Title: AUDIO / VISUAL: RADIO RECEIVER (for Floor Shift Type): INSTALLATION; 2015 MY Tundra [08/2014 -
]
INSTALLATION
1. INSTALL STEREO COMPONENT TUNER ASSEMBLY (w/ Satellite Radio)
2. INSTALL NO. 2 RADIO RECEIVER BRACKET
(a) w/o Satellite Radio:
Install the No. 2 radio receiver bracket with the 3 bolts.
Torque:
3.5 N·m {36 kgf·cm, 31in·lbf}
(b) w/ Satellite Radio:
Install the No. 2 radio receiver bracket with the 5 bolts.
Torque:
3.5 N·m {36 kgf·cm, 31in·lbf}
3. INSTALL NO. 1 RADIO RECEIVER BRACKET
(a) w/o Satellite Radio:
Install the No. 1 radio receiver bracket with the 3 bolts.
Torque:
3.5 N·m {36 kgf·cm, 31in·lbf}
(b) w/ Satellite Radio:
Install the No. 1 radio receiver bracket with the 5 bolts.
Torque:
3.5 N·m {36 kgf·cm, 31in·lbf}
4. INSTALL NO. 1 NAVIGATION WIRE (w/ Satellite Radio)
5. INSTALL RADIO AND DISPLAY RECEIVER ASSEMBLY
(a) Connect each connector.
(b) Insert the radio and display receiver assembly with bracket and attach the 2 guides and 3 clips on its
backside.
NOTICE:
When inserting the radio receiver, do not press its knobs.
(c) Install the radio and display receiver assembly with bracket with the 4 bolts.
Torque:
5.5 N·m {56 kgf·cm, 49in·lbf}
6. INSTALL AIR CONDITIONING CONTROL ASSEMBLY
7. INSTALL UPPER CONSOLE PANEL SUB-ASSEMBLY
8. INSTALL REAR UPPER CONSOLE PANEL SUB-ASSEMBLY
