVE TEST; 2015 MY Tundra [08/2014 - ]
DATA LIST / ACTIVE TEST
1. DATA LIST
NOTICE:
In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely
on these reference values when deciding whether a part is faulty or not.
HINT:
(a) Connect the Techstream to the DLC3.
(b) Turn the ignition switch to ON.
(c) Turn the Techstream on.
(d) Enter the following menus: Body Electrical / Navigation System / Data List.
(e) According to the display on the Techstream, read the Data List.
Navigation System
TESTER
DISPLAY
MEASUREMENT ITEM/RANGE
NORMAL CONDITION
DIAGNOSTIC NOTE
Battery
Voltage
Battery voltage/ Min.: 0 V, Max.: 24 V
11 to 14 V
-
Active
Dimmer
Active dimmer function/ON or OFF
ON: Active dimmer
function on
OFF: Active dimmer
function off
-
Tail Light
SW
Taillight switch/ON or OFF
ON: Light control switch
in tail or head position
OFF: Light control switch
off
-
Reverse
Signal
Reverse signal/ON or OFF
ON: Reverse selected
OFF: Reverse not
selected
-
Parking
Brake
Parking brake switch/ON or OFF
ON: Parking brake
applied
OFF: Parking brake
released
-
Ignition
Ignition switch/ON or OFF
ON: Ignition switch ON
OFF: Ignition switch off
-
NAVIGATION: NAVIGATION SYSTEM: DATA LIST / ACTIVE TEST...
