DI-21

General Description

DIFFERENTIALS

399703600

PULLER ASSY

Used for removing companion flange.

899874100

INSTALLER

Used for installing the companion flange.

498077000

REMOVER

• Used for removing the differential side bearing
cone.
• For VA2-type

899864100

REMOVER

Used for removing the differential side bearing.

499277200

INSTALLER

• Used for installing the front bearing cone.
• For VA2-type

ILLUSTRATION

TOOL NUMBER

DESCRIPTION

REMARKS

ST-399703600

ST-899874100

ST-498077000

ST-899864100

ST-499277200

DI-22

General Description

DIFFERENTIALS

18758AA000

PULLER

• Used for removing side bearing cup.
• For VA2-type

18759AA000

PULLER ASSY

• Used for removing the differential side bearing
cone.
• For T-type

18678AA000

DUMMY SHAFT

• Used for adjusting pinion height and preload.
• For VA2-type

18831AA010

DIFFERENTIAL
CARRIER GAUGE

• Used for adjusting pinion height.
• For VA2-type

18630AA010

WRENCH COMPL
RETAINER

• Used for removing and installing the side oil
seal holder.
• For  VA-type
• WRENCH ASSY (499787000) can also be
used.

ILLUSTRATION

TOOL NUMBER

DESCRIPTION

REMARKS

ST18758AA000

ST18759AA000

ST18678AA000

ST18831AA010

ST18630AA010

DI-23

General Description

DIFFERENTIALS

498175500

INSTALLER

• Used for installing the rear bearing cone.
• For VA1-type

498447100

INSTALLER

• Used for installing the oil seal.
• For VA1-type and T-type

399520105

SEAT

• Used for removing the side bearing cone.
• Used together with the PULLER SET
(899524100).
• For  VA-type

498485400

DRIFT

• Used for installing side bearing cone.
• For VA1-type

498505501

DIFFERENTIAL
CARRIER GAUGE

• Used for adjusting pinion height.
• For VA1-type

ILLUSTRATION

TOOL NUMBER

DESCRIPTION

REMARKS

ST-498175500

ST-498447100

ST-399520105

ST-498485400

ST-498505501

DI-24

General Description

DIFFERENTIALS

498447110

DRIFT

• Used for press-fitting the bearing race (front)
of the differential carrier.
• For VA1-type

498447150

DUMMY SHAFT

• Used for adjusting pinion height and preload.
• For VA1-type

899524100

PULLER SET

Used for removing the differential side bearing
cone.
(1) Puller
(2) Cap

498515500

REPLACER

• Used for removing rear bearing cone.
• For VA1-type

499705404

SEAT

• Used for removing the side bearing race.
• Used together with PULLER ASSY
(499705401).
• For VA1-type

ILLUSTRATION

TOOL NUMBER

DESCRIPTION

REMARKS

ST-498447110

ST-498447150

ST-899524100

(1)

(2)

ST-498515500

ST-499705404
