5AT-12

General Description

AUTOMATIC TRANSMISSION

8. DIFFERENTIAL GEAR

(1)

Lock plate

(8)

Pinion shaft

(14)

Differential bevel pinion

(2)

Differential side retainer RH

(9)

Straight pin

(15)

Differential side retainer LH

(3)

O-ring

(10)

Differential case RH

(4)

Oil seal

(11)

Differential case LH

Tightening torque:N·m (kgf-m, ft-lb)

(5)

Taper roller bearing

(12)

Differential bevel gear

T1: 25 (2.5, 18.4)

(6)

Hypoid driven gear

(13)

Washer

T2: 70 (7.1, 51.6 )

(7)

Drive pinion shaft





AT-03807

(1)

(7)

(8)

(13)

(12)

(12)

(14)

(13)

(1)

(2)

(3)

(5)

(10)

(6)

(9)

(11)

(5)

(3)

(15)

(4)

(4)

(14)

T1

T2

T1

5AT-13

General Description

AUTOMATIC TRANSMISSION

9. TRANSFER CASE, EXTENSION CASE & REDUCTION GEAR

AT-03533

(45)

(47)

(48)

(46)

(43)

(44)

(10)

(12)

(13)

(15)

(14)

(4)

(3)

(6)

(5)

(7)

(8)

(9)

(11)

(2)

(18)

(20)

(34)

(33)

(32)

(35)

(37)

(36)

(38)

(40)

(42)

(41)

(21)

(22)

(23)

(24)

(25)

(26)

(27)

(28)

(29)

(30)

(31)

(19)

(17)

(16)

(1)

(39)

(49)

5AT-14

General Description

AUTOMATIC TRANSMISSION

(1)

Seal ring

(18)

Transfer clutch hub

(34)

Reduction driven gear

(2)

Reduction gear shim

(19)

Transfer clutch plate

(35)

Snap ring

(3)

Ball bearing

(20)

Driven plate No. 3

(36)

Ball bearing

(4)

Snap ring

(21)

Ball bearing

(37)

Shim

(5)

Planetary pinion washer

(22)

Rear drive shaft shim

(38)

Shim

(6)

Needle bearing

(23)

Revolution gear

(39)

Extension case

(7)

Spacer

(24)

Snap ring

(40)

Transmission hanger

(8)

Pinion gear

(25)

Clutch spring retainer

(41)

Oil seal

(9)

Washer

(26)

Return spring

(42)

Dust cover

(10)

Planetary carrier ASSY

(27)

Spring retainer

(43)

Taper roller bearing

(11)

Planetary pinion shaft ASSY

(28)

Pressure plate

(44)

Drive pinion shim

(12)

Snap ring

(29)

Ball bearing

(45)

Oil seal

(13)

Thrust bearing

(30)

O-ring

(46)

Drive pinion collar

(14)

Intermediate shaft

(31)

D-ring

(47)

O-ring

(15)

Thrust washer

(32)

Drive pinion shaft

(48)

Lock nut

(16)

Rear drive shaft

(33)

Ball bearing

(49)

O-ring

(17)

Ball

bearing





5AT-15

General Description

AUTOMATIC TRANSMISSION

10.TRANSMISSION CONTROL DEVICE & PARKING SUPPORT

(1)

Bracket

(9)

Parking support actuator

(17)

Ball bearing

(2)

Floating bracket

(10)

Parking pawl shaft





(3)

AT main case

(11)

Return spring

Tightening torque:N·m (kgf-m, ft-lb)

(4)

Range select lever

(12)

Parking pawl

T1: 6 (0.6, 4.4)

(5)

Straight pin

(13)

Ball bearing

T2: 7 (0.7, 5.2)

(6)

Detent spring

(14)

Snap ring

T3: 25 (2.5, 18.4)

(7)

Manual plate

(15)

Parking gear

T4: <Ref. to 5AT-79, Parking Pawl.>

(8)

Parking rod

(16)

Reduction driven gear





T3

T3

T4

T1

T2

(1)

(2)

(3)

(10)

(11)

(8)

(7)

(5)

(4)

(6)

(12)

(13)

(14)

(15)

(16)

(17)

(9)

AT-03872
