Suzuki Grand Vitara JB627. Manual - part 203

4F-51 Electronic Stability Program:

Specifications

Tightening Torque Specifications

S6JB0B4607001

Reference:
For the tightening torque of fastener not specified in this section, refer to “Fastener Information in Section 0A”.

Special Tools and Equipment

Special Tool

S6JB0B4608001

Fastening part

Tightening torque

Note

N

⋅m

kgf-m

lb-ft

Yaw rate / G sensor assembly bolt

8

0.8

6.0

)

09956–02311

SUZUKI scan tool

Brake pressure gauge

—

)

This kit includes following
items. 1. Tech 2, 2. PCMCIA
card, 3. DLC cable, 4. SAE
16/19 adapter, 5. Cigarette
cable, 6. DLC loop back
adapter, 7. Battery power
cable, 8. RS232 cable, 9.
RS232 adapter, 10. RS232
loop back connector, 11.
Storage case, 12. ) / ) / )
/ ) / ) / ) / )
