11-16

Radio

CD/MP3

2) Display Window

Radio station band: FM1/FM2/AM

FM stereo reception display

EQ: POP/ROCK/COUNTRY/VOICE/JAZZ/

CLASSIC

Receiving broadcasting frequency

Digital clock

Specified station number: P1~P6

1.

2.

3.

4.

5.

6.

Disc insertion display

Play mode display

RDM (Random): Play folder in random

orderRPT (Repeat): Play folder

repeatedly

INT (Intro): Play folder intro

Current folder name

Play disc

Current playing song name

Other information of current playing song:

Play time/album/artist/genre

7.

8.

9.

10.

11.

12.

USB

USB connection

USB play

13.

14.

BT AUDIO

Bluetooth connection

15.

11-17

8910-05

Tone setup

▶

When pressing the SET button, "Setup List" is displayed.

- "Setup List" screen is displayed only for 5 seconds.

Turn the [TUNE] dial to select a desired "Tone Setup" and press the [ENTER] button.
- Press the [1BACK◀] button in order to go back to the previous screen.

Turn the [TUNE] dial to select a desired setup item and press the [ENTER] button.
- Select one of the following: Bass ↔ Middle ↔ Treble ↔ Balance ↔Fader ↔ EQ (sound effect).

Turn the [TUNE] dial or press the [ENTER] button to select the desired setting value.

- Bass: setting the bass level (-7 ~ +7)

- Middle: setting the middle level (-7 ~ +7)

- Balance: setting LH/RH speaker balance (LEFT 15 ~ RIGHT 15)

- EQ (Equalizer): select EQ (sound effect) style.
  (EQ OFF ↔ POP ↔ ROCK ↔ COUNTRY ↔ VOICE ↔ JAZZ ↔ CLASSIC)

- Default: initialize all the settings.

1.

2.

3.

4.

Set the Bass/Middle/Treble, Balance and EQ (sound effect) for the sound of the output speaker.

5. SETTINGS

11-18

Turn the power off and set the displayed current time and date.

▶

When pressing the SET button, "Setup List" is displayed.

- "Setup List" screen is displayed only for 5 seconds.

Turn the [TUNE] dial to select a desired "Time & Date" and press the [ENTER] button.
- Press the [1BACK◀] button in order to go back to the previous screen.

Turn the [TUNE] dial to select a desired setup item and press the [ENTER] button.
- Select one of the followings: Set Time ↔ Set Time Format ↔ Set Date ↔ Display Digital

  Clock On/Off

Turn the [TUNE] dial or press the [ENTER] button to select the desired setting value. Repeat these

steps if several items need to be set. (e.g. YY/MMDD in date setting)

- Set Time: Set the current time.

- Set Time Format: Set the time format to 12-hour or 24-hour system.

- Set Date: Set the date.

- Display Digital Clock On/Off: Set whether the digital clock is displayed or not.

1.

2.

3.



4.

6. CURRENT TIME/DATE SETTING

11-19

8910-05

Listening radio station

▶

Press the [BAND] button repeatedly to select the desired broadcasting band.

- Select one of FM1, FM2 or AM.

- Broadcasting is received from the broadcasting frequency which has been listening previously.

1.

Searching for broadcasting manually

Turn the [TUNE] dial or press the <<ADJ>> button repeatedly to select the desired broadcasting

frequency.

▷

2.

Searching for broadcasting automatically

Press the <<ADJ>> button more than 2 seconds and release it so that the system searches for one

broadcasting frequency with good reception and receives it automatically.

▷

3.

Selecting broadcasting with automatic search

When pressing the [SCAN] button, the system searches for the broadcasting with good reception

one by one within the receiving frequency range and gives a hearing about for 5 seconds. If you hear

the desired broadcasting, press the [SCAN] button briefly to keep listening it.

▷

4.

Registering broadcasting frequency manually

▶

Select the broadcasting frequency to register.
When the [1BACK◀] ~ [6FLDR▲] buttons to register is pressed for more than 2 seconds,

the beep sounds to indicate the registration is completed.

1.

2.

Registering broadcasting frequency automatically

▶

Press the [BAND] button repeatedly to select the desired broadcasting band.

- Select one of FM1, FM2 or AM.

- The system shows the selected frequency previously in the selected broadcasting band

  and receives it.

Press the [AS] button for more than 2 seconds.

- "AST Scanning" is displayed, and the system searches for 6 stations with good reception
  one by one to register them to each [1BACK◀] ~ [6FLDR▲] button.

1.

2.

Listening registered station

▶

Press the [BAND] button repeatedly to select the desired broadcasting band.

- Select one of FM1, FM2 or AM.

- The system shows the selected frequency previously in the selected broadcasting band

  and receives it.
Press the desired button between [1BACK◀] and [6FLDR▲] to listen the broadcasting.

1.

2.

7. RADIO SETTINGS
